ELENA
Bathtub faucet
User Manual
Robinet pour baignoire
Guide de l'utilisateur
DO NOT RETURN THIS PRODUCT TO STORE, CONTACT US. We're there if you need help
NE RETOURNEZ PAS CE PRODUIT AU MAGASIN, CONTACTEZ-NOUS.
Nous sommes à vos côtés si vous avez besoin d'aide
1 844 666-0155 • question@dimex360.com
1 2
3 4
1 844 666-0155
RB 6115BL
Store/Magasin
RB 6115CP
2020-04
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Akuaplus ELENA RB 6115CP
Summary of Contents for Akuaplus ELENA RB 6115CP
- Page 1 ELENA Bathtub faucet User Manual Robinet pour baignoire Store/Magasin Guide de l’utilisateur RB 6115CP 1 844 666-0155 RB 6115BL DO NOT RETURN THIS PRODUCT TO STORE, CONTACT US. We’re there if you need help NE RETOURNEZ PAS CE PRODUIT AU MAGASIN, CONTACTEZ-NOUS. Nous sommes à...
- Page 2 We recommend that you hire a professional plumber to install and repair this product. Refer to the regulations stipulated in the Canadian Plumbing Code and inquire about your municipality’s requirements before proceeding to the installation. The Canadian Plumbing Code requires the installation of a water-hammer arrester to dampen water hammer in pipes. ALLOW PROPER OPENING FOR EASY ACCESS TO CONNECTIONS OR OTHER PLUMBING DEVICES FOR MAINTENANCE OR REPAIR.
- Page 3 Parts list-Liste de pièces #4-5-6 9-10-11-13...
- Page 4 N°/No. Description N°/No. Description 1 Hot water handle Poignée de l’eau chaude 21 Diverter ceramic cartridge Cartouche de céramique de l’inverseur 2 Allen screw Vis Allen 22 Aerator Aérateur 3 Finishing cap Capuchon de finition 23 Ceramic cartridge locknut Contre-écrou pour la cartouche de céramique 4 Nylon ring Anneau de nylon 24 Deviator handle adapter...
- Page 5 Ø 1 3/8” (35 mm) 5” 127 mm 5” 127 mm 5” 127 mm...
- Page 6 WARNING/ AVERTISSEMENT Before connecting to your water supply, flush your piping to make sure it is free of sediment, flux, weld residue, deposits, debris or any other impurities that could damage your new faucet. Failure to rid your piping of the contaminants mentioned above will void your warranty and may result in premature failure, as well as property damage.
- Page 7 Hot water Faucet Cold water Handshower Eau chaude Robinet Eau chaude Douchette CLOSED CLOSED FERMÉ FERMÉ 90° 90° OPEN OPEN OUVERT OUVERT Be careful not to damage or twist the hoses Assurez-vous de ne pas endommager ni tordre les boyaux...
-
Page 8: Troubleshooting Guide
LIMITED WARRANTY Les produits akuaplus® ont été conçus pour répondre à des normes de haute qualité très strictes et sont assortis d’une garantie akuaplus® products have been designed to meet high-quality standards and come with a limited lifetime warranty against à...
