Campbell Hausfeld AT0510 Manual

See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and/or property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . 1
Unpacking . . . . . . . . . . . . . . . . . . . . . . 1
Safety Guidelines . . . . . . . . . . . . . . . . 1
Important Safety Information . . . . . . 1
Tool Components and
Specifications. . . . . . . . . . . . . . . . . . . . 2
Operating Instructions . . . . . . . . . . . . 4
Lubrication . . . . . . . . . . . . . . . . . . . . 4
Recommended Hookup. . . . . . . . . . 4
Operational Mode . . . . . . . . . . . . . . 5
User-Maintenance Instructions . . . . . 5
Troubleshooting Chart . . . . . . . . . . . . 6
Warranty . . . . . . . . . . . . . . . . . . . . . . . 8
Description
Ratchets are air tools designed for
removing and installing spark plugs
and different engine parts such as
water pumps, radiators, etc. Use in
confined areas where hand tools are
cumbersome.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service.
© 2019 Campbell Hausfeld
A Marmon/Berkshire Hathaway Company
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not
avoided, WILL result in death or
serious injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
information, that if not followed,
may cause damage to equipment.
NOTE: Information that requires special
attention.
Important Safety Instructions
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
This manual contains safety, operational
and maintenance information. Contact
your Campbell Hausfeld representative
if you have any questions.
should always be followed,
including the following:
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.campbellhausfeld.com
3/8 inch Ratchet
Danger indicates
an imminently
Models AT0510 and TL0501
Warning indicates
a potentially
Caution indicates
a potentially
CALIFORNIA PROPOSITION 65
Notice indicates
important
This product can expose you to
chemicals including lead, which are
known to the State of California
to cause cancer and birth defects
or other reproductive harm. For
more information go to www.
P65Warnings.ca.gov.
You can create dust
when you cut, sand, drill
or grind materials such
as wood, paint, metal, concrete,
cement, or other masonry. This dust
often contains chemicals known to
When using tools,
cause cancer, birth defects, or other
basic precautions
reproductive harm. Wear protective
gear.
AT0510, TL0501
Locate model and date code on
tool and record below:
Model No.: _____________________
Date Code: _____________________
Retain these numbers for
future reference.
IN732703 1/19
