INSTRUCTIONS MANUAL
Professional mini clamp meter
C-LOGIC 810
SKU: CLOGIC810DC230VCBINT
ENGLISH
The meter is a safe and reliable digital clamp meter with stable performance. lts design is
based on a large scale integrated circuit double integral A/D converter, with full measuring
range of overload protection circuit.
The meter is used for AC current, AC voltage, DC voltage, frequency, duty ratio, resistance,
capacitance, temperature measurement, circuit connection, diode test and non-contact
voltage detection.
SAFETY INFORMATION
The digital AC/DC clamp meter has been designed according to Safety Standard IEC61010-
1 IEC61010-2-032 for electronic measuring instruments and hand-held current clamps. It
conforms to safety standards for double insulation CAT III 600 V and grade 2 for pollution.
USAGE
• Before using this meter, please read carefully this user manual and pay special attention
to "warning" content. Please follow the "warning" instructions.
• To meet the safety requirements, only use probe supplied with the meter. If the probe is
replaced, a new one with the same model or same electric specification should be used.
• Before using it, please check the meter and probe for any damage or abnormal condition.
If an abnormal situation appears (for example: bare probe, enclosure damage, no liquid
crystal display, etc), don't use the meter.
• When the meter is measuring, don't touch the unused input terminal.
• Be careful when measuring voltage greater than 60V DC and 30V AC. Don't allow fingers
to touch or block part of the probe.
• When you can't determine the size range of signal to be tested, please switch the function
measuring range to the maximum position, then gradually select lower ranges until the
correct range is found. Do not exceed the input limit specified in each measuring range.
• Don't measure voltage greater than the upper limit for each range.
• Before changing the function measuring range switch to a different position, set the probe
and the circuit being tested to an open state.
• Before online resistance measurement, turn off all power supplies in circuit and release
all charges on both ends of capacitor.
• Don't expose the meter exposure to strong light, high temperature or moisture (humidity).
• Don't touch bare wires, connectors or circuits being measured.
MAINTENANCE
• Before opening the meter back cover, make sure that the probe is removed from the circuit
to be measured.
• Only wet cloth and a small amount of detergent can be used for cleaning the meter. Don't
use chemical solvents to wipe the meter case.
• If you find any abnormal condition on the meter, stoop using the meter immediately and
have it repaired.
• Do not attempt to repair or perform maintenance on the instrument without being
experienced maintenance personnel in calibration, performance testing, and relevant
maintenance information.
TO CLEAN INPUT JACKS
• Turn off power to the instrument and remove test leads from the input jacks.
• Brush off all dirt from input jacks
• With a clean cotton swab, use a cleaner or lubricant to clean input jacks.
• Use a new swab for each jack to avoid cross contamination.
REPLACING THE BATTERIES
Warning
To avoid electric shock, make sure that the test leads have been clearly move away from
the circuit under measurement before opening the battery cover.
Warning
Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
• If the sign
appears, it means that the batteries should be replaced.
• Loosen the fixing screw of the battery cover and remove it.
• Replace the exhausted batteries with new ones.
• Put the battery cover back and fix it again to its origin form.
Note:
Do not reverse the polarity of the batteries.
REPLACING TEST LEADS
Replace test leads if leads become damaged or worn.
Warning
Use meet EN61010-031 standard, rated CAT.III 600V 10A, or better test leads.
Warning
To avoid electric shock, make sure the probes are disconnected from the measured circuit
before removing the rear cover. Make sure the rear cover is tightly screwed before using
the instrument.
ACCESORIOS
• Test probe
• K type thermocouple
EN
• Short instruction manual
• 1.5V AAA battery
FULL MANUAL DOWNLOAD
MANUFACTURER:
MGL International
APAC: MGL GLOBAL SOLUTIONS LTD
info.apac@mgl-intl.com
Flat 4-1, 4/F, No. 35, Section 3 Minquan
East Road. Taipei, Taiwan.
Tel: +886 2-2508-0877
EMEA: MGL EUMAN S.L.
info.emea@mgl-intl.com
Parque Empresarial Argame, 33163
Morcín. Asturias, Spain.
Tel: +34 985-08-18-70
1 pair
1 pc
1 pc
3 pcs
You can download the complete
manual at the URL
https://clogic-intl.com/clogic-810
AMERICAS: MGL AMERICA, LLC.
info.na@mgl-intl.com
US East Coast: 2810 Coliseum Centre
Drive, Ste. 100. Charlotte, North Carolina,
28217 USA
Tel: +1 833 533-5899
US West Coast: 760 Challenger Street.
Brea, California 92821 USA
Tel: +1 310-728-6220
www.mgl-intl.com
