Campbell Hausfeld SN528K Operating Instructions Manual

See Warranty on page 6 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury, death and/or
property damage! Retain instructions for future reference.
BUILT TO LAST
Table of Contents
General Safety . . . . . . . . . . . .1-3
Specifications . . . . . . . . . . . . . . .2
Operating The Tool . . . . . . . .3-5
Troubleshooting . . . . . . . . . . .5-6
Warranty . . . . . . . . . . . . . . . . . .6
Description
This stapler is designed for cabinetry,
casebacks, decorative trim and crafts.
Features include: convenient bottom
loading magazine which holds up to
100 staples, sequential trip safety
mechanism and a narrow nose for
accurate fastener placement in tight
applications.
General Safety
Information
CALIFORNIA PROPOSI-
TION 65
You
DANGER
!
can
create dust when you cut,
sand, drill or grind materi-
als such as wood, paint, metal, con-
crete, cement, or other masonry. This
dust often contains chemicals known
to cause cancer, birth defects, or other
reproductive harm. Wear protective
gear.
Excessive exposure
WARNING
!
to vibration, work-
ing in awkward positions and repeti-
tive work motions can cause injury to
hands and arms. Stop using any tool if
discomfort, numbness, tingling or pain
occur and consult a physician.
This manual contains safety, opera-
tional and maintenance information.
Contact your Campbell Hausfeld repre-
sentative if you have any questions.
OPERATOR'S RESPONSIBILITY:
The tool operator is responsible for:
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
Campbell Hausfeld Nailers meet or exceed
Industries' Standards as set forth by the
American National Standard
Institute/International Staple, Nail and Tool
Association in ANSI/ISANTA SNT-101-2002.
© 2003 Campbell Hausfeld/Scott Fetzer
• Reading and understanding tool
labels and manual.
• Selecting an appropriate tool actua-
tion system, taking into considera-
tion the work application for which
the tool is used.
• The safe use of the tool.
• Ensuring that the tool
is used only when the
operator and all
other personnel in
the work area are
wearing ANSI Z87 eye protection
equipment, and when required,
other appropriate protection equip-
ment such as head, hearing and foot
protection equipment. Serious eye or
permanent hearing loss could result.
• Assuring that the tool is kept in safe
working order as described in this
manual.
EMPLOYER'S RESPONSIBILITY:
• Selecting an appropriate tool actua-
tion system, taking into considera-
tion the work application for which
the tool is used.
• Ensuring that this manual is available
to operators and personnel perform-
ing maintenance.
• The safe use of the tool.
• Enforcing that the
tool is used only
when the operator
and all other person-
nel in the work area
are wearing ANSI Z87 eye protection
equipment, and when required,
other appropriate protection equip-
ment such as head, hearing and foot
protection equipment. Serious eye or
permanent hearing loss could result.
• Assuring that the tool is kept in safe
working order as described in this
manual.
For parts, product & service information
visit www.chpower.com
Model SN258K
Finishing
Stapler
Model SN258K
Locate model and date code on tool
magazine and cap and record below:
Model No. ________________________
Date Code ________________
Retain these numbers for
future reference.
• Assuring the proper maintenance
of all tools in employer's possession.
• Ensuring that tools which require
repair are not further used before
repair. Tags and physical segrega-
tion are recommended means of
control.
Danger indicates
DANGER
!
an imminently
hazardous situation which, if not
avoided, WILL result in death or seri-
ous injury.
Read and understand
tool labels and manual.
Failure to follow warn-
ings, dangers, and cau-
tions could result in
DEATH or SERIOUS
INJURY.
Do not use any type
of reactive gases,
including, but not
limited to, oxygen
and combustible
gases, as a power
source. Use filtered, lubricated, reg-
ulated compressed air only. Use of a
IN231204AV 7/03
O
CO
2
