PRODUCT NO.
FDS252RBS0
MARKET
North America
SERVICE DATA SHEET # - 154384501
OWNER'S GUIDE # - 154418701
ENERGY GUIDE LABEL # - 154399019
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDS252RB
18" Portable
Publication No.
5995370862
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
white
020423
821
©2002 Electrolux Home Products, Inc.
All rights reserved
DISHWASHER
18" Portable
DISHWASHER
Model No.
FDS252RB
Advertisement
Related Manuals for Frigidaire FDS252RB
Summary of Contents for Frigidaire FDS252RB
- Page 1 PRODUCT NO. BASE MODEL NO. FDS252RBS0 FDS252RB MARKET North America SERVICE DATA SHEET # - 154384501 OWNER’S GUIDE # - 154418701 ENERGY GUIDE LABEL # - 154399019 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 FACTORY PARTS CATALOG...
-
Page 2: Control Panel
Publication No. FDS252RBS0 5995370862 CONTROL PANEL 04/02... - Page 3 POS. NO # = Fast Moving Part * = Non-Illustrated Part CONTROL PANEL PART NO DESCRIPTION 154357602 Panel,control ,white 154418601 Insert,control panel ,white 154376202 Timer 154220401 Switch,selector ,5 button 154242201 Shield,switch 5303318719 Screw,mtg. 5304428149 Lens,light 154236502 Pushbutton,white 154239504 Knob,timer ,white 154421901 Wiring Harness 154416601...
- Page 4 Publication No. FDS252RBS0 5995370862 DOOR 04/02...
- Page 5 POS. NO 11 # 12 # # = Fast Moving Part * = Non-Illustrated Part DOOR PART NO DESCRIPTION 154237401 Spring,door ,(2) 154093301 Screw,arm assy ,(4) 5303270031 Arm Assy,RH & LH 154221401 Cover,arm assy 5303298513 Pin,arm assy 5300805884 Pad,door spring 154079601 Nut,arm assy ,(4) 154352201...
- Page 6 Publication No. FDS252RBS0 5995370862 04/02...
- Page 7 POS. NO 25 # # = Fast Moving Part * = Non-Illustrated Part PART NO DESCRIPTION 154218701 Tub assy,w/gasket 154211601 Strike,door 154219501 Gasket,tub 154200601 Screw,#10-16 x 3/8 154333902 Roller,tub 5303943103 Screw,w/washer ,(8) 154239801 Tubing,water inlet 5303318539 Clamp,tubing ,(2) 154209701 Float 154242302 Trim-tub flange,RH 154242303...
-
Page 8: Motor & Pump
Publication No. FDS252RBS0 5995370862 MOTOR & PUMP 04/02... - Page 9 POS. NO 15 # 18 # # = Fast Moving Part * = Non-Illustrated Part MOTOR & PUMP PART NO DESCRIPTION 154220901 Heater 154289801 Shield,heater terminal 154359701 Bracket,heater ,(2) 154106201 Nut,heater ,(2) 154365101 Macerator 154365302 Cover,volute 154365401 Impeller,lower drain 154365501 Slinger,pump 154364802 Housing,pump...
- Page 10 Publication No. FDS252RBS0 5995370862 FRAME 04/02...
- Page 11 POS. NO 12 # 26 # 34A* 35 # # = Fast Moving Part * = Non-Illustrated Part FRAME PART NO DESCRIPTION 154218801 Front frame assy 154236102 Bracket-front frame 154200601 Screw,#10-16 x 3/8 154373301 Valve,water 154219101 Brace,front frame 154408701 Switch assy,float 5300804672 Screw,start relay 154200602...
- Page 12 Publication No. FDS252RBS0 5995370862 RACKS 04/02...
- Page 13 POS. NO # = Fast Moving Part * = Non-Illustrated Part RACKS PART NO DESCRIPTION 154239101 Rack assy,lower 5300808994 Basket,silverware 154237502 Rack assy,upper 5304407064 Wheel & bushing assy,upper rack 5300809927 Cap,slide ,(4) 154232701 Slide,rack ,(2) 154174501 Wheel & bracket assy,lower rack 154225203 Shelf,cup 154352401...
