Freestyle FS80925 Instructions

Quartz Analog-Eng-1.ai 2008/4/14 12:41:44 PM Quartz Analog-Eng-1.ai 2008/4/14 12:41:44 PM
3 HAND MOVMENT
QUARTZ ANALOG
INSTRUCTIONS
Time Setting
FUNCTIONS 1. Pull the crown out to farthest
point. If the crown is a screw-
down crown make sure to un-
• 3 HAND MOVEMENT
screw the crown and then pull out
• 3 HAND MOVEMENT W/ DATE
to the farthest point.
• 3 HAND MOVEMENT W/ DAY/
2. Turn the crown clockwise moving
DATE
the hands to the position of the
• MULTI-FUNCTION MOVEMENT
desired time.
• CHRONOGRAPH MOVEMENT
3. Once the desired time is selected
• ALARM MOVEMENT
firmly push the crown back in to
• EL MOVEMENT
its original position. Please make
sure to push back in completely to
avoid any entry of water. If the
crown is a screw-down crown
make sure to screw the crown
back in tightly to avoid any water
entry.
3 HAND MOVEMENT WITH DATE
Time and Date Setting
1. Pull crown out to the first "click"
as shown in position 2. If the
crown is a screw-down crown
make sure to un-screw the crown
and then pull out to the first
"click" as shown in position 2.
2. Turn the crown and set the date to
one day before the actual date.
This is important to ensure proper
date advancement. If date does
not advance, turn crown in
opposite direction.
3. Pull the crown out one more
"click" as shown in position 3.
4. Turn the crown clockwise, moving
the watch hands until the correct
date appears. Note that you are
now in the AM mode and must
advance the hour hand all the way
past the 12 o'clock position to set
PM time. Failure to follow this step
will cause the date to advance at
12'clock noon instead of 12 o'clock
midnight.
5. With the crown still in position 3,
rotate the crown until the hands
are positioned at the desired time.
6. Firmly push crown in as shown in
position 1. This will activate your
2. Turn the crown clockwise and set
watch. If the crown is a screw-
the day for the previous day.
down crown make sure to screw
the crown back in tightly to avoid
Date Setting
any water entry.
1. With the crown still in position 2,
turn the crown counter-clockwise
MULTI-EYE MOVEMENT
and set the date to one day before
the actual date. This is important
to ensure proper date
advancement.
Time Setting
1. Pull crown out to the first "click"
as shown in position 2. If the
crown is a screw-down crown
make sure to un-screw the crown
and then pull
Date Setting
out to the first "click" as shown in
1. Pull out crown to the first "click"
position 2.
as show in position 2. If the crown
2. Turn crown clockwise to advance
is a screw-down crown make sure
the time and continue until the
to un-screw the crown and then
day/date changes to the present
pull out to the first "click" as show
day. Note that you are now in the
in position 2.
AM mode and must advance the
2. Turn the crown clockwise to
hour hand all the way past the 12
advance the date hand.
o'clock position to set PM time.
Failure to follow this step will
Day and Time Setting
cause the date to advance at 12
1. Pull the crown out one more
o'clock noon instead of 12 o'clock
"click" as shown in position 3.
midnight.
2. Turn crown clockwise to advance
3. Set the correct time, and firmly
hour and minute hands. The hand
push the crown in as shown in
showing days of the week will also
position 1. This will activate your
move with the hour and minute
watch. If the crown is a screw-
hands. Keep turning until you have
down crown make sure to screw
reached the desired day.
the crown back in tightly to avoid
any water entry.
24 Hour Sub-Dial Setting
1. The 24-hour hand moves
CHRONOGRAPH MOVEMENT
correspondingly with the hour and
minute hands. When setting the
time be sure to check that the 24-
hour hand is set properly.
2. Firmly push crown in as shown in
position 1. This will activate your
watch. If the crown is a screw-
down crown make sure to screw
the crown back in tightly to avoid
any water entry.
DAY-DATE MOVEMENT
If your watch is a chronograph, you
can set the date and time according
to the instructions on the "3 HAND
MOVEMENT WITH DATE" section.
Additionally, to use the chronograph
feature, do the following:
1. The chrono tracks seconds using
the large second hand on the
watch. Minutes are tracked by the
small hand at the 12 o'clock
position and hours by the hand at
Day Setting the 9 o'clock position.
1. Pull crown out to the first "click" 2. Start the chrono by pressing
as shown in position 2.If the crown button RT. Stop it by pressing RT
is a screw-drown crown make again. Reset to zero by pressing
sure to un-screw the crown and RB.
then pull out to the first "click" as 3. If your chrono is not zeroed
shown in position 2. correctly (second hand is not at 12
o'clock when reset), you can
adjust the zero point by fully
extending the crown and pressing
RT repeatedly.
ALARM MOVEMENT
1. Set the alarm by pulling out the 3
o'clock crown to position 1 and
turning it in a clockwise direction.
The shortest hand is usually the
alarm hand.
2. When the hand is set to the
desired alarm time pull out the 2
o'clock crown to turn the alarm
on. Alarm sounds for 15 seconds
and is repeated for around 3
minutes.
3. To turn the alarm sound off push
the 2 o'clock crown button
completely in.
EL Movement
If your watch is equipped with an
electroluminescence (EL) backlight ,
first set the time and date according
to the Time Setting instructions that
match your watch . To activate the
EL backlight , press the light button ,
The dial will light up for three
seconds .
If there is no separate light button ,
press the crown in to activate the
backlight .
