Frigidaire FDB1051RES2 Service Data Sheet

Electronic series
Hide thumbs

Advertisement

Exploded View of Wash System
Nozzle
Funnel
Nut
Funnel Base
Center Spray Arm
Lower Spray Arm
Check Ball
Circulation
Motor Assembly
Motor Bracket
Water Inlet Tube
Water Valve
Incoming Water Supply
Pump Assembly
The pump assembly is driven by a synchronous
is attached by a worm gear clamp to the discharge
motor. Rotation is in the counterclockwise
end of the drain pump.
direction at 3600 RPM. The motor drives a pump
The drain hose must have a loop at a minimum
which supplies 100 percent filtered water at a
height of 32 inches in order to insure proper
rate of approximately 12 GPM to one spray arm
drainage.
at a time. The spray arm's operation is alternated
by small "pauses" of the motor during the wash
The main pump can easily be removed by
cycle.
disconnecting the upper spray arm supply tube
hose, the drain pump connector hose, the wiring
Draining is accomplished by using a small
harness connections made at the circulation
separate synchronous drain pump mounted to
motor, the water heat thermistor located on the
the side of the sump. The drain pump is
bottom of the pump and rotating the four sump
connected to the main pump by a small rubber
retainers toward the middle of the sump.
hose. The drain check valve is located at the
discharge end of the drain pump. The drain hose
900 Watt Heater
Refer to the cycle chart on the reverse side to
Voltage checks of the heater should be made in
the dry portion of the service test mode.
determine when the heater is on during the wash
cycle. The heater cycles ON and OFF for brief
periods during the drying cycle.
Standard Dry Air Flow
When the control advances to the "dry" portion of
the cycle, a linear actuator retracts a valve, which
opens a vent path through the console into the
kitchen. The heated, moist air leaving the
dishwasher through the console vent causes
drier air to be drawn into the unit by way of intake
Drain Hose
(32" minimum
height)
Detergent and Rinse Aid Dispenser
The detergent and rinse aid dispenser is a one
piece component consisting of a molded
Spray Arm
detergent cup and a built-in rinse aid dispenser.
Support
The detergent cup has a spring loaded cover
Glass Trap
and the rinse aid dispenser has a removable
cover.
Heating
Element
Liquid rinse aid is added to the dispenser up to
the fill line indicator. The amount of rinse aid
Filter
released can be adjusted by turning the arrow
indicator from one, being the least amount, to
Soil Director
four, being the greatest amount.
Volute Cover
Drain Motor
Delivery Tube
Tub and Door Seal
Connector Hose and Clamps
The door seal is pressed into the tub channel for
an interference fit. Center the gasket (marked on
Sump
back) at the tub top center and press in place
Sump Retainers (4)
Product Specifications
Electrical
Rating ................................... 120 Volts, 60Hz
Separate Circuit..15 amp min.- 20 amp max.
Motor (Amps) ........................................... 0.6
Heater Wattage ....................................... 900
Total Amps (load rated) ......................... 10.0
TempAssure .............................. 140°F ±5°F
(60°C±3°C) [with outer door in place]
TempBoost ............. 145°F ±5°F (63°C ±3°C)
Heated Wash/Heated Rinse
Sanitize .................. 155°F ±5°F (66°C ±3°C)
Hi-Limit Thermostat ................ 200°F (93°C)
vents located at the bottom of the door. The water
on the dishes is evaporated into drier air and the
venting process continues. The heating element
is turned ON and OFF during the entire drying
cycle.
Always disconnect the dishwasher from the electrical power source before adjusting or
replacing components.
Symptom
Dishwasher will not operate when
turned on.
To replace dispenser:
• shut off electricity to dishwasher,
• remove outer door panel assembly,
• disconnect wiring to the actuator,
• remove the six screws,
• remove the dispenser,
• replace and reinstall screws,
Motor hums but will not start or run.
• rewire actuator.
Motor trips out on internal thermal
overload protector.
Dishwasher runs but will not heat.
Detergent cover will not latch or
without stretching or bunching. The gasket takes
open.
a short turn at the bottom of the tub channel
before ending at the channel end wall.
Dishwasher will not pump out.
Gasket Cross Section
Mounting
Dishwasher will not fill with water.
Rib
Tub
Interior
Dishwasher water siphons out.
Short Turn
Detergent left in dispenser.
Water Supply
Suggested minimum incoming water
temperature ............................. 120°F (49°C)
Pressure (PSI) min./max. ................... 20/120
Connection (NPT) .....................................
3
/
"
8
Consumption (Normal Cycle) .......................
............. 4.9 - 9.7 U.S. gal., 18.5 - 36.7 liters
Water valve flow rate (U.S. GPM) ........... .83
Water recirculation rate (U.S. GPM) ..............
.................................................... approx. 12
Water fill time ..................................... 87 sec.
Trouble Shooting Tips
Personal Injury Hazard
Check the Following
Remedy
1. Fuse (blown or tripped).
1. Replace fuse or reset breaker.
2. 120 VAC supply wiring connection
2. Repair or replace wire fasteners at
faulty.
dishwasher junction box.
3. Electronic control board defective.
3. Replace control module.
4. Motor (inoperative).
4. Replace motor/impeller assembly.
5. Door switch (open contacts).
5. Replace latch assembly.
6. Door latch not making contact with
6. Replace latch assembly.
door switch.
7. Touch pad circuit defective.
7. Replace console assembly.
8. No indicator lamps illuminate when
8. Replace console assembly.
START or OPTIONS are pressed.
1. Motor (bad bearings).
1. Replace motor assembly.
2. Motor stuck due to prolonged
2. Rotate motor impeller.
non-use.
1. Improper voltage.
1. Check voltage.
2. Motor windings shorted.
2. Replace motor/impeller assembly.
3. Glass or foreign items in pump.
3. Clean and clear blockage.
1. Heater element (open).
1. Replace heater element.
2. Electronic control board defective.
2. Replace control module.
3. Wiring or terminal defective.
3. Repair or replace.
4. Hi-Limit thermostat defective.
4. Replace thermostat.
1. Latch mechanism defective.
1. Replace dispenser.
2. Electronic control board defective.
2. Replace control module.
3. Wiring or terminal defective.
3. Repair or replace.
4. Broken spring(s).
4. Replace dispenser.
5. Defective actuator.
5. Replace dispenser.
1. Drain restricted.
1. Clear restrictions.
2. Electronic control board defective.
2. Replace control module.
3. Defective drain pump.
3. Replace pump.
4. Blocked impeller.
4. Check for blockage, clear.
5. Open windings.
5. Replace pump assembly.
6. Wiring or terminal defective.
6. Repair or replace.
1. Water supply turned off.
1. Turn water supply on.
2. Defective water inlet fill valve.
2. Replace water inlet fill valve.
3. Check fill valve screen for
3. Disassemble and clean screen.
obstructions.
4. Defective float switch.
4. Repair or replace.
5. Electronic control board defective.
5. Replace control module.
6. Wiring or terminal defective.
6. Repair or replace.
7. Float stuck in "UP" position.
7. Clean float.
1. Drain hose (high) loop too low.
1. Repair to proper 32-inch minimum
height .
2. Drain line connected to a floor drain
2. Install air gap at counter top.
not vented.
1. Detergent allowed to stand too long in
1. Instruct customer/user.
dispenser.
2. Dispenser wet when detergent was
2. Instruct customer/user.
added.
3. Detergent cover held closed or blocked
3. Instruct customer/user on proper
by large dishes.
loading of dishes.
4. Improper incoming water
4. Incoming water temperature of
temperature to properly dissolve
120°F is required to properly
detergent.
dissolve dishwashing detergents.
5. See "Detergent cover will not open."
020905
