Clam POLAR TRAILER HD 1200 Manual

Advertisement

Quick Links

- S P E C IF I C AT I O N S:
Part Number:
Load Capacity:
Load Size:
Dimensions:
Overall Weight:
Tires:
Instruction P/N
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
IMPORTANT-PLEASE READ:
CLAM OUTDOORS INC. warrants to the original retail purchaser its product be free from manufacturers defects for (5)
years from the date of the original purchase. Clam Outdoors Inc will replace or repair any part found defective within the
(5) year time limit. All parts must be returned to Clam Outdoors Inc. Before returning any parts, you must first call or write
and acquire a return authorization. All returns must be returned postage-prepaid and include the original cash register
receipt (date and purchase price).
To submit a warranty claim request, please use one of the following methods:
▪ Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
▪ Clam Corporation
Attn: Customer Service – Warranty Department
12135 Brockton Lane
Rogers, MN 55369
▪ Phone: 763-231-4120
▪ Fax: 763-231-4121
▪ Email:
customerservice@clamcorp.com
▪ Website:
Polartrailer.com
The warranty does not apply to any Polar Trailer which has been subjected to an accident, improper installation,
modification, adjustment, repair, misuse, misapplication, neglect, including but not limited to improper maintenance, or
use of unauthorized parts or attachments.
LIMITATION OF LIABILITY
It is expressly understood that Clam Outdoors Inc. liability for its products, whether due to breach of warranty, negligence,
strict liability, or otherwise, is limited to the repair of the product as stated above. Clam Outdoor Inc. is not liable for any
injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit,
or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or replacement
of Clam Outdoor Inc. products. Clam Outdoor Inc. reserves the right to make alterations or modifications in its products
at any time, which in its opinion, may improve the performance and efficiency of the product. It shall not be obligated to
make such alterations or modifications to products already in service.
115251
1200 lbs.
15 Cubic Feet
L87x W47 x H32
107 lbs.
18 x 8.50-8
106305
WARRANTY INFORMATION
HD 1200
MODEL 8232

Advertisement

loading
Need help?

Need help?

Do you have a question about the POLAR TRAILER HD 1200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clam POLAR TRAILER HD 1200

  • Page 1 Clam Outdoors Inc will replace or repair any part found defective within the (5) year time limit. All parts must be returned to Clam Outdoors Inc. Before returning any parts, you must first call or write and acquire a return authorization.
  • Page 2 THE FOLLOWING STATEMENTS ARE SUGGESTIONS AND DO NOT SUPERCEDE OR ELIMINATE ANY TOWING AND SAFETY INSTRUCTIONS LISTED IN ANY OWNERS MANUALS FOR ANY PRODUCT BEING USED FOR THE PURPOSE OF TOWING ANY CLAM OUTDOORS INC. PRODUCTS. ALWAYS REFER TO THE TOWING VEHICLES MANUAL, GUIDELINES OR INSTRUCTIONS.
  • Page 3: Parts List

    PARTS LIST QTY. PART NO. DESCRIPTION 102587 ASSY, WHEEL 18 X 8.50-8, 4-PLY TURF 101939 BASE, MED XTR TRAILER 102654 DECAL, POLAR, HD1200 102658 DECAL, POLAR, ONE TOUGH TRAILER 106305 INSTRUCTIONS, HD1200 104259 REMOVABLE LABEL, HD 1200 TRAILER 106304 INNERPACK, HD 1200 TRAILER (INCLUDES THE FOLLOWING) 101721 TUBE, 2 X 2 PIVOT...
  • Page 4 FASTENERS...
  • Page 5 STEP-1 *USING A DROP OF OIL ON ALL NUTS WILL EASE THE ASSEMBLY PROCESS. *IT IS BEST TO USE THE AID OF ANOTHER PERSON DURING ASSEMBLY. 1. INSTALL THESE COMPONENT AND FASTENERS TO AXEL ASSEMBLY (101743) AS SHOWN AND SECURELY TIGHTEN. 101721 MUST MOVE FREELY REFLECTORS TAPE...
  • Page 6 STEP-3 1. ATTACH U-FRAME (101755) TO COMPLETED ASSEMBLY FROM STEP 2 WITH FASTENERS AS SHOWN AND SECURELY TIGHTEN. STEP-4 1. ASSEMBLE THE WHEEL (102587) TO AXLE AS SHOWN AND SECURE WITH PIN (101823) LYNCH PIN (101823) MUST BE LOCKED IN POSITION AS SHOWN BEFORE MOVING TRAILER GREASE SHAFTS...
  • Page 7: Trailer Operation

    STEP-5 1. INSTALL BASE TO FRAME ASSEMBLY WITH ALL FASTENERS AS SHOWN AND SECURELY TIGHTEN FASTENERS . TRAILER OPERATION Disconnecting Towed Attachment Unload trailer. • Stop attachment on level ground. • Stop machine engine. • Lock machine park brake. • Block attachment wheels •...
  • Page 8 DUMP OPERATION KEEP CLEAR OF ROTATING BOX AREA TO AVOID INJURY VISIT OUR WEB-SITE FOR ADDITIONAL ACCESSORIES THAT MAY BE AVAILABLE FOR YOUR TRAILER TOOL RACK PART# 110517 TOOL ORGANIZER PART# 110518...
