Page 4
Section Components Part quantities based on bench model SFB110 SFB160 SFB210 SFB260 SFB310 SFB360 SFB410 SFB460 SFB510 Part Description Quantity Quantity Quantity Quantity Quantity Quantity Quantity Quantity Quantity 1 x 1320mm / 2 x 890mm / 2 x 1140mm / 2 x 1390mm / 3 x 1080mm / 3 x 1247mm /...
Page 9
Section Prepare the brackets Insert a grub screw backwards into the bracket and screw into place until only 2 threads are showing. Insert two grub screws in from the flat face of the bracket 2 turns only. IMPORTANT: Make the brackets for your bench using all J and K parts supplied.
Page 10
Section How to fit the brackets Slide a corner bracket into position and place the spacer over it. Hold the spacer so it is flush with the top of the leg. Use a straight edge to ensure that the spacer is flush with the end of the leg. Initially tighten gently with the long end of the Allen key.
Page 11
Section Build the legs Add the brackets (page 9) to the leg (part D) Unit Type Corner Leg Middle Leg 1 Middle Leg 2 SFB110 SFB160 / SFB210 / SFB260 SFB310 / SFB360 / SFB410 SFB460 / SFB510 The lower brackets can be fixed at any point along the leg as long as they are all the same distance from the upper brackets.
Section Attach the feet Fix an adjustable foot into any of the four grooves at the bottom of each leg, make sure the aluminium block is flush with the bottom of the leg. Fix the screw very tightly.
Page 13
Section Build the leg frames (See page 14-16 for detailed instructions) Unit Number of left hand leg frames Number of intermediate leg frames Number of right hand leg frames SFB110 SFB160 / SFB210 / SFB260 SFB310 / SFB360 / SFB410 SFB460 / SFB510...
Page 14
Section How to build a left hand leg frame Take a pair of corner legs (page 11) and lay one on the floor. Place a beam2 (part C - page 4) on each bracket. Do not tighten the screws yet. Place the second corner leg over the other end of the beams.
Page 15
Section How to build an intermediate hand leg frame Take a middle leg 1 (page 11) and lay one on the floor. Place a beam2 (part C - page 4) on each bracket. Do not tighten the screws yet. Place middle leg 2 over the other end of the beams. Press down and ensure all the beam ends are flush against the leg Tighten the screws using the 4mm Allen key supplied.
Page 16
Section How to build a right hand leg frame Take a pair of corner legs (page 11) and lay one on the floor. Place a beam2 (part C - page 4) on each bracket. Do not tighten the screws yet. Place the second corner leg over the other end of the beams.
Page 17
Section Assemble the bench upside down (1/4) The bench is assembled up side down then turned over when complete Place a bench edge (part A - page 4), flat side down, on the floor together with the left support plate (Part G)and left hand leg frame. Slide the parts together.
Page 18
Section Assemble the bench upside down (2/4) IMPORTANT: If constructing a SFB110, substitute intermediate leg frame for right hand leg frame. Place an intermediate leg frame onto an intermediate support plate (Part I) and slide so the bracket just enters 1cm into the bench edge (Part A).
Page 19
Section Assemble the bench upside down (3/4) Tighten the remaining loose screws in this section firmly (as shown on page 10). Continue to build your bench in this way until you reach the end.
Page 20
Section Assemble the bench upside down (4/4) To complete your bench assembly, place a right hand leg frame onto an right support plate (Part H) and slide so the bracket just enters 1cm into the bench edge (Part A). Align the other three beams and push the frame into position. Tighten all screws fully, checking that there are no gaps.
Page 21
Section Flip the bench over once assembled Turn the bench over by rolling onto its front face and then onto its feet. Place in its final working position IMPORTANT: Before the cutter is mounted it is essential the bench edge extrusions are all flat to within 3mm.
Page 23
Section Prepare the brackets Insert a grub screw backwards into the bracket and screw into place until only 2 threads are showing. Insert two grub screws in from the flat face of the bracket 2 turns only. IMPORTANT: Make the brackets for your bench using all J and K parts supplied.
Page 24
Section How to fit the brackets Slide a corner bracket into position and place the spacer over it. Hold the spacer so it is flush with the top of the leg. Use a straight edge to ensure that the spacer is flush with the end of the leg. Initially tighten gently with the long end of the Allen key.
Page 25
Section Attach the feet Fix an adjustable foot into any of the four grooves at the bottom of each leg, make sure the aluminium block is flush with the bottom of the leg. Fix the screw very tightly.
Page 26
Section Build the legs Add the brackets (page 23) to the leg (part D) Unit Type Corner leg 1 Corner leg 2 Corner leg 3 Middle leg 1 Middle leg 2 SFB110 SFB160 / SFB210 / SFB260 SFB310 / SFB360 / SFB410 SFB460 / SFB510 The lower brackets can be fixed at any point along the leg as long as they are all the same distance from the upper brackets.
Page 27
Section Prepare the leg frames (See page 28-34 for detailed instructions) Unit Type Number of left hand leg frames Number of intermediate leg frames Number of right hand leg frames SFB110 SFB160 / SFB210 / SFB260 SFB310 / SFB360 / SFB410 SFB460 / SF510...
Page 28
Section How to build a left hand leg frame Take corner leg 1 (page 26) and lay one on the floor. Place a beam2 (part C - page 4) on each bracket. Do not tighten the screws yet. Place corner leg 2 over the other end of the beams. Press down and ensure all the beam ends are flush against the leg Tighten the screws using the 4mm Allen key supplied.
Page 29
Section How to build intermediate leg frame Take middle leg 1 (page 26) and lay one on the floor. Place a beam2 (part C - page 4) on each bracket. Do not tighten the screws yet. Place middle leg 2 over the other end of the beams. Press down and ensure all the beam ends are flush against the leg Tighten the screws using the 4mm Allen key supplied.
Page 30
Section How to build right hand leg frame Take corner leg 1 (page 26) and lay one on the floor. Place a beam2 (part C - page 4) on each bracket. Do not tighten the screws yet. Place corner leg 3 over the other end of the beams. Press down and ensure all the beam ends are flush against the leg Tighten the screws using the 4mm Allen key supplied.
Page 31
Section Make the cantilever corners Cantilever corner Cantilever middle Unit Type Cantilever corner Cantilever middle SFB110 SFB160 / SFB210 / SFB260 SFB310 / SFB360 / SFB410 SFB460 / SFB510 Assemble cantilever joiners and corner brackets as shown. Ensure screws are fully tightened (see page 24). If available hold the cantilever joiner in a vice whilst tightening.
Page 32
Section Make the cantilever joints (1/3) Attach the cantilever corners and cantilever middle to the cantilever arm (part E - page 4). Firmly tighten the screws.
Page 33
Section Make the cantilever joints (2/3) Fix the cantilever corner assembly to the left and right hand leg frames. Ensure the brackets on the cantilever corner assembly are pointing in the same direction as the brackets on the frame. Fully tighten all screws (see page 24).
Page 34
Section Make the cantilever joints (3/3) Fix the cantilever middle assembly to the intermediate leg frames. Ensure the brackets on the cantilever corner assembly are pointing in the same direction as the brackets on the frame. Fully tighten all screws (see page 24).
Page 35
Section Assemble the bench upside down (1/4) The bench is assembled up side down then turned over when complete Place a bench edge (part A - page 4), flat side down, on the floor together with the left support plate (Part G) and left hand leg frame. Slide the parts together.
Page 36
Section Assemble the bench upside down (2/4) IMPORTANT: If constructing a SFB110, substitute intermediate leg frame for right hand leg frame. Place an intermediate leg frame onto an intermediate support plate (part I) and slide so the bracket just enters 1cm into the bench edge (part A).
Page 37
Section Assemble the bench upside down (3/4) Tighten the remaining loose screws in this section firmly (as shown on page 24). Continue to build your bench in this way until you reach the end.
Page 38
Section Assemble the bench upside down (4/4) To complete your bench assembly, place a right hand leg frame onto an right support plate (part H) and slide so the bracket just enters 1cm into the bench edge (part A). Align the other three beams and push the frame into position. Tighten all screws fully, checking that there are no gaps.
Page 39
Section Flip the bench over once assembled Turn the bench over by rolling onto its front face and then onto its feet. Place in its final working position IMPORTANT: Before the cutter is mounted it is essential the bench edge extrusions are all flat to within 3mm.
Page 41
Section Levelling the bench (1/5) 13mm Adjust foot by twisting the base so it is about halfway extended. Lock in place using the 13mm spanner.
Page 42
Section Levelling the bench (2/5) Place the spirit level in highlighted position and adjust highlighted foot to bring it to level. IMPORTANT: Do not tighten the nut on the foot yet. This action is to be carried out on page 45.
Page 43
Section Levelling the bench (3/5) Place the spirit level in highlighted position and adjust highlighted foot to bring it to level. IMPORTANT: Do not tighten the nut on the foot yet. This action is to be carried out on page 45.
Page 44
Section Levelling the bench (4/5) Place the spirit level in highlighted position and adjust highlighted foot to bring it to level. IMPORTANT: Do not tighten the nut on the foot yet. This action is to be carried out on page 45.
Page 45
Section Levelling the bench (5/5) 13mm Repeat steps 3 & 4 from pages 43-44 until you reach the end of the bench. Once complete and your bench is levelled, lock all feet in position using the 13mm spanner provided.
Section Preparing the worktop Worktop width = 1220mm (8’) or 1525mm (10’) dependent upon cantilever Unit Type 3050mm (10’) long boards 2440mm (8’) boards SFB110 1440mm (56 5/8”) 1440mm (56 5/8”) 1940mm (76 3/8”) 1940mm (76 3/8”) SFB160 SFB210 2440mm (96”) 2440mm (96”) 1.2m (4’) 2940mm (115 5/8”)
Page 47
Section Fixing the worktop IMPORTANT: Fit the SmartFold cutter before fitting the worktop. Evenly space the worktop fixing brackets and screws to fasten the worktop down to the bench framework and bench edge extrusion as shown.
Section Maintenance Regularly remove offcuts and clean with a vacuum cleaner. Moisten a cloth in diluted detergent to remove any marks. IMPORTANT: Do not use harsh chemicals or solvents. If the bench is not rigid ensure all grub screws are fully tightened.
