Clam POLAR TRAILER HD 1500 TA Manual

Clam POLAR TRAILER HD 1500 TA Manual

Advertisement

- S P E C IF I C AT I O N S:
Part Number:
Load Capacity:
Load Size:
Heap Load Size:
Dimensions:
Overall Weight:
Tires:
Instruction P/N
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
IMPORTANT-PLEASE READ:
CLAM OUTDOORS INC. warrants to the original retail purchaser its product be free from manufacturers defects for (5)
years from the date of the original purchase. Clam Outdoors Inc will replace or repair any part found defective within the
(5) year time limit. All parts must be returned to Clam Outdoors Inc. Before returning any parts, you must first call or write
and acquire a return authorization. All returns must be returned postage-prepaid and include the original cash register
receipt (date and purchase price).
To submit a warranty claim request, please use one of the following methods:
https://polartrailer.com/pages/warranty-form
Email:
customerservice@clamcorp.com
The warranty does not apply to any Polar Trailer which has been subjected to an accident, improper installation,
modification, adjustment, repair, misuse, misapplication, neglect, including but not limited to improper maintenance, or
use of unauthorized parts or attachments.
LIMITATION OF LIABILITY
It is expressly understood that Clam Outdoors Inc. liability for its products, whether due to breach of warranty, negligence,
strict liability, or otherwise, is limited to the repair of the product as stated above. Clam Outdoor Inc. is not liable for any
injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit,
or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or replacement
of Clam Outdoor Inc. products. Clam Outdoor Inc. reserves the right to make alterations or modifications in its products
at any time, which in its opinion, may improve the performance and efficiency of the product. It shall not be obligated to
make such alterations or modifications to products already in service.
Clam contact information
Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
▪ Clam Outdoors
Attn: Customer Service
12135 Brockton Lane
Rogers, MN 55369
▪ Phone: 763-231-4120
115250
1500 lbs.
22 Cubic Feet
27 Cubic Feet
L100x W58 x H33
212 lbs.
18 x 8.50-8
106303
POLARTRAILER.COM
WARRANTY INFORMATION
** REGISTER YOUR PURCHASE ONLINE AT POLARTRAILER.COM **
HD 1500 TA
MODEL 8262

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POLAR TRAILER HD 1500 TA and is the answer not in the manual?

Questions and answers

Summary of Contents for Clam POLAR TRAILER HD 1500 TA

  • Page 1 Clam Outdoors Inc will replace or repair any part found defective within the (5) year time limit. All parts must be returned to Clam Outdoors Inc. Before returning any parts, you must first call or write and acquire a return authorization.
  • Page 2 THE FOLLOWING STATEMENTS ARE SUGGESTIONS AND DO NOT SUPERCEDE OR ELIMINATE ANY TOWING AND SAFETY INSTRUCTIONS LISTED IN ANY OWNERS MANUALS FOR ANY PRODUCT BEING USED FOR THE PURPOSE OF TOWING ANY CLAM OUTDOORS INC. PRODUCTS. ALWAYS REFER TO THE TOWING VEHICLES MANUAL, GUIDELINES OR INSTRUCTIONS.
  • Page 3 PARTS LIST QTY. PART NO. DESCRIPTION 101980 BASE, LRG XTR TRL 102658 DECAL, POLAR, ONE TOUGH TRAILER 102656 DECAL, POLAR, HD1500 102587 ASSY, WHEEL 18 X 8.50-8, 4-PLY TURF 106303 INSTRUCTIONS, TANDEM 1500 TA 104262 REMOVABLE LABEL, HD 1500 TA TRAILER 101953 KIT, TANDEM W/O TIRES (INCLUDES THE FOLLOWING)
  • Page 4 FASTENERS...
  • Page 5 STEP-1 *USING A DROP OF OIL ON ALL NUTS WILL EASE THE ASSEMBLY PROCESS. *IT IS BEST TO USE THE AID OF ANOTHER PERSON DURING ASSEMBLY. 1. INSTALL THESE COMPONENT AND FASTENERS TO AXEL ASSEMBLY (101792)AS SHOWN AND SECURELY TIGHTEN. 101721 MUST MOVE FREELY REFLECTORS TAPE...
  • Page 6 STEP-3 1. ATTACH U-FRAME (101787) TO COMPLETED ASSEMBLY FROM STEP 2 WITH FASTENERS AS SHOWN AND SECURELY TIGHTEN. STEP-4 1. ASSEMBLE THE WHEEL (102587) TO AXLE AS SHOWN AND SECURE WITH PIN (101823) LYNCH PIN (101823) MUST BE LOCKED IN POSITION AS SHOWN BEFORE MOVING TRAILER GREASE SHAFTS...
  • Page 7 STEP-5 1. INSTALL BASE TO FRAME ASSEMBLY WITH ALL FASTENERS AS SHOWN AND SECURELY TIGHTEN FASTENERS. TRAILER OPERATION Disconnecting Towed Attachment Unload trailer. • Stop attachment on level ground. • Stop machine engine. • Lock machine park brake. • Block attachment wheels •...
  • Page 8 DUMP OPERATION KEEP CLEAR OF ROTATING BOX AREA TO AVOID INJURY VISIT OUR WEB-SITE FOR ADDITIONAL ACCESSORIES THAT MAY BE AVAILABLE FOR YOUR TRAILER TOOL RACK PART# 110517 TOOL ORGANIZER PART# 110518...
