Summary of Contents for Greyp G6
- Page 1 READ BEFORE YOUR FIRST RIDE...
- Page 3 BIKE USER MANUAL ENGLISH...
-
Page 4: Table Of Contents
Contents INTRODUCTION Front suspension Shock pressure chart Greyp Bikes Disclaimer Recommended tire pressure General warning Assembling parts supplied General information unassembled Safety information General information BATTERY AND CHARGER about assembly Battery technical data GENERAL NOTES Important battery information ABOUT RIDING... - Page 5 Shock Power off Lubrication Walk assist mode Lights on/off WARRANTY Joystick General Assist level up/down Battery Info and Pair a bike screen Frame Manual software update Motor Battery pack mount/dismount Electronics Brakes BIKE MAINTENANCE & RANGE Suspension Maintenance Range Drivetrain Shifting recommendations How to file a claim Recommended tightening...
-
Page 7: Introduction
Introduction This user instruction manual is developed for your Greyp G6 only. It contains important safety, performance and technical information, which you should read before your first ride and keep for reference. You should also read the entire User Manual, because it contains additional important general information and instructions that you should follow. -
Page 8: General Information
This User Manual is not intended as a service and repair manual. The Greyp G6 is classified as a pedelec. The G6 is a vehicle where the rider’s pedalling is assisted by an electric motor with 5 assist and torque levels, which gives you a range of power assistance. -
Page 9: Safety Information
Please make sure you learn how to operate your Greyp bike in a safe and responsible way. The Greyp G6 is intended to transport only one person at a time. If you allow somebody else to use your Greyp bike, please provide them with this User Manual. -
Page 10: General Information About Assembly
WARNING — Do not alter or modify any parts of your Greyp bike. Do not install incompatible components or hardware. The maximum permissible total weight (vehicle + driver + luggage) of Greyp G6 is 150kg [330.7 lb]. THE PERMISSIBLE TOTAL... -
Page 11: General Notes About Riding
General notes about riding The G6 motor provides pedal assistance while you are pedalling, and the the bike is in motion. The amount of pedal assistance will be higher or lower depending on the amount of force applied to the pedals. If you stop pedalling, the motor will stop providing any assistance. The Greyp G6 can also be ridden as a normal bicycle without motor assistance by switching the vehicle to the OFF mode. -
Page 12: Pre-Ride Inspection
Riding tips for children Greyp bikes are only designed and tested for use by one person at a time. Greyp bikes are not intended for children under 16 years. Do not allow children under 16 years old to drive a Greyp bike. -
Page 13: Seat Post - Basics
You can raise and lower your saddle to any desired position within the seat post’s travel. Brakes – basics WARNING — Braking devices on Greyp bikes are a high-performance product, offering a stopping power greater than normal brakes. As a result, less effort is required to lock up the wheel when braking. -
Page 14: Suspension - Basics
Set the spring sag before making any other tuning adjustments. G6.1 & G6.1(US) are using Rock Shox Monarch RT1 216x63 and G6.2, G6.2O, G6.2O(US), G6.2(US), G6.3 & G6.3(US) are using Rock Shox Monarch RT3 216x63. -
Page 15: Adjusting Rebound
To increase the rebound speed, rotate counter-clockwise. To decrease the rebound speed, rotate clockwise. Adjusting the threshold (only for models G6.2&G6.3) The threshold, or pedal setting prevents the shock from compressing until moderate impact or downward force occurs. Use the threshold setting to increase pedalling efficiency on flat, rolling, and smoother terrain. -
Page 16: Adjusting Lockout
Check values on front fork. If values on front fork and in this manual are different use values given on front fork. FRONT FORK – AIR SPRING PRESSURE G6.1 & G6.1(US) ROCK SHOX YARI RC 27.5” BOOST DEBONAIR, 150MM [5.9”] TRAVEL, 15MM [0.6”] AXLE <55 kg 55–63 kg... -
Page 17: Recommended Tire Pressure
G6.2 , G6.2O & G6.2(US) ROCK SHOX LYRIK SELECT+ 27.5” BOOST DEBONAIR, 150MM [5.9”] TRAVEL, 15MM [0.6”] AXLE <55 kg 55–63 kg 63–72 kg 72-81 kg 81-90 kg 90-99 kg >99 kg MAX PSI <65 psi 65-75 psi 75-85 psi... -
Page 18: Assembling Parts Supplied Unassembled
Assembling parts supplied unassembled CAUTION — Do not use the chainguide and chainguard at the same time. Chainguide – use only with positive foot-retention devices on the pedals Chainguard GENERAL NOTES ABOUT RIDING... - Page 19 CHAINGUIDE OR CHAINGUARD MOUNT NAME/DESCRIPTION TORQUE, Nm [lbf ft] CHAINGUIDE ALUMINUM PART CHAINGUIDE PLASTIC PART DIN 7991 M5X18 4 [3] DIN 7991 M5X12 4 [3] CHAINGUARD ISO 7045 M4X8 4 [3] REFLECTORS NAME/DESCRIPTION FRONT REFLECTOR 313/5K REAR REFLECTOR 314/1 REAR REFLECTOR 313/1ZB SPOKE REFLECTOR 309 (M);...
-
Page 21: Battery And Charger
Greyp bike. Only use the Greyp battery with the corresponding Greyp bike. Do not use the Greyp battery with other products or any other battery with the Greyp bike, even if it fits. -
Page 22: Important Battery Information
If your battery or charger exhibits any signs of damage, do not use it and immediately bring it to your authorized Greyp Bikes retailer for inspection. BATTERY AND CHARGER... - Page 23 Greyp retailer . In case of a foreign object please remove it before you connect the battery to your Greyp bike. Keep the battery away from metal objects as they can cause a short-circuit.
-
Page 24: Charging Process
ON BATTERY Charging socket ON BIKE Charging socket Plug the charger plug into an appropriate AC outlet (depending on the charger) using the appropriate plug/adapter for the country’s standard. Uncover the charging socket on the bike, then connect the charger to the charging socket on the bike. - Page 25 CAUTION: If the red LED light is flashing during the charging process, a charging error has occurred. In that case, immediately remove the charger from the socket, discontinue the use of the motor support and contact an authorized Greyp retailer. CHARGER 1...
-
Page 26: Battery Life
Strongly reduced operating time after charging can be a sign that the battery is reaching the end of its useful life and must be replaced. Provided your Greyp bike has been used properly, approximately 80% of the battery’s original capacity should remain after 500 charging cycles or two years. -
Page 27: System Functions
System functions Bike parts BIKE PARTS NAME/DESCRIPTION DISPLAY UNIT (CIM) CHAINSTAY CONTROL UNIT (CBC) PUSHPLATE REAR CAMERA (BUTS) RATIO LEVER BATTERY FRAME SEATSTAY MOTOR SYSTEM FUNCTIONS... -
Page 28: Control Unit Functions
Control unit functions LEGEND NAME/DESCRIPTION ICON FUNCTION TYPE POWER ON/OFF AND STAND BY LONG/SHORT PRESS WALK ASSIST WALK ASSIST PRESS & HOLD TURN ON/OFF FRONT AND LIGHT SHORT PRESS REAR SIGNAL LIGHTS RETRO VIDEO WORKS ONLY WITH MOBILE APP SWITCH BETWEEN DISPLAY SHORT PRESS IN ALL JOYSTICK FUNCTIONS... -
Page 29: Display Unit Information
Display unit information CIM DISPLAY INTERFACE NAME/DESCRIPTION SPEED BATTERY CHARGE / REMAINING DISTANCE RIDE STATISTICS TIME ASSISTANCE LEVEL CADENCE SYSTEM FUNCTIONS... -
Page 30: Power On
Power on To turn on the bike, long press the power button Long press Stand by mode on To put your bike in standby mode, short press the power button Short press Stand by mode off To wake up the bike from stand-by mode, press any button on the control unit or move the bike Press any button SYSTEM FUNCTIONS... -
Page 31: Power Off
Power off To turn off the bike, long press the power button Long press Walk assist mode To activate the walk assistance mode, press and hold walk assist button Press and hold Lights on/off To turn the lights on or off, short press the light button Short press SYSTEM FUNCTIONS... -
Page 32: Joystick
Joystick To switch between different information on the display unit, move the joystick up or down » TRIP » ODOMETER » AVERAGE SPEED » TRIP TIME Move in the up or down direction Assist level up/down To change the assistance level, short press the plus or minus assist level button Short press to change by one level SYSTEM FUNCTIONS... -
Page 33: Info And Pair A Bike Screen
Info and Pair a bike screen To acess the Info screen, use a combination of buttons. Press and hold Short press Move the joystick up or down to scroll inside the screen or move the joystick left/ right to switch between screens Move up/down or left/right Manual Software Update To start the software update use a combination of buttons. -
Page 34: Battery Pack Mount/Dismount
click pull BATTERY PACK MOUNT/DISMOUNT NAME/DESCRIPTION BATTERY BATTERY LOCK SYSTEM FUNCTIONS... -
Page 35: Bike Maintenance & Range
Additionally, the Greyp G6 uses a power-assisted drive system, which means more distance at different rates, depending on the component. The drivetrain and brake components are especially subject to wear. - Page 36 Greyp retailer, which means it should be cleaned and lubricated. Regularly clean and lubricate the drivetrain according to the drivetrain manufacturer’s instructions. Do not apply lubricant on the disc brake rotors. Lubricant on brake surfaces can cause decreased braking function, and increase the possibility of an accident or injury.
-
Page 37: Range
Appropriate spares: TYRES BRAKES ROTORS INNER TUBE FORMULA SIX BOLT SCHWALBE NOBBY NIC FORMULA G6.1 203mm [8″] FRONT CURA PERFORMANCE LINE, 70-584 180mm [7″] REAR FORMULA SIX BOLT PRESTA 27.5 SCHWALBE MAGIC MARY FORMULA G6.2 PLUS X 2.8/3.0 203mm [8″] FRONT... -
Page 38: Shifting Recommendations
Shifting recommendations For better range, Greyp advises to shifting according to the speed. For low speeds, low gearing is best. The higher the speed, the higher the gear that can be chosen. For a smooth support and optimum range, it is best to release the pedal pressure while shifting gears. - Page 39 HANDLEBAR PARTS / STEM / TORQUE SPECIFICATION NAME / DESCRIPTION TORQUE, Nm [lbf ft] GRIPS / HANDLEBAR G6.1 & G6.2 - 2[1.5], G6.3 - 3 [2.2] SHIFTER / HANDLEBAR 4 [3] BRAKE LEVERS / HANDLEBAR 4 [3] CBC / HANDLEBAR 1,2 [0.9]...
- Page 40 BIKE COMPONENTS TORQUE SPECIFICATION NAME / DESCRIPTION TORQUE, Nm [lbf ft] PUSHPLATE / FRAME 4 [3] SPEED SENSOR / CHAINSTAY 2 [1.5] SPEED SENSOR / SPEED SENSOR HOLDER 2 [1.5] REAR BRAKE / CHAINSTAY 6 [4.4] DERAILLEUR / DROPOUT 12 [8.9] CHAINWHEEL / MOTOR 30 [22.1] CRANKARMS / MOTOR...
-
Page 41: Cleaning The Bike
Cleaning the bike Most cleaning can be done with soap, water, sponges and brushes. » Avoid using high-pressure sprayers because water can penetrate through seals ; » Avoid using corrosive soaps and strong solvents – always use cleaning products intended for an electric bicycle ; »... -
Page 42: Lubrication
Performing the right maintenance on your RockShox products not only ensures years of worry-free riding, but will also keep performance optimal and enhance your experience on the bike. Each service interval indicates the maximum number of riding hours designated for each type of recommended maintenance. -
Page 43: Warranty
If Greyp is unable to provide a replacement and if a repair is not practical or cannot be made in a timely fashion, Greyp may elect to refund the purchase price in exchange for the return of the product. -
Page 44: Battery
Greyp at their own cost. Greyp will reimburse the customer for its own labour & replacement parts in the first 24 months of bike ownership. Greyp will pay to return the battery to the customer. Greyp retains the right to repair or replace WARRANTY... -
Page 45: Frame
If a frame is found to be defective, EU shipping, parts and labour to replace the frame is paid by Greyp for the first 24 months from the original date of manufacture. The cost of repairing/replacing custom paint is never included in frame warranty at any time. -
Page 46: Drivetrain
» delivery of the product or the defective part, postage prepaid and carefully packed and insured, to Greyp Bikes d.o.o. or an agreed dealer The product or defective part has to be delivered to Greyp Bikes d.o.o. or an agreed dealer postage prepaid and carefully packed and insured. When the warranty service is completed, any repaired or replacement product or part will be returned to the customer postage prepaid. -
Page 47: Disposal
Ask your authorized Greyp retailer for information on how to dispose a battery or charger and any applicable take-back programs. -
Page 49: Ec - Declaration Of Conformity
(2014/30/EC), Radio Equipment Directive (2014/53/EU), Low Voltage Directive (LVD) (2014/35/ EU), ROHS 2 Directive (2011/65/EU) The following harmonizing standard was applied to the G6.1 and G6.2: EN 15194:2017 Bicycles – electrically power assisted cycles – EPAC bicycles. The following standard was used for G6.1, G6.2, G6.2O and G6.3: EN ISO 4210, EN ISO 12100:2010 EN 62368-1:2014/AC Feb.:2015/A11:2017/ AC Mar.:2017... - Page 51 Since we are constantly working on improving our user experience, you can expect frequent mobile app updates FIND THE LATEST VERSION OF THE GREYP APP MANUAL ON OUR WEBSITE The Greyp mobile application is available on Google PlayStore and AppStore...
- Page 52 Greyp Bikes d.o.o. Ljubljanska 7 10431 Sveta Nedelja Croatia Tel: +385 1 409 3377 Fax: +385 1 333 6698 info@greyp.com...
