ANNA
Kitchen faucet
User Manual
Robinet de cuisine
Guide de l'utilisateur
NSF
®
DO NOT RETURN THIS PRODUCT TO STORE, CONTACT US. We're there if you need help
NE RETOURNEZ PAS CE PRODUIT AU MAGASIN, CONTACTEZ-NOUS.
1 844 666-0155 • question@dimex360.com
1 844 666-0155
Nous sommes à vos côtés si vous avez besoin d'aide
Store/Magasin
1 2
3 4
RC1057BL
2020-04
Advertisement
Related Manuals for Akuaplus ANNA RC1057BL
Summary of Contents for Akuaplus ANNA RC1057BL
- Page 1 ANNA Store/Magasin Kitchen faucet User Manual 1 844 666-0155 Robinet de cuisine Guide de l’utilisateur RC1057BL ® DO NOT RETURN THIS PRODUCT TO STORE, CONTACT US. We’re there if you need help NE RETOURNEZ PAS CE PRODUIT AU MAGASIN, CONTACTEZ-NOUS. Nous sommes à...
- Page 2 We recommend that you hire a professional plumber to install and repair this product. Refer to the regulations stipulated in the Canadian Plumbing Code and inquire about your municipality’s requirements before proceeding to the installation. The Canadian Plumbing Code requires the installation of a water-hammer arrester to dampen water hammer in pipes. ALLOW PROPER OPENING FOR EASY ACCESS TO CONNECTIONS OR OTHER PLUMBING DEVICES FOR MAINTENANCE OR REPAIR.
- Page 3 Parts list-Liste de pièces Description Handle Poignée Allen screw Vis Allen Finishing cap Capuchon de finition Trim cap Garniture d’écrou Cartridge locknut Écrou de la cartouche Ceramic cartridge Cartouche de céramique Faucet body Corps du robinet Flexible hose Boyau flexible Spray head Douchette Flange...
- Page 4 8 3/4" 4 5/16" (222.5mm) (109mm) CLOSED FERMÉ OPEN OUVERT HOT WATER COLD WATER EAU CHAUDE EAU FROIDE Ø1 3/4" (Ø45mm) Ø2 1/2" M32x1.5 (Ø63mm) 2XG1/2 CLOSED FERMÉ OPEN OUVERT HOT WATER COLD WATER EAU CHAUDE EAU FROIDE Be careful not to damage or twist the hoses Assurez-vous de ne pas endommager ni tordre les boyaux...
- Page 5 Ø 1 3/8” (35 mm) 4” 100 mm WARNING/ AVERTISSEMENT Before connecting to your water supply, flush your piping to make sure it is free of sediment, flux, weld residue, deposits, debris or any other impurities that could damage your new faucet. Failure to rid your piping of the contaminants mentioned above will void your warranty and may result in premature failure, as well as property damage.
-
Page 6: Troubleshooting Guide
LIMITED WARRANTY Les produits akuaplus® ont été conçus pour répondre à des normes de haute qualité très strictes et sont assortis d’une garantie akuaplus® products have been designed to meet high-quality standards and come with a limited lifetime warranty against à...
