User Guide Unisto e-Guard / Unisto e-Guard Data Trans Set contain: backplate Nut M6 hexagon screw M6 cradle cover hasp e-Guard base washer e-Guard cover O-ring large 4x O-ring small 4x Torx 8 screw Unisto Battery bridge foam rocker Version:Unisto_User-Guide-e-Guard_1C...
Page 2
Wake-up your e-Guard: 5 SEK When the button is pressed, SLEEP To activate the device you have to After that the display shows StArt for appears on the display. press the button 5 times within 5 a short time. Now the seal is ready seconds.
Page 3
Cut excess with a saw and remove any sharp edges with a file. How to use: Close the seal Push the button and write down the Push the button on your final desti- 4 digit unique sealing number. nation and check your code again. unlock your seal Version:Unisto_User-Guide-e-Guard_1C...
Plug in the new battery and turn the While booting the display lights up. battey. Use a replacement battery e-Guard to check the display. from Unisto Mount the back cover. Place all five Fix the back plate with the four new screws.
10 SEK Push the touch button until the yel- After the numbers “CLOSE” appears When the calibration was successful low LED flashes for the second time on the display and the new hasp the display will show “donE”. If cali- and the display shows “CAL”.
Page 6
Missing hasp MAC Adress During the reboot the mac-address is shown on the display splitted in 6 When the hasp is missing the e-Gu- segments. For example: To display the mac-address unplug ard does not show or generate num- and plug the battery. 1 - - E7 4 - - Cb 2 - - 1A...
Page 7
App Function Unisto e-Guard Data Trans The app is developed for Smartphones with operating system Android 8.0 or higher. Download the app from the store and follow the instructions. https://play.google.com/store/apps/de- tails?id=com.unisto.eguard Version:Unisto_User-Guide-e-Guard_1C...
Initial operations: It’s important to make sure the e-Guard was once connected to the smartphone before use! 5 SEK Activate Bluethooth Touch the button for 5 seconds and the green LED starts flashing. The trailer number can only be set...
Page 9
last time seal was active latest No. seal closed seal open missing hasp scan another seal Send data with Choose your mailing program Type in a valid e-mail address to send the csv file. Version:Unisto_User-Guide-e-Guard_1C...
Unisto Site. Repairs community. may only be carried out at the Unisto site. Our aim is to repair or replace faulty units within 10 working days upon receipt of the units in UCH. Carriage will be paid for warranty repairs dispatched, not collected, only.
Page 11
This will be quoted separately, and will be dependent on the type of fault discovered. In addi- tion Unisto will not normally repair a standard unit, which is deemed uneconomical to repair. Repairs or replacement parts are warranted to be free of defect in materials or workmanship for 3 months.
