Energy Monitoring Hub
Data Acquisition System
TM
Cat. No. A8812
Installation and Operation Manual
DI-001-A8812-00A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Leviton EMH

Summary of Contents for Leviton EMH

  • Page 1 Energy Monitoring Hub Data Acquisition System Cat. No. A8812 Installation and Operation Manual DI-001-A8812-00A...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 Product Application Limitation ......................4 2 Features and Specifications ......................5 3 Installation Checklist ........................7 4 Installation ............................8 5 Configuration ..........................11 6 EAS Administration Overview ......................15 7 Security ............................17 8 Modbus ............................18 9 Wireless ............................29 10 Networking ...........................30 11 System Options ...........................32 12 Diagnostics ..........................35 13 LCD Console ..........................36...

  • Page 4: Product Application Limitation

    1 PRODUCT APPLICATION LIMITATION • Leviton products are not intended for use in critical applications such as nuclear facilities, human implantable devices or life support. Leviton is not liable, in whole or in part, for any claims or damages arising from such uses.

  • Page 5: Features And Specifications

    2 FEATURES AND SPECIFICATIONS The Energy Monitoring Hub™ Data Acquisition Server is designed to allow owners and managers of commercial and industrial facilities with a cost-effective means of gathering crucial information in a timely manner. To meet these requirements, the Energy Monitoring Hub™ system provides the installer with all the tools necessary to install and configure the hardware and software with a minimum of time and investment.
  • Page 6 2 FEATURES AND SPECIFICATIONS 2.1 Electrical Connections A8812 Internal View Not available with this model...

  • Page 7: Installation Checklist

    • Ethernet Cat 5 cable (required for LAN or direct laptop-to-DAS connection) Optional hardware: • Leviton Series 2000 and 3000 meters (Modbus RTU standard). • Analog sensors for temperature, humidity, etc. • Pulse output transducers for measuring gas, electricity, water, etc. from existing meters and sensors.

  • Page 8: Installation

    RS485 loop, between the + and – wires. For more information about RS485 termination, read the Modbus FAQ at www.leviton.com Note: Some Modbus devices do not use the same label notation as the Energy Monitoring Hub.
  • Page 9 4 INSTALLATION Power-up and diagnostics: Attach the power supply to the power input jack on the DAS, and plug the power brick into a wall outlet. The power brick should be in a location that is accessible for connection and disconnection. After power is applied, the green “Alive” light in the upper right of the Energy Monitoring Hub should come on and the LCD display will display a series of diagnostic screens ending with the following message on the LCD display (this boot sequence may require up to 20 seconds to complete):...
  • Page 10 4 INSTALLATION Verify connected devices: To verify that the Modbus devices are installed and reporting correctly, use the Modbus status utility on the DAS. To do this test, follow these steps: 4.4.1 Press and release the menu (top) button on the DAS. The following will appear on the LCD display: 4.4.2 Press the menu (top) button several more times until the LCD display shows the...

  • Page 11: Configuration

    5 CONFIGURATION 5.1 Basic Network Configuration 5.1.1 Determine the IP addressing needs: The IP address of the DAS can be implemented using one of three methods. Check with the network administrator to determine which method applies. For phone installations, use “direct connection to laptop” to allow initial configuration.
  • Page 12 5 CONFIGURATION 5.1.2.4 At this point, the cursor on the display will be blinking on the first number in the IP address on the second line. 5.1.2.5 To change the number, press the menu (top) button and the display will cycle through the digits 0-9 as well as “.”.
  • Page 13 5 CONFIGURATION 5.2 Laptop/Computer Setup 5.2.1 You must have a computer to access and configure the DAS. This computer must have an ethernet connection (on the LAN or by direct connection) and must have a web browser installed. Note: If your building already has an existing LAN that the DAS is attached to, you can use an existing computer on that LAN.
  • Page 14 5 CONFIGURATION 5.3 Laptop/Computer IP Address Configuration Configure the laptop IP address using the following steps. Note: Only Windows is detailed below, however you can use any OS/Browser you wish such as MacOS or Linux. Details on network setup for non-windows operating systems is beyond the scope of this document however.

  • Page 15: Eas Administration Overview

    Some devices may require additional information. For example, the Veris H8238 Multi circuit power meter allows the CT size to be specified. The Leviton A8332 Module and the A8812 DAS internal IO module have additional configuration options on each data point line to specify the details of the analog or pulse input.
  • Page 16 If you have an in-house data collection service, you should enter the address of your data server in this field. Leviton also provides a service called Building Manager Online that can collect and report data for you. If you are using the BMO service, the target address to upload data should be set to http://upload.levitonbmo.com/...

  • Page 17: Security

    7 SECURITY The DAS has three levels of security. These are “operator”, “user” and “admin”. When using a browser to access the DAS , basic http authentication is used to prompt your browser for a username and password. The admin account uses “admin” as the default password. To change the password, select the Accounts menu from the left side tree display.

  • Page 18: Modbus

    firmware. Use the System/Firmware update page to check for newer versions of the firmware. The leviton.com website FAQ also has a list of supported Modbus devices. Modbus devices that are not supported by built in drivers may be configured using the Modbus Framework feature in the DAS.
  • Page 19 8 MODBUS 8.2 Device List Options At the top of the Modbus device list page, there are several display options that control the sorting of the device list. Tree display: click this icon to organize the list by showing each ModHopper ®...
  • Page 20 8 MODBUS 8.3 Device Details The device detail page will show a list of all the meter data points, alarm settings and console options. The data point names for most devices are automatically entered. Some devices have generic inputs, and will be labeled as “pulse input #1”.
  • Page 21 8 MODBUS 8.4 Device Configuration When the “configure” button is clicked from the device details page, the screen will be refreshed, with the same information, however the device name, alarm settings and console checkbox will be available. Device Name: This field allows you to specify a name for the device such as “main building power” or other useful name to indicate the location or function of the device.
  • Page 22 8 MODBUS 8.6 Manual Device Add Options Modbus devices may be added manually by clicking on the “add” link on the bottom of the modbus device list page. This option is intended for use when adding devices to the configuration profile prior to installing the physical hardware, or configuring Modbus/TCP devices that will automatically populate in the Modbus device list.
  • Page 23 8 MODBUS 8.7 Internal IO Configuration The A8812 Energy Monitoring Hub provides 8 multipurpose flex inputs on board. The onboard io inputs will always be device 250 in the device list. 8.7.1 Click on the device number 250 in the device list. A page showing the device inputs will be presented.
  • Page 24 (Curve Scale Templates) are provided with the DAS. For more information refer to the Curve Scale Documentation supplement provided on the leviton.com website. Pulse Rate: For most units, this feature is an automatic rate field. For KWH points, the rate is KW.
  • Page 25 250. The internal I/O device will respond with Modbus registers that represent all of the features seen in the Energy Monitoring Hub configuration pages. Complete documentation of the Internal IO device 250 Modbus registers is available online on the website Leviton .com in the A8812 overview section.
  • Page 26 Verify the + (red), - (black), and Shield connections are correct on all connections. Look for any connection in the middle of the loop that may have the wires reversed, or shorted together. Check the Modbus FAQs on the leviton.com website for further details on wiring a Modbus serial connection. •...
  • Page 27 Modbus RS485 loop that are not specifically supported by the DAS. A Modbus/TCP technical guide may be available soon at www.leviton.com. Modbus RS/485 baud rate: This feature allows the configuration of the RS485 serial port speed which the DAS uses to communicate with Modbus devices.
  • Page 28 DAS that requires the user to be familiar with the Modbus protocol and with the Modbus register point list for the specific Modbus device that will be used. For more information on the Modbus Framework feature, download the Modbus Framework documentation from www.leviton.com.

  • Page 29: Wireless

    9 WIRELESS 9.1 Sensor List The sensor list feature works in conjunction with a number of non Modbus sensors. Sensor devices such as PointSix, BAPI, and Badger/Orion typically transmit data on a preset interval and are not polled by the DAS. Data is received and uniquely identified by the sensor’s serial number.

  • Page 30: Networking

    10 NETWORKING 10.1 Network Status This page displays the current status of the DAS network connections. Several interfaces may be shown if both Ethernet and ppp dialin/dialout are active at the same time. Each interface will report the IP address, number of packets sent and received, and other details specific to the interface.
  • Page 31 10 NETWORKING 10.3 Troubleshooting Ethernet Problems After reconfiguring the ethernet settings you experience problems accessing the DAS with your web browser, check the following items. • Verify that you rebooted the DAS after making the changes to the network settings. •...

  • Page 32: System Options

    You may need to verify if your firewall will allow NTP or Rdate packets to pass through. Generally, it is better to use a local time server if possible. The time server time.leviton.com supports both NTP and Rdate time protocols. If you use a GSM connected system, you will probably need to use Rdate.
  • Page 33 11 SYSTEM OPTIONS If you store data in local time, you will have the following issues. Local time is relative. Is Local the time where the DAS exists, or local to where the data is stored? If local to the DAS , you must shift each DAS data set depending on its location. There are about 11 time zones in the US.
  • Page 34 “dialout now” button on the Networking/Modem-ppp/Status page. After clicking the “Check for updates” button, the DAS will contact the Leviton .com webserver and attempt to download a list of firmware files. The list is compared to the firmware versions installed, and a listing of the files will be displayed.

  • Page 35: Diagnostics

    12 DIAGNOSTICS 12.1 Host Lookup The Host Lookup page provides the ability to do some basic network tests. These are as follows: Ping: send an echo request to the specified Traceroute: Send an echo request to the target address and attempt to locate every router in between the DAS and that address.

  • Page 36: Lcd Console

    13 LCD CONSOLE The DAS has an LCD console and two push buttons labeled “menu” and “select”. These can be used to configure some of the basic features of the DAS. The intended purpose of the console is to configure the DAS to a point where a computer can communicate with it for further detailed configuration.
  • Page 37 The Enable Console feature will provide a shell prompt on the serial port for remote diagnostics. This is intended to be used by Leviton technical support only. The Reset Configuration option will remove all the user settings, data, and passwords that have been configured and will return the DAS to the factory default settings.

  • Page 38: Log File Data

    14 LOG FILE DATA The DAS stores data from the modbus devices in text (.CSV) log files. One log file is created for each modbus device on the system. On a daily basis, the log files are “rotated”, that is, the current log file is renamed and compressed with gzip compression, and a new log file is started.
  • Page 39 14 LOG FILE DATA Comments: Date/Time: The date/time column reports the time at which data was logged from the Modbus device. Note: this is not necessarily the time at the start of the log cycle. Users with large number of devices may notice some of the Modbus devices at higher address numbers report 1 or 2 seconds after the first Modbus devices.
  • Page 40 14 LOG FILE DATA 138 Gateway Path Unavailable (the Modbus/TCP gateway may be misconfigured) 139 Device Failed to Respond (the Modbus device may be off or disconnected) 140 Received invalid Modbus data checksum 141 Received response from unexpected device 142 Received unsolicited query, assume another Modbus master device is present 143 Modbus device probe function received some good responses and some failures 160 Start log (Entry in log file after DAS starts up) 161 Stop log (Entry in log file if DAS is shut down properly)
  • Page 41 14 LOG FILE DATA When the DAS storage area on the flash starts to run out of space, the following action is taken: • When the 8 MB log file storage area is 75% full, the DAS will immediately compress the log files and attempt to upload the data to the BMO website or user specified site.
  • Page 42 14.4.3 Contact the Leviton Technical Support department. Please have the DAS serial number and password to upload data handy. Your tech support representative will confirm your BMO account and will add the DAS to one of your client databases.

  • Page 43: Retrieving Data From The Eas

    Enertrax download direct from the DAS Leviton provides a free tool called Enertrax DL that can automate the process of downloading log data from the DAS to your Windows PC hard drive. Enertrax DL can merge new log data into existing log files on your computer as well as provide configuration information about the DAS.
  • Page 44 For FTP, the process is essentially the same process as the manual FTP data download. For more information on FTP access to the DAS, please view the FAQ and Technotes section at leviton.com. Steps for Microsoft Windows command prompt FTP.

  • Page 45: Mechanical Drawings

    16 MECHANICAL DRAWINGS The DAS uses a metal enclosure that is approximately 9.25 in x 8 in x 2 in deep. The Enclosure has a tab on the bottom that requires 2.5 in clearance. Two 1.2 in holes are provided in the bottom of the DAS for wiring purposes.

  • Page 46: Warranty And Contact Infromation

    LIMITED 5 YEAR WARRANTY AND EXCLUSIONS Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by Leviton is free of defects in materials and workmanship under normal and proper use for five years from the purchase date. Leviton’s only obligation is to correct such defects by repair or replacement, at its option.
  • Page 48 DI-001-A8812-00A...
