PRODUCT NO.
FDS251RJR0
MARKET
North America
SERVICE DATA SHEET # - 154384501
OWNER'S GUIDE # - 154381201
WIRING DIAGRAM # - 154384501
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDR251RJ
18" Portable
Publication No.
5995344628
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
black
001011
©2000 White Consolidated Industries, Inc.
821
All rights reserved
DISHWASHER
18" PORTABLE
DISHWASHER
Model No.
FDS251RJ
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FDS251RJ
Summary of Contents for Frigidaire FDS251RJ
- Page 1 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 FACTORY PARTS CATALOG SERIES COLOR 18" Portable black Publication No. 5995344628 001011 -EN/SERVICE /ECL ©2000 White Consolidated Industries, Inc. All rights reserved DISHWASHER 18" PORTABLE DISHWASHER Model No. FDS251RJ...
-
Page 2: Control Panel
Publication No. FDS251RJR0 5995344628 CONTROL PANEL 12/00... - Page 3 POS. NO # = Fast Moving Part * = Non-Illustrated Part FDS251RJR0 CONTROL PANEL PART NO DESCRIPTION 154357601 Panel-control,black 154381103 Insert-control pnl,black 154376202 Timer 154220401 Switch-selector,5 button 154242201 Shield-switch 5303318719 Screw,mtg. 5300809036 Lens-light 154236501 Pushbutton,black 154239503 Knob-timer,black 5300809144 Shield-wire 154377601 Harness-wiring Publication No.
- Page 4 Publication No. FDS251RJR0 5995344628 DOOR 12/00...
- Page 5 POS. NO 11 # 12 # # = Fast Moving Part * = Non-Illustrated Part FDS251RJR0 DOOR PART NO DESCRIPTION 154237401 Spring-door,(2) 154093301 Screw-arm assy,(4) 5303270031 Arm Assy,RH & LH 154221401 Cover-arm 5303298513 Pin-arm 5300805884 Pad-spring 154079601 Nut-arm assy,(4) 154352201 Door-inner assy 154230101 Dispenser-det/rinse aid,includes #22...
- Page 6 Publication No. FDS251RJR0 5995344628 12/00...
- Page 7 POS. NO 25 # # = Fast Moving Part * = Non-Illustrated Part FDS251RJR0 PART NO DESCRIPTION 154218701 Tub assy w/gasket 154211601 Strike-door 154219501 Gasket-tub 154200602 Screw,10-16 x 3/8 ,hex 154333901 Roller-tub 5303943103 Screw w/washer,(8) 5300809902 Inlet-water 154239801 Tubing-water inlet 5303318539 Clamp-tubing,(2) 154209701...
-
Page 8: Motor & Pump
Publication No. FDS251RJR0 5995344628 MOTOR & PUMP 12/00... - Page 9 POS. NO 15 # 18 # # = Fast Moving Part * = Non-Illustrated Part FDS251RJR0 MOTOR & PUMP PART NO DESCRIPTION 154220901 Heater 154289801 Shield-heater terminal 154359701 Bracket-heater,(2) 154106201 Nut-heater,(2) 154365101 Macerator 154365301 Cover-volute 154365401 Impeller-lower 154365501 Slinger-pump 154364801 Housing-pump 154367701 Check valve...
- Page 10 Publication No. FDS251RJR0 5995344628 FRAME 12/00...
- Page 11 POS. NO 12 # 26 # 35 # # = Fast Moving Part * = Non-Illustrated Part FDS251RJR0 FRAME PART NO DESCRIPTION 154218801 Front frame assy 154236102 Bracket-front frame 154200601 Screw-#10-16 x 3/8 154359801 Valve-water 154219101 Brace-front 154225501 Switch-float 154209801 Bracket-float switch 154025901 Screw,truss head ,10 x 0.625...
- Page 12 Publication No. FDS251RJR0 5995344628 RACKS 12/00...
- Page 13 POS. NO # = Fast Moving Part * = Non-Illustrated Part FDS251RJR0 RACKS PART NO DESCRIPTION 154239101 Rack assy-lower 5300808994 Basket-Silverware 154239001 Rack assy-upper 5300809974 Wheel & bracket assy,upper rack 5300809927 Cap-slide,(4) 154232701 Slide-rack,(2) 154174501 Wheel & bracket assy,lower rack 154225203 Shelf-cup 154352401...
