- Page 1 ATX MID TOWER User's Manual TEMPERED GLASS & RGB LED LIGHTING SYNC Ver. 051019 * To ensure safe and easy installation, please read the following precaution. * Product design and specifications may be revised to improve quality and performance without notice. www.zalman.com...
- Page 2 Z7 NEO Precautions ■ Read this manual carefully before installing. ■ Check the product and components before installing. If you find any abnormality, contact the location where you purchased the product for a replacement or refund. ■ Wear gloves to prevent accidents when installing the product.
-
Page 3: Меры Предосторожности
Precauciones ■ Lea atentamente este manual antes de la instalación. ■ Compruebe el producto y los componentes antes de instalarlos. Si encuentra alguna anomalía, comuníquese con la ubicación donde compró el producto para un reemplazo o un reembolso. ■ Use guantes para evitar accidentes al instalar el producto. ■... - Page 4 Z7 NEO 预防措施 ■ 在安装前请仔细阅读本手册。 ■ 在安装前请检查产品和组件。如果您发现任何异常情况，请联系您购买本产品的地方，进行更换或是退款。 ■ 在安装本产品时，请佩戴手套，以防止发生事故。 ■ 在安装系统时，可能会发生严重伤害，所以请不要过度用力。 ■ 错误的接线可能导致因短路而造成的火灾。接线时请确保参考本手册。 ■ 在使用该系统时，请小心不要遮挡本产品的通风口。 ■ 避免放置在阳光直晒、有水、潮湿、有油或是尘土过多的地方。请在通风良好的场合保存并使用本产品。 ■ 请不要用化学品擦拭本产品的表面。（例如酒精或丙酮等有机溶剂） ■ 在操作过程中请不要把手或是其它物品伸入本产品中，这可能会导致您的手或物品受伤或受损。 ■ 请在儿童无法接触到的地方保存并使用本产品。 ■ 我们公司对于因本产品用于不当用途和/或用户失误而造成的任何问题，不承担任何责任。 ■ 本产品的外形设计和参数可能会因为质量提升而有所变更，恕不另行通知。 Precauções ■ Leia este manual com atenção antes da instalação. ■ Verifique o produto e os componentes antes da instalação. Se encontrar alguma anormalidade, contacte o local onde comprou o produto para o substituir ou para obter um reembolso.
-
Page 5: Środki Ostrożności
Środki ostrożności ■ Przed przystąpieniem do montażu należy zapoznać się ze zrozumieniem z treścią tego podręcznika. ■ Przed przystąpieniem do montażu należy sprawdzić produkt i podzespoły. W razie stwierdzenia nieprawidłowości należy skontaktować się ze sklepem, w którym produkt został zakupiony, aby wy mienić... - Page 6 Z7 NEO Tedbirler ■ Kurmadan önce bu kılavuzu dikkatlice okuyun. ■ Kurmadan önce ürünü ve bileşenleri kontrol edin. Herhangi bir anormallik bulursanız, değiştirme veya iade için ürünü satın aldığınız yer ile iletişim kurun. ■ Ürünü kurarken kazaları önlemek için eldiven takın.
-
Page 7: Specifications
Specifications Model Z7 NEO Case Form Factor ATX Mid-Tower Dimensions 420 x 213 x 460(H)mm Weight 7.2kg Case Materials Plastic, Steel, Tempered Glass Motherboard Support ATX / mATX / Mini-ITX Maximum VGA Length 355mm Maximum CPU Cooler Height 165mm Maximum PSU Length... -
Page 8: Removing The Side Panels
Z7 NEO I/O Ports ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓖ ⓗ Part Part Part Part ⓐ ⓑ ⓒ ⓓ USB 3.0 Port USB 2.0 Ports Headphone Jack Microphone Jack ⓔ ⓕ ⓖ ⓗ HDD / Power LED LED Control Button... -
Page 9: Mounting The Motherboard
2. Mounting the motherboard Motherboard Standoffs SSD / MB Screws 2-1. Motherboard size 1) ATX 2) mATX 3) Mini-ITX 1 ITX 1 ITX 1 ITX 1 ITX 1 ITX 1+2 MICRO ATX 1+2 MICRO ATX 1+2 MICRO ATX 1+2 MICRO ATX 1+2 MICRO ATX 1+2+3 ATX 1+2+3 ATX... - Page 10 Z7 NEO 3. Mounting the PSU PSU / VGA Screws x 4 4. Mounting the PCI-E(VGA) card PSU / VGA Screws x 2...
- Page 11 5. Mounting the 3.5" and 2.5" SSD / HDD 1. HDD 2. SSD HDD Screws SSD / MB Screws 6. Mounting the 2.5” SSD / HDD SSD / MB Screws x 4 SSD / MB Screws x 2...
- Page 12 Z7 NEO 7. Mounting the top fans Fan Screws 8. Mounting the front radiator Fan Screws Caution ※ Limited fitment to memory equipped with heatsinks. ※ Some motherboards with tall heat sink will cause interference on the installation of the 280mm radiator.
-
Page 13: Fan Specifications
9. Fan specifications RPM : 1200± 10% Input : 12V 0.6A 10. I/O Connectors HDD LED Reset Power LED Power HD Audio USB 3.0 USB 2.0... - Page 14 Z7 NEO 11. RGB LED Controller Fan 1~8 / 6Pin - Connector to RGB LED fans (Four pre-installed) - RGB LED Fans I/O port 8ea Fan + (12V) Fan - LED + (12V) LED + (12V) Fan - Fan + (12V)
- Page 15 11. RGB LED Controller Fan 1~8 / 6Pin - RGB LED 팬 연결 (4개 기본장착) - RGB LED 팬을 연결 가능한 I/O 포트 (8개 제공) Fan + (12V) Fan - LED + (12V) LED + (12V) Fan - Fan + (12V) LED 컨트롤...
- Page 16 Z7 NEO 11. RGB LED Контроллер Вентилятор 1~8 / 6Pin - Коннектор к RGB LED вентиляторам (четыре предустоновлено) - RGB LED Вентиляторы I/O порты 8ea Вентилятор + (12V) Вентилятор - LED + (12V) LED + (12V) Вентилятор - Вентилятор + (12V) Кнопка...
- Page 17 제품 보증서 제품명 모델명 구입일 년 월 일 Serial No. 구입처 판매 금액 1. 품질 보증기간 : 제품 구입일로부터 1년. (단, 구입 영수증이 있을 때) 2. 무상 A/S : 품질 보증기간 내에 제품 자체 성능 상의하자 및 불량 발생 시. 3.
- Page 18 Z7 NEO MEMO...
- Page 19 MEMO...
- Page 20 Z7 NEO www.zalman.com...
