DRIVER PROTECTION
LADDER
(for versions/markets, where provided)
On some versions, a fixed ladder fig. 54
is provided to protect the driver from
unstable loads and allow greater
loading capacity from the passenger
side.
54
COMBI VERSIONS
(for versions/markets, where provided)
Fixed partition fig. 55
55
32
This is located behind the backrest of
the rear seats.
SECURING YOUR LOAD
Hooks (various number, according to
version) are fixed to the floor for easy
securing load.
Cargo versions fig. 56;
56
F0T0177
Combi versions fig. 57.
57
F0T0195
LOADING ADVICE
Some simple suggestions can improve
driving safety, comfort and vehicle
duration: - distribute the load evenly
over the platform: if it must be
concentrated it in a single area, choose
an area mid-way between both axles;
- lastly, remember that the dynamic
behaviour of the vehicle is affected by
the transported weight: in particular, the
stopping distances are longer,
especially at high speed.
24) 25) 26) 27)
WARNING
F0T0057
24) Bumpy roads and abrupt braking may
cause unexpected load shifting with
consequently hazardous situations for the
driver and passengers: before setting
off, secure the load tightly using the
partition and appropriate hooks, steel
cables, ropes or chains strong enough to
hold the items to be secured.
25) Even when the car is stopped on a
steep hill or side slope, opening the rear or
side doors could cause unsecured goods
to fall out.
26) If you wish to carry a reserve of petrol
in a can, observe the legal restrictions
F0T0058
and only use a can that is type-approved
and properly secured to the load
anchorage eyebolts. In the event of a
collision the fire risk is increased all the
same.
