Trigno
Wireless
Biofeedback System
__
Avanti Load Cell Adapter
User's Guide
Download EMGworks® at
www.delsys.com/emgworks
Copyright © 2019 by Delsys Incorporated
MAN-022-2-0
MP1313A
October 2019
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form by any means without the written
permission of Delsys Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Delsys Trigno Avanti Load Cell Adapter
Summary of Contents for Delsys Trigno Avanti Load Cell Adapter
- Page 1 Biofeedback System Avanti Load Cell Adapter User’s Guide Download EMGworks® at www.delsys.com/emgworks Copyright © 2019 by Delsys Incorporated MAN-022-2-0 MP1313A October 2019 No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written...
-
Page 2: Table Of Contents
Important Information ................3 Intended Use ......................3 Contraindications ....................3 Technical Service and Support ................3 Warnings and Precautions ..................4 Device Information ....................5 Windows PC Requirements ..................6 Android Device Requirements................. 6 Trigno System Overview ................7 Trigno Load Cell Adapter Features ................ -
Page 3: Important Information
DO NOT USE on Patients with allergies to Silver. DO NOT USE in critical care applications. Technical Service and Support For information and assistance please visit our web site at: www.delsys.com Contact us at: E-mail: support@delsys.com Telephone: (508) 545 8200 Trigno Avanti Load Cell Adapter User’s Guide... -
Page 4: Warnings And Precautions
Connect only to Delsys-approved devices. Connecting a patient to high-frequency surgical equipment while using Delsys EMG systems may result in burns at the site of the EMG sensor contacts Immediately discontinue device use if skin irritation or discomfort occurs. -
Page 5: Device Information
Dispose the device according to local rules for electronic waste. Authorized Representative: EMERGO EUROPE Prinsessegracht 20, 2514 AP The Hague The Netherlands Trigno Wireless Biofeedback System Sensor Model: SP-W06-022 (“Trigno Avanti Load Cell Adapter”) System Model: DS-T03 FCCID: W4P-SP-W06 (Sensor) FCCID: W4P-SP-W02 (Base Station) IC: 8138A-DST03 (System) 211-190332 (DS-T03) 211-190333 (SP-W06) This device complies with Part 15 of the FCC Rules and Industry Canada’s... -
Page 6: Windows Pc Requirements
Connect the equipment into outlet on a separate circuit. Pursuant to FCC 15.21 of the FCC rules, changes not expressly approved by Delsys Inc. could void the User’s authority to operate the equipment. Please refer to the main Trigno System User Guide for additional information. -
Page 7: Trigno System Overview
• battery charge monitoring and status indicator • environmentally sealed enclosure • low power mode • auto shutoff • internal magnetic switch • LED User Feedback 1. Communication distance is dependent on the RF operating environment. Trigno Avanti Load Cell Adapter User’s Guide... -
Page 8: Inertial Measurement Unit
Inertial Measurement Unit Trigno sensors have a built-in 9 DOF inertial measurement unit which can relay acceleration, rotation and earth magnetic field (compass) information. Users can use this information to discern movement activity time-synchronized with the EMG signals. One of 4 ranges can be selected for each sensor to span ±2g to ±16g for accelerometer outputs and ±250°/s to ±2000°/s for gyroscope outputs. -
Page 9: Sensor Led Feedback States
Pairing Fail (Base) double flash(≥3x) BLE Mode Advertise (BLE) Cyan Slow flash Low Power Advertise (BLE) Cyan occasional flash Data Collection (BLE) Blue slow flash Idle (BLE) Magenta slow flash Table 1: Sensor LED functions. Trigno Avanti Load Cell Adapter User’s Guide... - Page 10 LED State Descriptions 1) Power Off: No LED arrow activity is present when the sensor is off. 2) Power On: When undocked, the sensor illuminates white and fades to black. A magnetic field will turn the sensor on within 6 seconds, otherwise the arrow fades to dark and sensor turns off.
-
Page 11: Getting Started With The Load Cell Adapter
Ch. x.3 148 sa/sec DC-50 Hz Ch. x.4 148 sa/sec DC-50 Hz Table 2: Analog Output signal details. Note that sampling rates are approximate; please refer to specification table for precise sampling periods. Trigno Avanti Load Cell Adapter User’s Guide... -
Page 12: Working With Load Cells
Figure 1: Analog Output Data Flowchart Refer to the Trigno System User Guide for more information on Analog Output Operation. Working with Load Cells Connecting the Load Cell to the Adapter The Trigno Load Cell Adapter presents a LEMO connector for connecting load cell transducers. - Page 13 The Figure above illustrates a common technique that researchers employ when using load cell type devices. Each situation and use-case is unique, however, so the user is encouraged to explore strategies as needed. Trigno Avanti Load Cell Adapter User’s Guide...
-
Page 14: Maintenance And Care
Maintenance and Care Trigno Sensors Trigno sensor are encased in a sealed polycarbonate enclosure. The following points should be kept in mind when handling the sensors. • All sensors should be visually inspected before each use to ensure that no mechanical deterioration has occurred. •... -
Page 15: Specifications
Gyroscope Bandwidth 50 Hz – 361 Hz (configurable in software) Magnetometer Range ±4900 uT Magnetometer Bandwidth 50 Hz Inter-Sensor Delay < 1 sample period (Base Station only) Intra-Channel Delay < 1-2 sample period Trigno Avanti Load Cell Adapter User’s Guide... -
Page 16: Inertial Measurement Data Modes
Inertial Measurement Data Modes 1 1 1 0.45 2222 DC-50 3.25 ±2 ±250 ±4 ±500 2 1 1 0.794 1259 DC-50 3.25 16 6.75 148 50 16 6.75 148 50 ±8 ±1000 ±16 ±2000 27 / 52 1926 3 1 1 DC-50 3.25 6.75... -
Page 17: Orientation Measurement Data Modes
Denotes raw Load Cell signal acquisition. Denotes onboard calculation of orientation fused from 3 DOF accelerometer, 3 DOF gyroscope and 3 DOF magnetometer data. Trigno Avanti Load Cell Adapter User’s Guide... - Page 18 This page intentionally left blank. MAN-022-2-0...
