Trigno
Wireless
Biofeedback System
__
Avanti Analog Input
Adapter
User's Guide
Download EMGworks® at
www.delsys.com/emgworks
Copyright © 2019 by Delsys Incorporated
MAN-021-2-0
MP1289A
August 2019
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form by any means without the written
permission of Delsys Inc.
Advertisement
Table of Contents
Related Manuals for Delsys Trigno Avanti
Summary of Contents for Delsys Trigno Avanti
- Page 1 Avanti Analog Input Adapter User’s Guide Download EMGworks® at www.delsys.com/emgworks Copyright © 2019 by Delsys Incorporated MAN-021-2-0 MP1289A August 2019 No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written...
-
Page 2: Table Of Contents
Important Information ................3 Intended Use ......................3 Contraindications ....................3 Technical Service and Support ................3 Warnings and Precautions ..................4 Device Information ....................5 Windows PC Requirements ..................6 Android Device Requirements................. 6 Trigno System Overview ................7 Trigno Analog Adapter Features................ -
Page 3: Important Information
DO NOT USE on Patients with allergies to Silver. DO NOT USE in critical care applications. Technical Service and Support For information and assistance please visit our web site at: www.delsys.com Contact us at: E-mail: support@delsys.com Telephone: (508) 545 8200 Trigno Avanti Analog Input Adapter User’s Guide... -
Page 4: Warnings And Precautions
Connect only to Delsys-approved devices. Connecting a patient to high-frequency surgical equipment while using Delsys EMG systems may result in burns at the site of the EMG sensor contacts Immediately discontinue device use if skin irritation or discomfort occurs. -
Page 5: Device Information
Dispose the device according to local rules for electronic waste. Authorized Representative: EMERGO EUROPE Prinsessegracht 20, 2514 AP The Hague The Netherlands Trigno Wireless Biofeedback System Sensor Model: SP-W06-025 (“Trigno Avanti Analog Input Adapter”) System Model: DS-T03 FCCID: W4P-SP-W06 (Sensor) FCCID: W4P-SP-W02 (Base Station) IC: 8138A-DST03 (System) 211-190332 (DS-T03) 211-190333 (SP-W06) This device complies with Part 15 of the FCC Rules and Industry Canada’s... -
Page 6: Windows Pc Requirements
Connect the equipment into outlet on a separate circuit. Pursuant to FCC 15.21 of the FCC rules, changes not expressly approved by Delsys Inc. could void the User’s authority to operate the equipment. Please refer to the main Trigno System User Guide for additional information. -
Page 7: Trigno System Overview
• internal magnetic switch • LED User Feedback • Industry Standard DSUB-9 connector • Optional Industry Standard BNC connectors • Optional push-button attachment for event triggering 1. Communication distance is dependent on the RF operating environment. Trigno Avanti Analog Input Adapter User’s Guide... -
Page 8: Robust +/-5V Input Signal
Robust +/-5V Input Signal The analog input adapter can accept 4 voltage signals in the +/-5V range and sample these to a resolution of 16 bits alongside other data from Trigno sensors. The adapter has a selectable filter of DC-100 Hz or DC-1000 Hz, depending on the configured mode that the adapter is operated in (see mode selection tables in the appendices). -
Page 9: Sealed Enclosure
Sensor LED Feedback States Trigno Avanti sensors indicate their status through various LED Arrow colors and blink patterns as indicated in the table below. Each of these states is described in subsequent sections of this User Guide. - Page 10 LED State Descriptions 1) Power Off: No LED arrow activity is present when the sensor is off. 2) Power On: When undocked, the sensor illuminates white and fades to black. A magnetic field will turn the sensor on within 6 seconds, otherwise the arrow fades to dark and sensor turns off.
-
Page 11: Getting Started With The Analog Input Adapter
Sampling Rate Data Type Bandwidth Ch. x.1 1926 sa/sec 20-450 Hz Table 2: Analog Output signal details. Note that sampling rates are approximate; please refer to specification table for precise sampling periods. Trigno Avanti Analog Input Adapter User’s Guide... -
Page 12: Analog Input Adapter Connections
Common 1,2,3,4,5 Figure 2: Trigno Avanti Analog Input Adapter. DSUB connector makes ground and 4 channel inputs available for sampling +/-5V signals. Bandwidth setting of DC-100 Hz is recommended for single BW data slot operation and DC-1000 Hz will require multi-slot acquisition. -
Page 13: Single Channel Bnc Connection (Dc-X06)
A push-button attachment is available that can be used to manually toggle a signal line from a voltage “high” to a voltage “low” signal to mark events. Figure 6: Event Marker Button attachment. Trigno Avanti Analog Input Adapter User’s Guide... -
Page 14: Maintenance And Care
Maintenance and Care Trigno Sensors Trigno sensor are encased in a sealed polycarbonate enclosure. The following points should be kept in mind when handling the sensors. • All sensors should be visually inspected before each use to ensure that no mechanical deterioration has occurred. •... -
Page 15: Specifications
±250 dps, ±500 dps. ±1000dps, ±2000dps Gyroscope Bandwidth 24Hz – 361 Hz (configurable in software) Magnetometer Range ±4900 uT Magnetometer Bandwidth 50 Hz Inter-Sensor Delay < 1 sample period (Base Station only) Intra-Channel Delay < 1-2 sample period Trigno Avanti Analog Input Adapter User’s Guide... -
Page 16: Analog Input Measurement Data Modes
Analog Input Measurement Data Modes 1.93 DC-100 +/- 5 1111 DC-100 +/- 5 DC-100 0.45 2222 +/- 5 DC-1000 DC-100 0.52 2222 DC-1000 +/- 5 DC-100 0.225 4444 +/- 5 DC-1000 27 / 52 1926 DC-100 +/- 5 The Trigno System is designed with 16 data slots for wireless transmission. Sensors can occupy up to 4 slots depending on the sampling rate settings. - Page 17 This page intentionally left blank. Trigno Avanti Analog Input Adapter User’s Guide...
- Page 18 This page intentionally left blank. MAN-021-2-0...
