- Page 1 Trigno Wireless Biofeedback System...
- Page 2 User’s Guide PM-W01 Copyright © 2017 by Delsys Incorporated MAN-031-0-1...
-
Page 3: Table Of Contents
Important Information ................7 Intended Use ......................7 Contraindications ....................7 Technical Service and Support ................7 Warnings and Precautions ..................8 Device Information ....................8 PC Requirements ....................10 Trigno System Overview ................11 System Components....................11 Trigno Avanti™ Sensor Features ................11 Onboard EMG Sensor ...................... - Page 4 Maintenance and Care ................25 Trigno Sensors ....................... 25 Trigno Base Station....................25 Specifications ................... 26 Appendix I ....................27 Mains Isolation ...................... 27...
-
Page 5: Important Information
NOT USE on irritated skin or open wounds. DO NOT USE on Patients with allergies to Silver. DO NOT USE in critical care applications. Technical Service and Support For information and assistance visit our web site at: www.delsys.com Contact us at: E-mail: support@delsys.com Telephone: (508) 545 8200... -
Page 6: Warnings And Precautions
Connect only to Delsys-approved devices. Connecting a patient to high-frequency surgical equipment while using Delsys EMG systems may result in burns at the site of the EMG sensor contacts Immediately discontinue device use if skin irritation or discomfort occurs. - Page 7 Type BF Equipment. Date of Manufacturing (appears on device) Serial Number (appears on device) Dispose the device according to local rules for electronic waste. Authorized Representative: EMERGO EUROPE Prinsessegracht 20, 2514 AP The Hague The Netherlands FCC ID: W4P-SP-W02 (Trigno Base Station) FCC ID: W4P-SP-W06 (Trigno “Avanti”...
-
Page 8: Pc Requirements
Connect the equipment into outlet on a separate circuit. Pursuant to FCC 15.21 of the FCC rules, changes not expressly approved by Delsys Inc. could void the User’s authority to operate the equipment. PC Requirements • EMGworks 4.3 or later •... -
Page 9: Trigno System Overview
Trigno System Overview The Trigno Wireless Biofeedback System is a device designed to make EMG (electromyographic) and biofeedback signal detection reliable and easy. The system transmits signals from the Trigno Avanti™ sensors to a receiving base station using a time-synchronized wireless protocol which minimizes data latency across sensors. -
Page 10: Onboard Emg Sensor
Onboard EMG Sensor Trigno Avanti™ sensors support a low noise, high fidelity sensing circuit for detecting EMG (electromyographic) biofeedback signals from the surface of the skin when muscles contract. The sensor bandwidth can be selected between 10-850Hz or 20-450 Hz and the input range of the sensor can be selected between 22mV or 11mV depending on user needs. -
Page 11: Sensor Led Feedback States
or if it is exercised within 3 seconds of pulling a sensor out of a charging pocket. Exposure to any magnetic fields outside of these 2 qualifying conditions will be ignored by the sensor. The internal magnetic switch is a feature which removes the need for a mechanical button resulting in improvements to sensor durability and performance. -
Page 12: Base Station Features
Base Station Features Each Base Station is equipped with the following features: • recharging cradle for 16 sensors • high speed USB communication with PC • 64-channel analog outputs • ± 5V analog output range • detachable antenna • full trigger capability (Start/Stop, Input/Output) •... -
Page 13: Getting Started With The Trigno System
Getting Started with the Trigno System Software Installation The Trigno EMG system is controlled by a PC through the USB port, and thus requires software. Trigno Systems include a Delsys Software DVD containing EMGworks Signal Acquisition and Analysis Software for interacting with the system Install EMGworks from the Delsys Software DVD or from www.delsys.com... -
Page 14: Turning The Sensor On
even when not in use in order to maximize battery life, as sensor batteries will self-discharge with time and will degrade if left uncharged for extended periods of time. Figure 2: Docking a sensor in the charge cradle (left). When docked, sensors will turn off and begin battery charging indicated by an amber LED indicator. -
Page 15: Turning The Sensors Off
Figure 3: Ensure sensors are docked and charging for a minimum of 3 seconds and then removed from the charge cradle to turn on. Turning the Sensors OFF There are 4 mechanisms that will turn the sensors off: a) Dock Sensors in Charger: docking the sensors in the charge cradle will automatically turn the wireless communication system of the sensor off and engage the battery charging circuit. -
Page 16: Acquiring Data With The System
Acquiring Data with the System Refer to the software user guide and help information for detailed explanation of software functions. Data collection and sensors configuration is initiated through the software. Configuring the Trigno Sensors Once paired to the system, EMG data and IMU data from sensor can be configured in the following ways: Electromyographic (EMG) Sensing Ranges Input Range... -
Page 17: Using The Wireless Emg Sensors
The sensor is easily attached to the skin using the Delsys Adhesive Sensor Interface. muscle-fiber direction Figure 6. EMG Sensors must be properly oriented with the muscle fibers. Align the sensor’s arrow with the direction of the underlying muscle fibers. - Page 18 alcohol to remove oils and surface residues. Allow the skin to dry completely before applying the interfaces. Adhesive Sensor Interfaces are for single use only. Immediately discontinue use if skin irritation or discomfort occurs. All Adhesive Sensor Interfaces and Reference Electrodes are for single use only.
-
Page 19: Using The Analog Outputs
Using the Analog Outputs The Trigno System provides simultaneous analog signal reconstruction of data being detected by all active sensors. These signals are made available on the 68-pin connectors located on the Base Station and range cover the +/-5V range Figure 4: Analog Output Connectors on Base Station. - Page 20 Figure 5: Pinouts of the analog output connectors Trigno™ System User’s Guide...
-
Page 21: Configuration Options For Trigno System
Configuration Options for Trigno System Trigno System Information The Information tab presents information pertaining to the system and its settings. Figure 6: Trigno System panel. Transmission Frequencies Wireless communication occurs on varieties of frequencies throughout the acceptable 2.4 GHz spectrum. Four frequency sets are available (“A”, “B”, “C” and “D”) and are displayed in this field. -
Page 22: Trigno System Settings
Trigno System Settings The Settings tab allows several system parameters to be modified as needed. Figure 7: Trigno System Settings panel. Frequency Set Use this setting to change the frequencies being used for wireless communication. The default set is “A”. The frequency set should only be changed if nearby sources are interfering with Trigno communications or the particular operating environment is causing significant path loss on the current frequency set. -
Page 23: Maintenance And Care
Maintenance and Care Trigno Sensors Trigno sensor are encased in a sealed polycarbonate enclosure. The following points should be kept in mind when handling the sensors. • All sensors should be visually inspected before each use to ensure that no mechanical deterioration has occurred. •... - Page 24 Specifications RF Frequency Band 2400-2483 MHz (ISM band) Dimension 27 x 37 x 13 mm Mass 14.7 g Temperature Range 5 - 50 degrees Celsius EMG Signal Input Range 11mV / 22mV r.t.i. EMG Signal Bandwidth 20-450 Hz / 10-850 Hz EMG Contact Dimensions 5x1 mm Contact Material...
- Page 25 PC running the Trigno Software is conceivably within their reach, it too must be isolated. Delsys does not supply isolation transformers for Personal Computers and their peripherals. Delsys recommends model IS1000HG manufactured by Tripp Lite (www.tripplite.com) for this task.
