OWPIR360 / OWPIR360BK
Specifications
Detection Range:
Detection Distance:
Time-Delay / 'Switch On' Duration:
Installing Height:
Power Consumption:
Power Sourcing:
Power Frequency:
Working Temperature:
Ambient Light:
Rated Load:
Working Humidity:
Detection Motion Speed:
Infrared Motion Sensor
Indoor 360°
Manual
360°
3m max (<24°C)
Min. 10sec±3sec
Max. 7min±2min
2.2m - 4m
<0.9W
220V/AC-240V/AC
50/60Hz
-20 > +40°C
<5-2000LUX (Adjustable)
2000W (incandescent lamp)
1000W (energy-saving lamp)
<93%RH
0.6 - 1.5m/s
Advertisement
Related Manuals for Trader ARCTIC OWL OWPIR360
Summary of Contents for Trader ARCTIC OWL OWPIR360
- Page 1 OWPIR360 / OWPIR360BK Infrared Motion Sensor Indoor 360° Manual Specifications Detection Range: 360° Detection Distance: 3m max (<24°C) Time-Delay / ‘Switch On’ Duration: Min. 10sec±3sec Max. 7min±2min Installing Height: 2.2m - 4m Power Consumption: <0.9W Power Sourcing: 220V/AC-240V/AC Power Frequency: 50/60Hz Working Temperature: -20 >...
- Page 2 Welcome to the OWPIR360 indoor 360 degree infrared motion sensor! This product features a high level of sensitivity, excellent performance and a practical size for convenience and safe, easy installation. It utilises the infrared energy from humans as the control-signal source and starts the load when one enters the detection field. It can identify day and night automatically and is extremely easy to install.
- Page 3 INSTALLATION: • Product must be installed by a licensed electrician. • Turn off the power and isolate the mains. • Mark out appropriate position in the ceiling (ensure it is at a suitable height) and drill a 63mm hole. Pull through the wiring to be connected, ensuring there are no obstructions in the ceiling space.
- Page 4 • Turn LUX knob anticlockwise to the minimum ‘ ’ (night/darkness). The sensor should not work after load switches off, provided the lux level in the room is higher than the level set for the minimum. Note: when testing in daylight, turn LUX knob to ‘ ’...
