ATI Technologies F12/D O & M Manual

Toxic gas transmitter with h10 smart sensor
Hide thumbs
Table of Contents

Advertisement

Quick Links

F12/D Toxic Gas Transmitter
With H10 Smart Sensor
Home Office
Analytical Technology, Inc.
6 Iron Bridge Drive
Collegeville, PA 19426
Phone: 800-959-0299
610-917-0991
Fax:
610-917-0992
Email: sales@analyticaltechnology.com
www.AnalyticalTechnology.com
O & M Manual
European Office
ATI (UK) Limited
Unit 1 & 2 Gatehead Business Park
Delph New Road, Delph
Saddleworth OL3 5DE
Phone: +44 (0)1457-873-318
Fax:
+ 44 (0)1457-874-468
Email: sales@atiuk.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F12/D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATI Technologies F12/D

Summary of Contents for ATI Technologies F12/D

  • Page 1 O & M Manual F12/D Toxic Gas Transmitter With H10 Smart Sensor Home Office European Office Analytical Technology, Inc. ATI (UK) Limited 6 Iron Bridge Drive Unit 1 & 2 Gatehead Business Park Collegeville, PA 19426 Delph New Road, Delph...

  • Page 2: Table Of Contents

    Table of Contents SAFETY ..............IV Trouble Indication ........... 35 Timed Return to Main Display ......35 ............ARNINGS Inhibiting Alarms from the Main Display ..35 ......AZARDOUS OCATION NSTALLATION 4.4 P ..........35 ISPLAYS PART1 - INTRODUCTION ........5 Sensor Removed Display........
  • Page 3 .....46 IGURE ENERATOR ISPLAY 11 - G ....14 IGURE ENERATOR XPLODED 60. A ....46 IGURE TEST TATUS ISPLAY 12. F12/D T .. 15 IGURE RANSMITTER ONFIGURATIONS 61. A IGURE TEST TATUS ISPLAY EQUENCE 13. S . 16 IGURE ENSOR...
  • Page 4 97. R ........71 IGURE ELAYS 98. R ......72 IGURE ELAY ETUP 99. P ........72 IGURE ANEL 100. D ........73 IGURE ISPLAY 101. S ........ 73 IGURE ECURITY 102. A ......74 IGURE CTIVATING ECURITY 103. D ....

  • Page 5: Safety

    SAFETY Read and understand this manual before installing, operating, or maintaining the F12/D Transmitter. Pay particular attention to the warnings and cautions below. All of the warnings and cautions shown here are repeated in the appropriate sections of the manual.

  • Page 6: Part1 - Introduction

    General F12/D Gas Transmitter The F12/D Gas Transmitter is used to monitor for gas leaks near storage cylinders, process piping, or gas feed equipment in nearly any type of industrial plant environment. It is housed in NEMA 4X, polycarbonate enclosure and features an H10 Smart Sensor, a non-intrusive four button user interface with a backlit transflective graphics display, three level alarms with three (optional) alarm relays, a high-resolution 4- 20mA current loop output, real-time clock, data-logger, and optional HART™...

  • Page 7: H10 Smart Sensors

    Model F12/D Gas Transmitter Part 1 - Introduction H10 Smart Sensors Part No. Standard Minimum Range Maximum Range Range GENERAL GASES Acetylene 00-1057 0-200 PPM 0-50 PPM 0-500 PPM Alcohol 00-1043 0-200 PPM 0-50 PPM 0-500 PPM Alcohol 00-1044 0-500 PPM...
  • Page 8 Model F12/D Gas Transmitter Part 1 - Introduction ACID GASES Hydrogen Bromide 00-1455* 0-20 PPM 0-10 PPM 0-200 PPM Hydrogen Chloride 00-1017* 0-10 PPM 0-10 PPM 0-200 PPM Hydrogen Cyanide 00-1018* 0-10 PPM 0-10 PPM 0-200 PPM Hydrogen Fluoride 00-1019*...

  • Page 9: Specifications

    Model F12/D Gas Transmitter Part 1 - Introduction Specifications Sensor Type Electrochemical cell Gas Type Sensor dependent (refer to list of available sensor types) Range User adjustable within limits of selected sensor (refer to list of available sensor types) Response Time...

  • Page 10: Part 2 - Mechanical Installation

    Part 2 – Mechanical Installation Transmitter Mounting Threaded inserts in the rear of the enclosure permit the attachment of brackets for securing the transmitter to a wall or pipe. An optional bracket is also available for “flush mounting” the transmitter into a panel, so that only the front cover protrudes.

  • Page 11: Wall And Pipe Mounting

    Part 2 – Mechanical Installation Model F12/D Gas Transmitter Figure 3 Deep Enclosure dimensions Wall and Pipe Mounting A PVC mounting bracket with attachment screws is supplied with the transmitter. The transmitter is attached to the bracket using four flat head screws, and the bracket is attached to a wall or pipe by way of the four slots in each corner.

  • Page 12: Figure 5. Wall Mounting Diagram

    Part 2 – Mechanical Installation Model F12/D Gas Transmitter Figure 5. Wall mounting diagram Figure 6. Pipe mounting diagram O&M Manual (Rev-H)

  • Page 13: Panel Mounting

    Part 2 – Mechanical Installation Model F12/D Gas Transmitter Panel Mounting (Remote Sensors Only) Figure 7 depicts the details for panel mounting the deep case. For this, a bracket attaches to the rear housing, and when adjusted, pulls the transmitter’s flange down against the adhesive side of the gasket supplied with the bracket (make certain to remove the protective paper first).

  • Page 14: Figure 9. Duct-Mount Assembly

    Part 2 – Mechanical Installation Model F12/D Gas Transmitter Figure 8 Duct Mount Sensor Exploded View Figure 9. Duct-mount assembly O&M Manual (Rev-H)

  • Page 15: Duct Mount (Integral)

    Part 2 – Mechanical Installation Model F12/D Gas Transmitter Duct Mount (Integral) Figure 10 - Duct Mount (Integral) Transmitter Dimensions Generator Installation/Removal Generators are inserted into the optional generator housing attached to the bottom of the sensor housing at the base of the transmitter.

  • Page 16: Part 3 - Electrical Connections

    4-24 mA 4-24 mA LooP LooP Autotest Generator AC or DC AC or DC 12-30V 12-30V Powered Powered Transmitter Transmitter w/Autotest w/o Autotest Generator Generator AC Mains AC Mains 12-30V 12-30V Autotest Generator Figure 12. F12/D Transmitter Configurations O&M Manual (Rev-H)

  • Page 17: Terminal Board - Sensor

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Terminal Board - Sensor Connections The Terminal Board is located just below the metal shield in the front cover. It contains the power and communication terminals, and provides a header for connecting the Sensor Housing wires and optional Autotest Generator wires.

  • Page 18: Terminal Board - Loopp

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Terminal Board – Loop Power Connections The Loop Powered transmitter model is powered in using terminals 5 and 6 commonly referred to as “two- wire mode”. Loop Powered models with the heated sensor housing and/or MODBUS communications option require an additional 24 VDC supply to power them.

  • Page 19: Heated Sensor Housingw

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Heated Sensor Housing Wiring The AC Powered and DC Powered models contain a power supply to create the power necessary for the optional Heated Sensor Housing. The two pink wires from the heated Sensor Housing connect to terminals 5 and 6 of the AC or DC Power Supply PCB.

  • Page 20: Remote Sensor Wiring

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Remote Sensor Wiring The remote sensor option permits the sensor to be mounted up to 100’ from the transmitter. Remote interconnect cable sold separately. The interconnections are shown below. Notes: ...

  • Page 21: Heated Sensor Wiring

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Heated Sensor Wiring (AC or VDC Powered) - Remote The heated remote sensor option requires an additional 2 wires between the transmitter and the remote junction box. The interconnections are shown below.

  • Page 22: Heated Remote Sensorw

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Heated Remote Sensor Wiring (2-Wire) The heated remote sensor option requires an additional 2 wires between the transmitter and the remote junction box. The interconnections are shown below. Notes:  Rx of the Transmitter must be connected to Tx of the Junction box ...

  • Page 23: Duct Mount Sensorw

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Duct Mount Sensor Wiring The Duct Mount Sensor option permits the sensor to be mounted into a process flowstream. Conductor Colors TB3 Pos Sensor Wires WHITE FROM SHLD BROWN RED & (2) DRAINS...

  • Page 24: Ac Or

    Part 3 – Electrical Connections Model F12/D Gas Transmitter Alarm Relay Boards (Option) The Alarm Relay board is available in both an AC powered and DC powered version. Each version features three SPST relays, an external remote alarm reset, and provides power to the transmitter and communication interface.

  • Page 25: 3.11 Relay Configuration

    Part 3 – Electrical Connections Model F12/D Gas Transmitter 3.11 Relay Configuration By default, RL1 and RL2 are under the control of the transmitter’s gas concentration alarms. The C (common) and NO (normally open) contacts of relays RL1 and RL2 are jumpered to TB3 and are open when their respective coils are de-energized (i.e., no gas alarm or no power).

  • Page 26: 3.14 Wiring Examples

    Part 3 – Electrical Connections Model F12/D Gas Transmitter 3.14 Wiring Examples ATI A17/B14 Receiver(s) Up to two transmitter/receivers may be connected to a single A17 power supply. 8 7 6 5 4 3 2 1 F12 P/S Board A17 Power Supply...

  • Page 27: Ac Or

    Part 3 – Electrical Connections Model F12/D Gas Transmitter 3.15 AC or 12-30 VDC Powered To Aux On Front Lid RS232/485 Supply (-) RS232/485 Supply (+) (L) 115/230 VAC (N) - Neutral (G) - Earth Ground (+) - 12-30 VDC...
  • Page 28 Part 3 – Electrical Connections Model F12/D Gas Transmitter To Aux On Front Lid CHART RECORDER DC version shown, But also applicable to AC version To J4a On Power Supply Figure 26 – Current Loop Output O&M Manual (Rev-H)

  • Page 29: Hart Point - To -Point

    Part 3 – Electrical Connections Model F12/D Gas Transmitter 3.16 HART Point-to-Point (2-Wire) The HART “Point-to-Point” connection permits the transmitter to communicate digitally, while retaining the functionality of its 4-20mA current loop. Setting the transmitter’s polling address to 0 permits the current loop to function normally.

  • Page 30: Communications Jumper

    Part 3 – Electrical Connections Model F12/D Gas Transmitter 3.17 Communications Jumper Setting Units with an optional communications interface use a jumper to select between RS-232, RS-485, and RS-485 with termination. The desired physical interface is set by positioning jumper JP5 as shown below.

  • Page 31: Part 4 - Operation

    Part 4 - Operation 4.1 Operator Interface Panel The F12/D operator interface is non-intrusive, so you do not have to remove the housing cover to view the display, configure the transmitter, or calibrate the sensor. It features a backlighted, transflective 96x32 dot LCD display and four panel keys.

  • Page 32: 4.2 Startup

    Part 4 – Operation Model F12/D Gas Transmitter While editing, the edit cursor changes its shape to provide feedback on which key is activate. Edit Active Saving Value Increasing Decreasing Enter Range = 50.0 Move the selection cursor in front of the setting’s label, and swipe the key.

  • Page 33: Sensor Review

    Part 4 – Operation Model F12/D Gas Transmitter Sensor Review Start (Same SIB) (New SIB) ATi Gas Xmtr ATi Gas Xmtr SIB-8-1-1 SIB-8-1-1 SIB–model-rev-id ► ►Verify SIB (Same Type Sensor) (New Type Sensor) (Sensor Missing) Sensor Trouble 24.2 H2S 24.2 H2S...

  • Page 34: Generator Review

    Part 4 – Operation Model F12/D Gas Transmitter Generator Review Start Gas number & name Gas Generator Output data 100 PPM H2S Usage data 0.00Hrs of 3.00 ► When the Auto-test status is READY, and no problems are detected with the...

  • Page 35: Main Display

    Part 4 – Operation Model F12/D Gas Transmitter 4.3 Main Display The Main Display Page shows the name and concentration of the target gas, and units of measurement (PPM, PPB, %, etc). Indicators on the left and below show alarm and operating status.

  • Page 36: Trouble Indication

    Part 4 – Operation Model F12/D Gas Transmitter Trouble Indication Main Display The Trouble alarm is indicated by four dashes appearing on the Main Display, along with the (!) flag in the lower left corner, and the 4-20mA status icon ---- indicating that the 4-20mA output is fixed (default = 3.6mA).

  • Page 37: Generator Removed

    Part 4 – Operation Model F12/D Gas Transmitter . If the types did not match, the review halts and waits for the operator to verify the new sensor’s full- scale range, and alarm settings. After verifying the sensor, the transmitter copies the sensor settings to its local memory.

  • Page 38: Enu

    Part 4 – Operation Model F12/D Gas Transmitter 4.5 Main Menu Main Menu >Menu The main menu provides direct access to the sensor calibration methods, data logger graph, and Menu transmitter settings. Zero Graph Span ►Setup Select to … Item...

  • Page 39: Menus , Methods , And Settings

    Part 4 – Operation Model F12/D Gas Transmitter 4.7 Sensor Menus, Methods, and Settings >Menu >Setup >Sensor Sensor Sensor Menu ►Settings Calibration Select to … Item Auto-test Configure the sensor range, damping, and blanking (see Settings Sensor Settings, below). Maintain the accuracy of the gas sensor (see Sensor Calibration on...

  • Page 40: Sensor Range Menu

    Part 4 – Operation Model F12/D Gas Transmitter …Settings>Range Menu Sensor Range Menu Settings ►Range= 50.0PPM Blank= 2.0PPM Select to … Item Damp.= Set the gas concentration value corresponding to the 20mA output value. Changing this value also changes the Blank (blanking) value, which is maintained as a fraction of the range.

  • Page 41: Sensor Calibration

    Part 4 – Operation Model F12/D Gas Transmitter Sensor Calibration Calibration Frequency While the transmitter itself requires no periodic calibration, H10 sensors should be “zero” and “span” calibrated every 3-6 months, based upon environmental factors. Sensors frequently exposed to dirt, oil mist, vapors, or very dry air, may require more frequent calibration.

  • Page 42: Sensor Calibration Menu

    Part 4 – Operation Model F12/D Gas Transmitter …Sensor>Calibration Sensor Calibration Menu Calibration ►Zero History Span Select to … Item Temp= 21.1°C Calibrate the gas sensor zero reading (below). Note – this item Zero also appears in the Main Menu (see Figure 39. Main Menu) Calibrate the gas sensor sensitivity (below).

  • Page 43: Figure 50. S

    Part 4 – Operation Model F12/D Gas Transmitter Sensor Span Calibration Span calibration* requires a bottled “span-gas” with a 500 cc/min regulator, calibration adapter, and a convenient length of ¼” tubing. The gas type and concentration used depends on the type of sensor installed.

  • Page 44: Figure 52. S

    Part 4 – Operation Model F12/D Gas Transmitter Sensor Calibration History A calibration record is written into the sensor memory each time a zero or span calibration is performed. Enough memory is reserved for 63 zero calibrations and 63 span calibrations. Zero and span calibration records are accessed on the Sensor Calibration History page.

  • Page 45: Sensor Auto-Test

    Part 4 – Operation Model F12/D Gas Transmitter Sensor Auto-test Auto-test verifies the serviceability of the sensor on a prescribed schedule by exposing it to a small amount of gas, and verifying a minimum response. Three attempts per test are made, and if the sensor does not respond on the third attempt, a temporary trouble alarm is triggered (may be optionally disabled).

  • Page 46: Figure 54. A

    Part 4 – Operation Model F12/D Gas Transmitter …Auto-test>Setup Auto-test Setup Menu Setup ►Day Interval= 1 Pass= 5PPM Select to … Item Options Configure the number of days between automatic tests. The Day Interval default is 1, and the limit is 1 to 14 (the exact time of day for testing may be set on the Next AT menu, see below).

  • Page 47: Figure 57. A

    Part 4 – Operation Model F12/D Gas Transmitter Auto-test History Menu The Auto-test History Menu provides a summary of passes, failures, and …Autotest>History retries, which are maintained in the sensor memory. Three attempts are made before a failure is recorded. The total number of tests is the sum of...

  • Page 48: Figure 59. G

    Part 4 – Operation Model F12/D Gas Transmitter Status = START Main Display  Status=OFF or READY  Update next Auto-test date  Resume normal operation Status = START MENU Auto-Test Status Display Time = 0 Auto-test Non-critical start exception ►WAIT...

  • Page 49: Enus , Methods , And Settings

    Part 4 – Operation Model F12/D Gas Transmitter 4.8 Alarm Menus, Methods, and Settings The transmitter features three gas level alarms - Alarm, Warning, and Caution, and a Trouble alarm. Gas level alarms are automatically configured when a gas sensor is installed, and are retained between same type sensors.
  • Page 50 Part 4 – Operation Model F12/D Gas Transmitter For oxygen sensors, Alarm is a low-low alarm set to 16%, Warning is a low alarm set to 19.5%, and Caution is a high alarm set to 23%. High Alarm Figure 63 depicts the relationships of these alarms.
  • Page 51 Part 4 – Operation Model F12/D Gas Transmitter Gas Alarm Operation Figure 64 illustrates the operation of a high (rising) gas level alarm. Set Level Res Level Set Delay Res Delay S e c o n d s Rdg at set level...

  • Page 52: Figure 67. A

    Part 4 – Operation Model F12/D Gas Transmitter Alarm Indicators Gas level alarms are indicated by three flags on the left side of the Main Display, each containing a letter indicating the alarm name, and an arrow indicating the type of alarm - high (rising) alarm, or low (falling) alarm.

  • Page 53: Figure 73. A

    Part 4 – Operation Model F12/D Gas Transmitter Alarm Setting Menus The Alarm Setting Menus are accessed from the Alarms Menu and are used to configure the three gas level alarms. >Menu>Setup>Alarms Alarms ►Alarm Inhibit Warning Test Caution …Alarms >Caution …Alarms>Alarm...

  • Page 54: Trouble Alarm

    Part 4 – Operation Model F12/D Gas Transmitter Select how the alarm is reset as Manu or Auto. When set to Auto, the alarm will Reset (clear) without operator intervention, as soon as conditions allow (concentration reaches Res Level, and the Res Delay period expires). When set to Manu, the...
  • Page 55 Part 4 – Operation Model F12/D Gas Transmitter Corrective Actions Prior to opening the transmitter housing:  Declassify the hazardous area - if the transmitter is located in a hazardous location.  Check connections and wiring outside of the transmitter for shorts or opens.
  • Page 56 Part 4 – Operation Model F12/D Gas Transmitter Table 2. Trouble Messages Trouble Description Corrective Action(s) Gas Signal Err The analog-to-digital converter channel assigned to the sensor’s gas concentration 1-3,4,6,8 output signal has failed, or is out of range. LCD Busy Error...
  • Page 57 Part 4 – Operation Model F12/D Gas Transmitter 3W Pwr Required Relays or RS232/485 communication is enabled, If relays are not being used, disable them but transmitter does not have 3-wire power (see Relays Menu on pg 71) applied. Xmtr Uncal The transmitter’s factory calibration data has...

  • Page 58: Alarm Inhibit

    Part 4 – Operation Model F12/D Gas Transmitter Alarm Inhibit Alarms are inhibited to temporarily disable (false) activation and should be re-enabled as soon as possible to maximize the safety of the area. The duration of inhibit period depends the method used to activate it.

  • Page 59: Alarm Test Menu

    Part 4 – Operation Model F12/D Gas Transmitter Alarm Test Menu …Alarms >Test The Alarm Test Menu can be used to test the gas level and Trouble alarms to verify operation of the associated relays (see Relay Operation, Menus, and Test Settings on page 70).

  • Page 60: Menus , Methods , And Settings

    Part 4 – Operation Model F12/D Gas Transmitter 4.9 Data-log Menus, Methods, and Settings The transmitter records gas concentrations in one of 12 intervals ranging from 1 to 60 minutes, providing data from 11 to 474 days. Table 4 details the sampling intervals, and the samples/day and totals days for each interval.

  • Page 61: Data Log Setup Menu

    Part 4 – Operation Model F12/D Gas Transmitter Data Log Setup Menu …DataLog>Setup Settings on the Data Log Setup page select one of the 12 discrete sampling intervals listed in Table 4, and control starting, stopping and clearing of the data-log.

  • Page 62: Figure 77. D

    Part 4 – Operation Model F12/D Gas Transmitter Table 5. Data Log Special Codes Special Code Description ---- Sample unavailable (transmitter powered off, or sample not yet recorded) FFFF Trouble alarm active at time of sample TEST Auto-test active at time of sample (if Log_Data=NO, see Auto-test Setup Options Menu)

  • Page 63: Data Log Print Menus, Methods, And Settings

    Part 4 – Operation Model F12/D Gas Transmitter Data Log Single View …DataLog>View>Single The Data Log Single View Menu allows scrolling to an exact date and time for viewing a single sample. ►Date= 07/09/14 Selecting Graph then presents the Graph view at the selected date and time.

  • Page 64: Figure 81. D

    Part 4 – Operation Model F12/D Gas Transmitter Data Log Print Menu The Data Log Print Menu appears by selecting Print from the Data Log Menu (pg 59). The data log must not be empty, and the communication protocol must be set to ASCII before entry (see 4.11 COM Menus on pg 66), or an exception message will be displayed.

  • Page 65: Enus , Methods And Settings

    Part 4 – Operation Model F12/D Gas Transmitter An RS232 connection can support full duplex communication and is perfectly suited for XON/XOFF flow control. However, an RS485 connection is only half duplex. It cannot receive while it is transmitting and might miss the XOFF character, resulting in a buffer overflow at the receiving device.
  • Page 66 Part 4 – Operation Model F12/D Gas Transmitter 4-20mA Menu During alarm inhibit and Auto-test, the 4-20mA output is fixed at 4.0mA (17.4mA for oxygen sensors) to …I/O>4-20mA prevent false alarms at the receiver. The output is forced to 3.6mA to signal a Trouble alarm to the ►Autotst mA= 4.0...

  • Page 67: Com Menus And Settings

    Part 4 – Operation Model F12/D Gas Transmitter …4-20mA>Adjust>Adjust 4mA Adjust 20mA Monitor the … ►DAC Count=13512 Select to … Item Scroll the DAC (digital-to-analog converter) count up to increase Menu>Setup>I/O>COM or down to decrease the analog output to 20.0mA.
  • Page 68 …COM>Setup ►Protocol=HART Interface=FSK Baud Rate=1200 Part 4 – Operation Settings= O,8,1 Model F12/D Gas Transmitter …COM>Setup COM Setup Menu ►Protocol=Modbus The COM Setup Menu is used to select the protocol and configure the transmitter’s connection settings. Interface=RS485 Baud Rate=9600 Select to …...
  • Page 69 Part 4 – Operation Model F12/D Gas Transmitter HART Menu …COM>HART The HART Menu appears by selecting HART from the COM Menu (pg 66). HART Tag=GAS XMTR ►Identification Select to … Item Operation This setting is read-only and can be used as a unique identifier for communicating to the transmitter.

  • Page 70: Figure 93. H

    Part 4 – Operation Model F12/D Gas Transmitter Fixed mA This setting provides direct access the associated HART network management setting. The value is adjustable only when the Loop setting is FIXED, and may be adjusted between 3.5 (4mA on 2-wire power) and 22 mA.

  • Page 71: Relay Operation, Menus, And Settings

    Part 4 – Operation Model F12/D Gas Transmitter More information about configuring the Modbus connection can be found in the table below. More Information… Where to find… Connect to a master using an RS485 multi-drop Figure 21 on page 23 connection.
  • Page 72 Part 4 – Operation Model F12/D Gas Transmitter Figure 95 illustrates the alarm and relay operation. Relay Logic Alarm (- - - user configurable) Logic Concentration (NO) (NO) (NC) 1 2 3 Sdly Set_Point Active ALARM RL3 Failsafe Res_Point Rdly...

  • Page 73: Menus , Methods , And Settings

    Part 4 – Operation Model F12/D Gas Transmitter …Relays>Setup Relay Setup Menu The Relay Setup Menu appears by selecting Setup from the Relays Menu above. Rly Coil Norm 1 ►Warning Alarm Select to … Item Trouble Change the alarm assigned to the relay coil. Selections Coil are ALARM, WARNING, CAUTION, or TROUBLE.

  • Page 74: Security Menu

    Part 4 – Operation Model F12/D Gas Transmitter Never On Off permanently Always On On permanently (not recommended) Figure 99. Display Menu Security Menu The transmitter prevents changes to the transmitter configuration through the front panel when security is active. Settings may be read, but not modified, and methods will not execute, including verifications during Sensor Review (see pg 32).
  • Page 75 Part 4 – Operation Model F12/D Gas Transmitter Activating Security The following display sequence appears when attempting to activate panel security. …Panel>Security Security ►Active= No Change Code …Security>Code Entry …Security>Code Entry Security Security Code= Code= Fail Enter code to . .
  • Page 76 Part 4 – Operation Model F12/D Gas Transmitter Deactivating Security The following display sequence appears when attempting to deactivate panel security. Note the option for automatically relocking the panel after a timed period. …Panel>Security Security ►Active= Yes Change Code …Security>Code Entry …Security>Code Entry...
  • Page 77 Part 4 – Operation Model F12/D Gas Transmitter Changing the Security Code The security code is changed by selecting Change Code from the Security Menu above. …Panel>Security Security Active= ►Change Code …Security>Change Code …Security>Change Code Security Security Code= Fail Old Code= Enter code to .

  • Page 78: Menu

    Part 4 – Operation Model F12/D Gas Transmitter 4.12 System Menu >Menu >Setup >System System ►Clock Site Reset Select to … Item Version Clock Set or update the transmitter’s real-time-clock. Restart the transmitter or change all user settings to default Reset values.

  • Page 79: Version Menu

    …Version>GasGen GasGen C18-g/n-id Part 4 – Operation Hw=xxxx/Sw=xxxx Model F12/D Gas Transmitter Version Menu …Version>SIB The Version Menu appears by selecting Version from the System Menu above and lists the major components of the transmitter as menu entries. SIB-m/n-ver-id Hw=xxxx/Sw=xxxx Select to …...

  • Page 80: Part 5 - Maintenance

    Part 5 – Maintenance The F12/D is virtually maintenance free. Other than the consumable sensor and auto-test generator, the battery backup for the real time clock is the only other user replaceable part. Real Time Clock Battery Replacement WARNING: Disconnect power, and move unit to a non-hazardous area before servicing.
  • Page 81 Part 5 – Maintenance Model F12/D Gas Transmitter 3. Remove the Internal Shield by removing the three screws (4) 4. Remove the Terminal PCB by pulling straight up, to expose the CPU PCB (5). 5. Remove the Battery (6), and replace with same kind.

  • Page 82: Part 6 - Spare Parts

    GAS TRANSMITTER Figure 108 - Exploded View Part No. Description 03-0477 F12/D Transmitter Front Lid Assembly 03-0479 F12/D Transmitter Front Lid Assembly w/ HART 00-1699 F12 Sensor Holder Assembly (heated) 00-1700 F12 Sensor Holder Assembly 03-0332 Standard Sensor Cap 00-1698...
  • Page 83 Part 6 – Spare Parts Model F12/D Gas Transmitter Table 7. H10 sensor modules Part No. Description 00-1000 Bromine, 0-1/5 PPM (2 PPM Standard) 00-1001 Bromine, 0-5/200 (20 PPM Standard) 00-1002 Chlorine, 0-1/5 PPM (2 PPM Standard) 00-1003 Chlorine, 0-5/200 (20 PPM Standard)
  • Page 84 Part 6 – Spare Parts Model F12/D Gas Transmitter 00-1358 Ozone, 200/1000 PPM (1000 PPM Standard) 00-1359 Chlorine dioxide, 200/1000 PPM (1000 PPM Standard) 00-1425 Chlorine dioxide, 1/5 PPM (low Cl2 response) 00-1450 Dimethylamine (DMA), 100/200 PPM (100 PPM Standard)
  • Page 85 Part 6 – Spare Parts Model F12/D Gas Transmitter PRODUCT WARRANTY Analytical Technology, Inc. (Manufacturer) warrants to the Customer that if any part(s) of the Manufacturer's products proves to be defective in materials or workmanship within the earlier of 18 months of the date of shipment or 12 months of the date of start-up, such defective parts will be repaired or replaced free of charge.
