Backhoe 260 with remote control 2020 1
Operator's Manual for Attachment
Backhoe 260 with remote control
For 800 series loaders
Product number:
A440295
www.avanttecno.com
A442765 2020 1 EN 2020-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 260 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVANT 260

Summary of Contents for AVANT 260

  • Page 1 English Backhoe 260 with remote control 2020 1 Operator's Manual for Attachment Backhoe 260 with remote control For 800 series loaders Product number: A440295 www.avanttecno.com A442765 2020 1 EN 2020-...
  • Page 2 Backhoe 260 with remote control 2020 1...

  • Page 3: Table Of Contents

    Backhoe 260 with remote control 2020 1 CONTENTS 1. FOREWORD ............................5 Warning symbols used in this manual ........................... 6 2. DESIGNED PURPOSE OF USE......................7 3. SAFETY INSTRUCTIONS FOR USING THE ATTACHMENT ............9 Personal protective equipment ..........................12 Safe shutdown procedure ............................
  • Page 4 7. MAINTENANCE AND SERVICE ....................... 43 Inspection of hydraulic components ........................43 Cleaning the attachment ............................44 Inspection of metal structures ..........................44 Lubrication ................................... 45 Radio remote control maintenance ........................46 7.5.1 Battery maintenance ............................46 8. WARRANTY TERMS .......................... 48...

  • Page 5: Foreword

    If you sell or transfer the equipment, be sure to hand over this manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant dealer or from the manufacturer.

  • Page 6: Warning Symbols Used In This Manual

    6 (50) Warning symbols used in this manual The following warning symbols are used throughout this manual. They indicate factors that must be taken into account to reduce the risk of personal injury or damage to property: WARNING SAFETY ALERT SYMBOL This symbol means: “Warning, be alert! Your safety is involved!”...

  • Page 7: Designed Purpose Of Use

    The Backhoe 260 with remote control is not designed for any other use than what is specified in this manual and must not be used for any other purposes than what is intended for. The Backhoe 260 with remote control is a product of its own.
  • Page 8 8 (50) Table 1 - Backhoe 260 with remote control - Compatibility with Avant loaders Model 313S 525LPG 320S 860i 225LPG 755i 760i A440295 • It is recommended to use the attachment only with loaders marked with • in Table 1. When using with models marked with (•), full performance may not be achieved.

  • Page 9: Safety Instructions For Using The Attachment

    9 (50) 3. Safety instructions for using the attachment Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly powerful and improper or careless use or maintenance may cause serious personal injury or property damage.
  • Page 10 10 (50)  Tipping over hazard - Note that the excavation or trench may suddenly cave in. Exercise extreme caution when driving near ditches or embankments, and avoid driving along a ditch or trench, as the machine could suddenly tip over if an edge caves in.
  • Page 11 11 (50)  The stability of the loader may change when leaving the driver’s seat, leading to tipping over of the machine. Always remember that the boom may lower unexpectedly due to loss of stability, mechanical fault, or if another person operates the controls of the loader, leading to crushing hazard.

  • Page 12: Personal Protective Equipment

    12 (50) 3.1 Personal protective equipment Remember to wear proper personal protective equipment:  The noise level at the driver's seat may exceed 85 dB(A) depending on loader model and operating cycle. Extended exposure to loud noise can cause hearing impairment. Wear hearing protection while working with the loader. ...

  • Page 13: Safe Shutdown Procedure

    13 (50) 3.2 Safe shutdown procedure Safe stopping of the attachment, before going near the attachment: Always stop the attachment following safe stopping procedure before leaving the driver's seat. Safe stopping procedure prevents all unintentional movements of the attachment. Note that the loader boom can move down even if the engine of the loader is turned off.

  • Page 14: Technical Specifications

    14 (50) 4. Technical specifications Table 2 - Backhoe 260 with remote control - Specifications Product number: A440295 Maximum reach: 260 cm 490 kg Mass: (with 400 mm bucket) Standard bucket: 400 mm, 3 teeth Bucket: Bucket options: See page 37...

  • Page 15: Information About Radio Remote Control

    This model of the backhoe must not be exported to or operated outside of EU and EFTA area. Other Backhoe models may be available for different market areas, contact your Avant dealer for more information. The operating frequency of the radio remote control system is regulated by local or market area specific laws and standards.
  • Page 16 A441344 Attachment identification plate Table 4 - Backhoe 260 with remote control - Main components Frame with Avant quick coupling brackets Support arm (2 pcs) RC valve control unit (Receiver) with light beacon...

  • Page 17: Attaching The Attachment

    5. Attaching the attachment The backhoe 260 is delivered with a 400 mm bucket fitted and it is ready for use as delivered. When coupling the backhoe onto the loader, in addition to the quick coupling and connecting the hydraulic fittings, the support arms must also be mounted.
  • Page 18 18 (50) Step 4:  After the locking pins are positively locked, fit the support arms (1) as shown in the figure below. Align the support arms (1) with the holes on the loader boom (2).  Lock the backhoe on the loader boom (2) by tightening the support arms (1) ...

  • Page 19: Connecting And Disconnecting Hydraulic Hoses

    19 (50) 5.2 Connecting and disconnecting hydraulic hoses On Avant loaders the hydraulic hoses are connected using the multi connector system. Risk of movement of the attachment and ejection of hydraulic oil - Never connect or disconnect quick couplings or other hydraulic components while the control...

  • Page 20: Electric Connection

    20 (50) Releasing residual hydraulic pressure: In case residual pressure is left in the hydraulic system of the attachment, it is often possible to disconnect the hydraulic couplings, but it may be difficult to connect them the next time. If the fittings will not connect, the residual pressure must be released by turning the auxiliary hydraulics control lever of the loader, when the engine is turned off.
  • Page 21 21 (50) If your loader is equipped with the Opticontrol ® If the loader is equipped with the Opticontrol , and ® the electric socket integrated in the multiconnector, the electric harness of the attachment is connected when the multiconnector is coupled. Clean both multiconnectors before connecting...

  • Page 22: Uncoupling And Storage

    22 (50) 5.4 Uncoupling and storage Uncouple and store the attachment on level ground. The best way to store the attachment is a place where it is protected from direct sunlight, rain, and extreme temperatures.  Avoid leaving the attachment laying directly on the ground. Place it on blocks of wood or on a pallet, for example.

  • Page 23: Using The Storage/Transport Support

    23 (50) Correct storage position: Turn the backhoe to the position as shown in the figure below: Bucket flat on the ground, straight front, not too close to the frame  Boom in such position that the storage supports can be locked ...

  • Page 24: Transport Position

    24 (50) 5.4.3 Transport position Turn the backhoe to its middle position (straight forward) so that it will not affect the stability of the loader. The middle position will obstruct visibility from the driver's seat as little as possible. Keep the loader stable. Always transport the backhoe as low and close to the ground as possible.

  • Page 25: Instructions For Use

    25 (50) 6. Instructions for use Check the attachment and the operating environment once more before starting to work, and that all obstacles have been removed from the operating area. Quick inspection of the equipment and the operating area before use are parts of ensuring safety and the best performance of the equipment.

  • Page 26: Checks Before Use

    26 (50) Risk of flying objects - Make sure that there are no outsiders in the operating area. Braking of hard soil by digging it with the backhoe may cause loose debris thrown at high speed. Always keep safety distance of 5 meters from bystanders. CAUTION 6.1 Checks before use Check that all obstacles, including any possibly hidden ones, have been removed from the working...

  • Page 27: Operating The Backhoe

    27 (50) 6.2 Operating the backhoe The backhoe can be controlled only with the remote control unit, either via radio link or with a cable. There are no manual control levers on this attachment. 1. Check that the backhoe is fully coupled to the loader before setting up the control unit Both of the quick coupling pins of the quick coupling must be in locking position ...

  • Page 28: Controls

    28 (50) 6.2.1 Controls Move the auxiliary hydraulics control lever of the loader to its locking position when ready to start operating the backhoe. Release the auxiliary hydraulics control lever whenever not operating the backhoe. The auxiliary hydraulics oil flow should not exceed 45 l/min. See the operator's manual of the loader for correct loader engine RPM setting.

  • Page 29: Outriggers

    29 (50) Left control joystick: Right control joystick:   front boom (stick) main boom   slewing bucket Switch on the left joystick:  Bucket tilt adapter/Thumb (optional equipment) Crushing hazard - Prevent unintentional movements of the attachment. Switch off the auxiliary hydraulics as soon as not using the backhoe to disable the controls of the backhoe.

  • Page 30: Starting To Use The Backhoe With Remote Controller

    30 (50) 6.2.3 Starting to use the backhoe with remote controller Risk of impact and crushing - Stay clear of the backhoe when setting it up. The backhoe may start unexpectedly during set up causing serious injuries from crushing or WARNING impact.
  • Page 31 31 (50) Connect the electric harness to the radio receiver of the loader.  If the loader is equipped with the Opticontrol system, the receiver is ® started with the ON/OFF switch of attachment control switch pack.  Otherwise use the separate switch of the cable kit A34731 rev.

  • Page 32: Using Digging Equipment

    32 (50) Risk of unexpected movement - Improper use. To prevent loss of control, accidental contact, or improper use, the user must always wear a waist belt or shoulder harness with the radio transmitter during operation. WARNING Risk of impact and crushing - Stay away from the reach area of the backhoe.
  • Page 33 33 (50)  Penetrate the ground with the bucket  Depending on soil material, the most efficient angle varies. In typical digging conditions,  start with the bucket at about a 45° angle to the ground. When digging hard ground, it ...

  • Page 34: Light Signals

    34 (50) Operate the backhoe only with its own hydraulic system and set of controls. Do not excavate by using the driving force of the loader. Working this way can damage the loader boom or the backhoe. Avoid sideways loading of the bucket. Working with the swivel force can damage the backhoe or the loader boom.

  • Page 35: Light Beacon

    35 (50) Receiving unit The receiving unit provides information as follows: The POWER LED indicates the status of the POWER receiving unit and the radio link. The ALARM LED warns about anomalies in the receiving unit. ALARM The meaning of signals provided by the ALARM LED are described in separate ARX Receiving Unit manual.

  • Page 36: Operating On Inclined Terrain

    36 (50) 6.6 Operating on inclined terrain Extra caution is needed when moving the equipment on inclined terrains and slopes. Drive slowly especially on inclined, uneven, or slippery surfaces, and avoid sudden changes in speed or direction. Operate the controls of the loader with careful and smooth movements. Watch out for ditches, holes on the ground, and other obstacles, as hitting an obstacle may cause the loader to tip over.
  • Page 37 37 (50) Table 5 - Backhoe 260 with remote control - Bucket options A414304 A35583 A414301 A35230 (standard bucket) Width: 250 mm 400 mm 750 mm 1000 mm Edge: 2 teeth 3 teeth straight straight Weight: 54 kg 66 kg...

  • Page 38: Installation Of Hydraulic Options

    38 (50) 6.8 Installation of hydraulic options Pinching and crushing hazard - Make sure any part of attachment cannot move. Make sure the attachment is securely lowered on the  WARNING ground. Shut down the loader engine and set the moving ...

  • Page 39: Excavator Thumb (Optional Extra)

    6.8.1 Excavator thumb (Optional extra) The Backhoe 260 can be equipped with an excavator thumb. The hydraulic excavator thumb makes it possible to handle irregural material such as rocks, concrete, branches, and debris that does not otherwise fit into the bucket.
  • Page 40 40 (50) Make sure that the slide bearings (3) are fixed to the mounting ends of the thumb (7). Slide the pivot pin (4) through the whole structure so that the boom, S30 quick coupling and bushings are fitted between the mounting ends of the thumb (7) as shown in the adjacent figure.

  • Page 41: Tilting Bucket Adapter (Optional Extra)

    Tilting bucket adapter (Optional extra) The Backhoe 260 can be equipped with a tilting bucket adapter. With the tilting adapter, a grading bucket can be used to level the ground surface to desired slopes or, for example, to dig a ditch. The tilting adapter includes the same S30-150 quick coupling system for the bucket as the backhoe itself, so the same buckets can be used with the tilting system.
  • Page 42 42 (50) Table 6 – Tilt adapter components 1. S30 quick coupling for bucket 2. Upper frame, installed to the backhoe 3. Hydraulic quick couplings, 2 pcs 4. Tilting cylinder 5. Pivot pin 6.8.2.1 Installing tilt adapter The tilting bucket adapter is mounted between the front boom of the backhoe and the bucket. The tilting bucket adapter replaces the standard coupling, and is also equipped with S30-150 quick coupling for the bucket.

  • Page 43: Maintenance And Service

    Repair all leaks immediately after detecting them; a small leak can quickly grow into a big one. Operate the attachment only with type of hydraulic oil that is accepted for use in Avant loaders. Risk of high pressure fluid injection through skin - Release residual pressure before maintenance.

  • Page 44: Cleaning The Attachment

    Finding any fault means that the hydraulic hose or component must be replaced and the equipment must not be used until it is repaired. Spare parts are available from your nearest AVANT retailer or authorised service point. Leave the repair work to professional service technicians, if you don’t have adequate knowledge and experience about hydraulic assemblies and how to perform the repairing safely.

  • Page 45: Lubrication

    45 (50) 7.4 Lubrication There are a total of 19 lubrication points at the joints of the backhoe. If a tilting bucket adapter is installed, there are 3 additional lubricating points. A small amount of grease should be added regularly. Correct lubrication interval depends heavily on operating conditions but lubricant must be added at least after every 10 hours of use.

  • Page 46: Radio Remote Control Maintenance

    46 (50) 7.5 Radio remote control maintenance Before any maintenance operation, disconnect the receiving unit from the power supply, and uncouple the hydraulic multiconnector. After maintenance or service, check that all control commands sent by the transmitting unit activate only the corresponding expected operations. Stop use and contact service in the unlikely case that the programming or memory of the control unit has been reset and movements do not correspond with controls.
  • Page 47 47 (50) Recharging the battery of the remote control Connect the battery charger to the AC mains socket. The POWER LED turns on with steady light. Insert the battery in its designated housing in the battery charger a. Push the battery towards the contacts on the battery charger b.

  • Page 48: Warranty Terms

    48 (50) 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows:  Work costs are covered, if the repair is not performed at the factory.
