Trigno
Wireless
Biofeedback System
__
Avanti FSR Adapter
User's Guide
Download EMGworks® at
www.delsys.com/emgworks
Copyright © 2019 by Delsys Incorporated
MAN-019-2-1
MP1278B
August 2019
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form by any means without the written
permission of Delsys Inc.
Advertisement
Table of Contents
Related Manuals for Delsys Trigno Avanti FSR Adapter
Summary of Contents for Delsys Trigno Avanti FSR Adapter
- Page 1 Biofeedback System Avanti FSR Adapter User’s Guide Download EMGworks® at www.delsys.com/emgworks Copyright © 2019 by Delsys Incorporated MAN-019-2-1 MP1278B August 2019 No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written...
-
Page 2: Table Of Contents
Important Information ................3 Intended Use ......................3 Contraindications ....................3 Technical Service and Support ................3 Warnings and Precautions ..................4 Device Information ....................5 Windows PC Requirements ..................6 Android Device Requirements................. 6 Trigno System Overview ................7 Trigno FSR Adapter Features ................... -
Page 3: Important Information
DO NOT USE on Patients with allergies to Silver. DO NOT USE in critical care applications. Technical Service and Support For information and assistance please visit our web site at: www.delsys.com Contact us at: E-mail: support@delsys.com Telephone: (508) 545 8200 Trigno Avanti FSR Adapter User’s Guide... -
Page 4: Warnings And Precautions
Connect only to Delsys-approved devices. Connecting a patient to high-frequency surgical equipment while using Delsys EMG systems may result in burns at the site of the EMG sensor contacts Immediately discontinue device use if skin irritation or discomfort occurs. -
Page 5: Device Information
Dispose the device according to local rules for electronic waste. Authorized Representative: EMERGO EUROPE Prinsessegracht 20, 2514 AP The Hague The Netherlands Trigno Wireless Biofeedback System Sensor Model: SP-W06-020 (“Trigno Avanti FSR Adapter”) System Model: DS-T03 FCCID: W4P-SP-W06 (Sensor) FCCID: W4P-SP-W02 (Base Station) IC: 8138A-DST03 (System) 211-190332 (DS-T03) 211-190333 (SP-W06) This device complies with Part 15 of the FCC Rules and Industry Canada’s... -
Page 6: Windows Pc Requirements
Connect the equipment into outlet on a separate circuit. Pursuant to FCC 15.21 of the FCC rules, changes not expressly approved by Delsys Inc. could void the User’s authority to operate the equipment. Please refer to the main Trigno System User Guide for additional information. -
Page 7: Trigno System Overview
• battery charge monitoring and status indicator • environmentally sealed enclosure • low power mode • auto shutoff • internal magnetic switch • LED User Feedback 1. Communication distance is dependent on the RF operating environment. Trigno Avanti FSR Adapter User’s Guide... -
Page 8: Inertial Measurement Unit
Inertial Measurement Unit Trigno sensors have a built-in 9 DOF inertial measurement unit which can relay acceleration, rotation and earth magnetic field (compass) information. Users can use this information to discern movement activity time-synchronized with the EMG signals. One of 4 ranges can be selected for each sensor to span ±2g to ±16g for accelerometer outputs and ±250°/s to ±2000°/s for gyroscope outputs. -
Page 9: Sensor Led Feedback States
Pairing Fail (Base) double flash(≥3x) BLE Mode Advertise (BLE) Cyan Slow flash Low Power Advertise (BLE) Cyan occasional flash Data Collection (BLE) Blue slow flash Idle (BLE) Magenta slow flash Table 1: Sensor LED functions. Trigno Avanti FSR Adapter User’s Guide... - Page 10 LED State Descriptions 1) Power Off: No LED arrow activity is present when the sensor is off. 2) Power On: When undocked, the sensor illuminates white and fades to black. A magnetic field will turn the sensor on within 6 seconds, otherwise the arrow fades to dark and sensor turns off.
-
Page 11: Getting Started With The Trigno Fsr Adapter
148 sa/sec FSR C DC-50 Hz Ch. x.4 148 sa/sec FSR D DC-50 Hz Table 2: Analog Output signal details. Note that sampling rates are approximate; please refer to specification table for precise sampling periods. Trigno Avanti FSR Adapter User’s Guide... -
Page 12: Working With Fsr Membranes
The FSR membranes are delicate transducers constructed in multiple layers that have an ability to change resistance as pressure is applied. Delsys supplies these membranes with a 30 cm cable extension, terminated with a shrouded barrel connector for mating with the wireless adapter. Care must be exercised when using these membranes as excessive forces will damage them. -
Page 13: Connecting The Fsr Membranes To The Adapter
This will produce a similar response as the previous example, but may offer some added convenience for repetitive data trails. Applying tape to the FSR membrane may extend its usage life. Trigno Avanti FSR Adapter User’s Guide... - Page 14 Figure 4: Affixing the FSR membrane to the top of the inner sole. Placing the FSR membrane on the bottom of the inner shoe sole, provides some added protection to the device, as load and shear forces are diffused between the show base and the sole.
-
Page 15: Placing The Fsr Adapter
Placing the FSR Adapter The Trigno FSR Sensor and the associated connection head can be easily affixed to the surface of the body using the Delsys Adhesive interfaces. connector head is easily serviced by cutting a full-size interface in half. -
Page 16: Maintenance And Care
Maintenance and Care Trigno Sensors Trigno sensor are encased in a sealed polycarbonate enclosure. The following points should be kept in mind when handling the sensors. • All sensors should be visually inspected before each use to ensure that no mechanical deterioration has occurred. •... -
Page 17: Specifications
±250 dps, ±500 dps. ±1000dps, ±2000dps Gyroscope Bandwidth 50 Hz – 361 Hz (configurable in software) Magnetometer Range ±4900 uT Magnetometer Bandwidth 50 Hz Inter-Sensor Delay < 1 sample period (Base Station only) Intra-Channel Delay < 1-2 sample period Trigno Avanti FSR Adapter User’s Guide... -
Page 18: Inertial Measurement Data Modes
Inertial Measurement Data Modes ±2 ±250 ±4 ±500 1 1 4 3.375 DC-50 16 6.75 148 50 16 6.75 148 50 ±8 ±1000 ±16 ±2000 2 1 4 27 / 14 DC-50 16 ±2 ±250 ±4 ±500 3 4 4 0.90 1111 DC-50 16 1.35 741 246... -
Page 19: Orientation Measurement Data Modes
Denotes raw FSR signal acquisition. Denotes onboard calculation of orientation fused from 3 DOF accelerometer, 3 DOF gyroscope and 3 DOF magnetometer data. Trigno Avanti FSR Adapter User’s Guide...
