ATI Technologies D12-17 O & M Manual

% lel gas transmiter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Home Office
Analytical Technology, Inc.
6 Iron Bridge Drive
Collegeville, PA 19426
Phone: 800-959-0299
610-917-0991
Fax:
610-917-0992
Email: sales@analyticaltechnology.com
Web: www.Analyticaltechnology.com
-0992
O & M Manual
D12-17
% LEL Gas Transmiter
Fax:
+ 44 (0)1457-874-468
European Office
ATI (UK) Limited
Unit 1 & 2 Gatehead Business Park
Delph New Road, Delph
Saddleworth OL3 5DE
Phone: +44 (0)1457-873-318
Fax:
+ 44 (0)1457-874-468
Email: sales@atiuk.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D12-17 and is the answer not in the manual?

Questions and answers

Related Manuals for ATI Technologies D12-17

Summary of Contents for ATI Technologies D12-17

  • Page 1 O & M Manual D12-17 % LEL Gas Transmiter Home Office European Office Analytical Technology, Inc. ATI (UK) Limited 6 Iron Bridge Drive Unit 1 & 2 Gatehead Business Park Collegeville, PA 19426 Delph New Road, Delph Phone: 800-959-0299 Saddleworth OL3 5DE...

  • Page 2: Table Of Contents

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Main Display Page ............26 Five-minute Time-out Rule ..........26 Esc Key Operation (Main Display Page) ......26 Table Of Contents Fault Indication (Main Display Page) ......... 26 Main Reading ..............27 Variable Editing ..............
  • Page 3 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Data-log Printout ............... 57 SPARE PARTS ________________________ 67 DISPLAY ..............58 Display Setup Page ............58 APPENDIX A. _________________________ 68 SYSTEM ..............59 ........68 RINTING EPORTS System Access Page ............59 Serial Connection.............

  • Page 4: Introduction

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor INTRODUCTION COMPONENTS D12 GAS Transmitter D12 LEL Transmitter The D12 LEL Transmitter is used to monitor for gas leaks near storage cylinders, process piping, or gas feed equipment in virtually any type of industrial plant environment.

  • Page 5: Gas Mixtures

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor The sensor elements a re c omb ined to form a Whea tsto ne b rid g e, a s show n in Reference Figure 4. Gas concentration is computed in proportion to the voltage developed across the bridge, which is read by Bridge transmitter’s CPU.

  • Page 6: Multiple Gas Safety

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Multiple Gas Safety Due to differences in LEL and oxidation rates between gases, it is usually best to avoid situations where the sensor may be exposed to more than one combustible gas at the same time. In situations where it cannot be avoided, the sensor should be calibrated to provide the highest margin of safety.

  • Page 7: Specifications

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor SPECIFICATIONS Ta ble 1. Specifications Gas Type Combustible gas such as Methane, Propane, Butane, plus many more, including Ammonia and Hydrogen Sensor Type Catalytic bead for combustible gas, 316 stainless steel housing 50 –...

  • Page 8: Installation

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor INSTALLATION MECHANICAL MOUNTING Transmitter Figure 5 shows the HAZARDOUS LOCATIONS dimensions of the transmitter enclosure and Connect housing to earth ground. Use explosion the location and size of proof conduit, and seal it inside and out. Follow national, state, and local, electrical codes.

  • Page 9: Figure 5. Overall Dimensions-Non Autotest Version (Ati-0587)

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor D12 GAS TRANSMITTER Fig ure 5. Overa ll Dimensions-Non Autotest Version (ATI-0587) D12 GAS TRANSMITTER Fig ure 6. Overa ll Dimensions- Autotest Version (ATI-0588) Revision J (July 15)

  • Page 10: Electrical Connections

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor ELECTRICAL CONNECTIONS The Stack The transmitter consists of three circuit boards, known collectively as the “stack”. From top to bottom, they are the, Display, CPU, and Power Supply. The top two boards, Display and CPU, are fastened together with metal standoffs, and plug into the Power Supply board, which is fastened to the lower housing with similar metal standoffs.

  • Page 11: Power Supply Board

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Power Supply Board Electrical connections are made to terminal blocks TB1 and TB2. The 4-20mA current loop, optional digital communications, and remote alarm reset, are connected at TB1. Connections to the three optional relays are made at TB2.

  • Page 12: Relay Contacts

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Relay Contacts Note: the behavior described below is determined by the default relay settings, which may be reprogrammed through the operator or communication interface. By default, RL1 is de-energized until the gas concentration reaches the Warning level, and is then energized until the alarm is cleared, or power fails.

  • Page 13: Wiring Examples

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Wiring Examples ATI A17/B14, 3-Wire Mode A single ATI A17 Power Supply may be used to power one ATI B14 Receiver with single D12-17 transmitter, as shown below. Fig ure 10. ATI A17/ B14 Exa mp le...

  • Page 14: Power Without 4-20Ma Signaling

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Power Without 4-20mA Signaling Power without 4-20mA signaling is not common practice, except when signaling digitally over HART multidrop and Modbus connections. There are several examples of those in the pages that follow. When 4-20mA signaling is not used, the transmitter may be powered from TB1-5,6,7,and 8, which are connected directly to the supply (note 1).

  • Page 15: 4-20Ma Signaling, Single Supply, 3-Wire Mode

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor 4-20mA Signaling, Single Supply, 3-Wire Mode The transmitter will source current to a loop receiver as shown. A single power supply provides both primary and loop power to the transmitter. Size each power supply according to the number of transmitters, the current demand of each (see specifications), and the wire resistance.

  • Page 16: 4-20Ma Signaling, Dual Supply, 4-Wire Mode

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor 4-Wire Mode 4-20mA Signaling, Dual Supply, To reduce the power requirement of a single current loop supply, the transmitter may be powered from both a primary and loop supply, providing the following conditions are met. 1.

  • Page 17: Hart Transmitter, Point-To-Point, 3-Wire (Active Source)

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor 3-Wire (Active Source) HART Transmitter, Point-to-Point, The HART “Point-to-Point” connection permits the transmitter to communicate digitally, while retaining the functionality of its 4-20mA current loop. Setting the transmitter’s polling address to 0 permits the current loop to function normally.

  • Page 18: Hart Transmitter, Multi-Drop, 3-Wire (Active Source)

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor 3-Wire HART Transmitter, Multi-drop, (Active Source) The HART “Multi-drop” connection permits up to 15 transmitters to communicate digitally on the same bus, but at the cost of analog current signaling. Setting the transmitter’s polling address from 1 to 15 fixes the current loop output at 4mA.

  • Page 19: Rs485 Modbus Multidrop

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor RS485 Modbus Multidrop RS485 operation requires the transmitter to be wired in 3- or 4- wire mode. In addition, the RS485 or RS485 UNTERMINATED COM jumper must be installed at JP4 on the CPU. Modbus permits up to 247 devices to communicate digitally on the same bus;...

  • Page 20: Rs232 Modbus, Pc Capture, Or Printer

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor RS232 Modbus, PC Capture, or Printer RS232 operation requires the transmitter to be wired in 3- or 4- wire mode. In addition, the RS232 COM jumper must be installed at JP4 on the CPU board. The RS232 connection may be used for a Modbus connection, capturing the data log output using a PC, or printing the data log output to an Epson compatible printer.

  • Page 21: Remote Sensor Wiring

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Remote Sensor Wiring The remote sensor option allows separation of the sensor and transmitter by up to 25 feet. The sensor is threaded into a junction box, and connected to the transmitter using a supplied cable, which may be shortened, if necessary.

  • Page 22: Cpu Board Configuration

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor CPU Board Configuration Install one jumper plug Pin 1 Jumper block on JP4 on JP4 as prescribed by (see table above) communication interface. I M P O R T A N T Note location of pin 1 After re-installing the transmitter board stack, set...

  • Page 23: Operation

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor OPERATION OPERATOR INTERFACE Interface Panel The D12 operator interface is non-intrusive, so you do not have to remove the housing cover to view the display, configure the transmitter, or calibrate the sensor. It features a backlighted*, 96x32 dot LCD display, and four “keys”.

  • Page 24: Startup Review Sequence

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Startup Review Sequence When the transmitter starts, the display cycles through a series of pages to review the configuration of the transmitter, sensor, and generator. Alarms are inhibited, and the output of the transmitter is held at 4.0 mA.

  • Page 25: Main Display Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Main Display Page The Main Display Page shows the name and concentration of the target gas, and units of measurement (PPM, PPB, %, etc). Indicators on the left and below show alarm and operating status. Indicates concentration Main Reading High Alarm Active Flag...

  • Page 26: Main Reading

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Main Reading The main reading represents the gas concentration value and appears on the Main Display, along with the sensor name, and units of concentration. It is reported on the 4-20mA output , and is the PV (Primary Variable) reported on the optional HART™...

  • Page 27: Variable Editing

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Variable Editing When a variable is selected, the edit cursor appears. The shape of the cursor symbolizes the up-down scroll nature of the value being edited. To provide feedback about which key is being activated, the cursor changes to a solid up-arrow when the magnet is touching the Up key, and to a solid down-arrow when the magnet is touching the Down key.

  • Page 28: Sensors And Generators

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Sensors and Generators The transmitter offers several pages for accessing and configuring the combustible sensor and its optional gas generator. Neither sensors nor generators have local memory; therefore, all settings are stored in the transmitter memory.

  • Page 29: Sensor More Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Sensor More Page >Menu >Setup >Sensor >More ►Cal_History Test_History Fig ure 27. Sensor “ more” p a g e Ta ble 4. Sensor “more” variables Variables Description Cal_History Cal_History is a link to the Calibration History page (see Sensor Calibration Records ).

  • Page 30: Bump-Testing

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Bump-Testing “Bump-testing” refers to a test whereby the sensor is briefly exposed to gas in order to verify the reading moves upscale from zero. It is recommended that it be performed at least once a month, using a small amount of bottled span gas.

  • Page 31: Calibration

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Calibration Calibration Frequency While the D12 transmitter requires no periodic calibration, Combustible sensors should be zero and span calibrated every 3-6 months. The frequency of calibration may depend on environment factors. Sensors frequently exposed to dirt, oil mist, vapors, or very dry air, may require more frequent calibration.

  • Page 32: Zero Calibration Procedure

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Zero Calibration Procedure Performing a zero calibration requires a cylinder of Zero-Air with a 500 cc/min regulator, calibration adapter, and a convenient length of ¼” D12 GAS Transmitter tubing. Referring to Figure 28, screw the calibration adapter onto the exposed end of the sensor and connect one end of the tubing (1), connect the other end of tubing to the cylinder’s...

  • Page 33: Span Calibration Procedure

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Span Calibration Procedure Span calibration* requires a cylinder of “span” gas with a 500 cc/min regulator, calibration adapter, and a convenient length of ¼” tubing. Referring to Figure D12 GAS Transmitter 30: screw the calibration adapter onto the exposed end of the sensor and connect one end of the tubing (1), connect the other end of tubing to the cylinder’s...

  • Page 34: Spanning For Otm Gases (Other Than Methane)

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Spanning for OTM Gases (Other Than Methane) Because the combustible gas sensor is normally calibrated for Methane, differences in the LEL and oxidation rates of other gases may lead to reading errors. These errors may be corrected by recalibrating the sensor span.

  • Page 35: Sensor Calibration Records

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Sensor Calibration Records A calibration record is written into the sensor memory each time a zero or span calibration is performed, and when a calibration Undo is performed. Enough memory is reserved for 63 zero calibrations and 63 span calibrations.

  • Page 36: Auto-Test

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Auto-test The Auto-test option requires the Combustible Sensor with the Auto-test Gas Generator. Auto-test verifies the serviceability of the transmitter on a prescribed schedule by exposing the sensor to a small amount of gas, and verifying a minimum response.

  • Page 37: Auto-Test Control Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Auto-test Control Page Auto-test is controlled by the Status variable, which appears on the Auto-test page shown below. >Menu >Setup >Auto-T ►Status=OFF Setup NextAT GasGen Fig ure 34. Auto -test c ontrol p a g e History Ta ble 6.

  • Page 38: Auto-Test Setup Options Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Auto-test Setup Options Page The Auto-test Setup Options page variables control the behavior of the >Menu>Setup>Auto-T>NextAT transmitter during Auto-test. ►Log_Data=YES Cause_Fault=YES Override_mA=YES Variables Description Log_Data The Log_Data variable controls values logged during Auto-test. When set to YES (default), the gas concentration (main reading) is logged as usual, including any increase caused by the gas generator.

  • Page 39: Auto-Test History Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Auto-test History Page The Auto-test History page provides a summary of passes, failures, and >Menu>Setup>Auto-T>History retries, which are maintained in the sensor memory. Since three Passes= attempts are made, there are always two retries before a failure is Failures= recorded.

  • Page 40: Figure 36. Auto-Test Sequence

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Main Display %LEL Combustible MENU Auto-Test Page Retry every minute for AUTO TEST 1 hour and 30 minutes. ►Start 00:00 Reading= 0%LEL Message Page Main Display Gas Conc PLEASE NOTE Concentration … %LEL Greater Than Combustible...

  • Page 41: Alarms And Relays

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor ALARMS and RELAYS Alarms are standard in the D12 transmitter, regardless of the optional relays. The alarm status indicators appear on the Main Display, and status is available over the optional serial interface. Alarms may be assigned to activate one or more of the three optional relays, which are discussed below in Alarm Relays.

  • Page 42: Gas Alarm Setup Pages

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Gas Alarm Setup Pages Variables for the gas alarms are configured on the respective setup pages, as shown in Figure 39, and described in Table 8. ►Alarm Relays Warning Setup Caution Test Inhibit >Caution...
  • Page 43 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Ta ble 8. Alarm varia bles Variable Description Active The Active variable is used to specify the concentration range where the alarm is active. When set to ABOVE_SP, the alarm becomes active at and above the set point (referred to as a rising alarm).
  • Page 44 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Reset The Reset variable defines how the alarm is permitted to transition from active, to inactive. When the variable is set to AUTO, the alarm will transition without operator intervention, as soon as conditions permit (concentration reaches the reset point, and the reset delay period expires).

  • Page 45: Alarm Variable Functions

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Alarm Variable Functions Figure 40 depicts relationships between variables associated with a rising gas alarm, and how they function in the presence of a gas leak, and recovery. Set_Point Res_Point Set_Delay Res_Delay S e c o n d s Conc.

  • Page 46: Fault Alarms

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Fault Alarms When a fault alarm occurs, the Main Display appears as shown below. By default, new alarms are inhibited, and active alarms are held so that relays controlling lights, sirens, and fans may continue to operate (this behavior may be modified on the Alarms Setup pages).
  • Page 47 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor SPI Bus Error Serial peripheral interface bus has faulted. 1. Cycle power off and on 2. Replace upper stack 3. Replace full stack ADC1 Read Error The analog-to-digital converter channel 1. Cycle power off and on assigned to the sensor’s temperature output 2.
  • Page 48 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Autotest Failed Auto-test failed after 3 attempts. 1. Replace generator 2. Replace sensor 3. Replace upper stack 4. Replace full stack Use 3-Wire Power Relay option jumper is installed, but 1. If relays are not used, remove transmitter is powered from loop (2-wire).

  • Page 49: Alarm Relays

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Alarm Relays The D12 transmitter provides three optional SPDT mechanical relays rated for 5 amps, non-inductive loads at 250VAC. These relays are suitable for switching small loads, such as horns and warning lights, but should not be used to switch motors or other high current, inductive loads.

  • Page 50: Relay Setup Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Relay Setup Page Relays are configured in the Relays Setup page, which is accessed by selecting Menu, Setup, Alarms, and (Relays) Setup. Select the alarm trigger source (Alarm, Warning, Caution, Fault), and failsafe property (Normal-On or Normal-Off).

  • Page 51: Inhibiting Alarms

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Inhibiting Alarms Alarms should be inhibited to prevent false activation, such as done just prior to “bump-testing” the sensor. The most convenient method for temporarily inhibiting alarms is from the Main Display. Hold the magnet over the ESC key for 2 seconds, and remove it.

  • Page 52: M A Output

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor 4-20mA Output The 4-20mA output normally sources positive current to a receiver, proportional to the main 4-20mA Output reading. The output is 4 mA at zero, and rises to 20mA at the full-scale range (see “Range” variable in Sensor Setup Page), and may go as high as 24mA (125%LEL) in case of gas flooding.

  • Page 53: 4-20Ma Control Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor 4-20mA Control Page The 4-20mA Control page permits adjustment of the analog output, and provides a method for manually forcing it to a fixed value to overcome leakages, verify linearity, or test receiver alarms. >Menu >Setup >4-20mA >More ►Adjust_4mA Adjust_20mA...

  • Page 54: Data Log

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor DATA LOG The D12 transmitter data log records gas concentration in one of 12 discrete intervals ranging from 1 to 60 minutes, providing data from 11 to 474 days. Table 13 details sampling intervals and the associated metrics.

  • Page 55: Data-Log Graphic Report Page

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Data may be displayed on the LCD graphically, or in a tabular report format. Data may also be output to a terminal, terminal program, or serial printer. Dates formats are configurable as MM/DD or DDMMM (see System Clock), and samples are displayed in the concentration units shown on the Main Display Page.

  • Page 56: Data-Log Printout

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Upon entry, the Date, Time, and Conc variables are set to the most recent sample. Scrolling the Time variable up increments it by the sampling interval, and causes the next, successive sample to be displayed at Conc.

  • Page 57: Display

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor DISPLAY The D12 Transmitter features a backlighted, 96w x 32h graphics LCD. Display Setup Page The Display Setup page variables are used to control the display >Menu >Setup >Display contrast, and manage the backlight. ►Contrast= Light= MANUAL Ta ble 16.

  • Page 58: System

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor SYSTEM System pages provide version information and configure the internal clock, security access, communication protocols, and to reset various memory defaults. System Access Page The System Access page provides links to the clock, security, >Menu >Setup >System communications, and version pages (the Reset link has been replaced ►Clock...

  • Page 59: Security

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Security The transmitter protects its configuration using a 4-digit, numeric password, from 0000 to 9999. When security is active, the “S” status indicator appears on the Main Display, variables may be read, but not modified, and functions will not execute, including the sensor verification function during startup review.

  • Page 60: Deactivating Security

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Deactivating Security The procedure to deactivate security is identical to that used for activating it, and if successful, the transmitter presents an option to automatically reactivate it after a timed interval. >Menu>Setup>System>Secure Password Entry Page Password Entry Page...

  • Page 61: Communications

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Communications The D12 Transmitter supports ASCII, HART 5, and Modbus communications. ASCII is the default protocol if the HART or Modbus option is not ordered. Communication Setup Page Communication Setup page variables are used to configure the Menu>Setup>System>Commun protocol and settings of the physical communication interface.

  • Page 62: Ascii

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Protocol specific settings are configured on separate pages that are accessible from links on the Setup page, and are discussed below. ASCII ASCII is used for sending the data log to a serial printer, terminal, or terminal program, using RS232 (RS485 might be used under certain conditions).

  • Page 63: Figure 66. Hart A) Find-Me And B) Device Found

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Poll_Addr The Poll_Addr variable sets the polling address of the transmitter. The default value is 0, which allows the transmitter to communicate digitally, while preserving the function of the 4-20mA output. The value may be set from 1 to 15, which fixes the output at 4mA, and disables analog signaling.

  • Page 64: Modbus

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Modbus Modbus is a master/slave protocol that supports a single master, and up to 247 slave devices on a common bus. The RS485 interface physically limits this number to 32 (1 master, 31 slaves), and RS232 restricts communication to a master and a single slave.

  • Page 65: Restart

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Restart The Restart function will cause the transmitter to start up, just as it does during a power-on-reset. This function replaces the Reset page beginning with version 2.23 of the D12 Combustible Gas Transmitter with Catalytic Bead sensor.

  • Page 66: Spare Parts

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor SPARE PARTS D12 GAS TRANSMITTER Ta ble 21. Spare parts Part No. Description 03-0231 PCB stack assembly (without Relays) 03-0232 PCB stack assembly (with Relays) 00-0258 Calibration adapter (Non-Autotest Version) 45-0081 Splash guard (Autotest Version) 00-0261 Remote Calibration Adapter / Rain Shield (Non-Autotest Version)

  • Page 67: Printing Data Log Reports

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Appendix A. Printing Data Log Reports The following pages describe how to send a data-log report to a printer or computer, over a serial RS232 connection, and to import that data into Microsoft Excel for plotting. Serial Connection The data log report may be sent to a printer or a computer over an RS232 connection, or in some cases, an RS485 connection.

  • Page 68: Report Format

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Report Format The format of the report is suitable for import into most spreadsheet programs and consists of a date column, a time column, and 1-30 columns for sample values. Each line of the report shows the date and time of the first sample.

  • Page 69: Example: Charting A Data Log Report

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Example: Charting a Data Log Report Start HyperTerminal by clicking Start, pointing to Programs, pointing to Accessories, pointing to Communications, clicking HyperTerminal, and then double-clicking Hypertrm.exe. When the Connection Description dialog box appears, type in Connect To D12. If you wish, choose an icon by sliding the horizontal scroll bar over and clicking one of the selections.
  • Page 70 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor When the COM1 Properties dialog box appears, configure the Port Settings as shown below and click Click View, then click Font and configure the font settings as shown. This will insure that the data is presented in the terminal window without wrapping from line to line.
  • Page 71 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Click File, then click Save As, and click the Save button to store the settings as a HyperTerminal session file named Connect To D12.ht (the filename should automatically appear). You may later place this file on your desktop and simply click it to get this point automatically.

  • Page 72: Starting The Report

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor HyperTerminal is now ready to accept a report from the D12 transmitter and save it in a file. Note that data may appear in the terminal window (shown below) if the Connect To D12 session has been run previously, but this data will not appear in the file just opened.
  • Page 73 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Navigate to the DataLog page and select Print. You will not be allowed access if there are no samples in the log. >Menu >Setup >Menu >Setup >DataLog Sensor ►DataLog Setup Alarms Display Review_Tabular Auto-T...
  • Page 74 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor The HyperTerminal terminal window should now begin to fill with lines from the report. 07/13/2006 00:00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 07/13/2006 00:10 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 07/13/2006 00:20 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 07/13/2006 00:30 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 07/13/2006 00:40 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00...

  • Page 75: Charting With Microsoft Excel

    Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Charting with Microsoft Excel Microsoft Excel can be used to import data log reports and create useful and informative charts. Start Excel by clicking Start, pointing to Programs, and clicking Microsoft Excel. When Excel opens, click File and then click Open.
  • Page 76 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor When the Text Import Wizard – Step 2 of 3 appears, configure the settings as shown below and click Next. When the Text Import Wizard – Step 3 of 3 appears, click Finish. Revision J (July 15)
  • Page 77 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor The report should appear as a spreadsheet resembling the format shown below. Of course the dates, times, and values will be different. Revision J (July 15)
  • Page 78 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor To chart the report, select one full day of data by dragging the mouse cursor over the region to be charted. Notice that this region begins in the time of day column and extends across each of the sample columns.
  • Page 79 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor After selecting the region, click Insert and then Chart (or click the Chart icon directly from the toolbar). When the Chart Type dialog appears, click on Column, and click Next. Revision J (July 15)
  • Page 80 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor When the Chart Source Data dialog appears, click Next. Revision J (July 15)
  • Page 81 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor When the Chart Options dialog appears, click off the Show legend option, and click Next. When the Chart Location dialog appears, click the As new sheet radio button and enter the name of a new sheet to store the chart in.
  • Page 82 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor If you have previously clicked the As new sheet radio button, the chart will appear on the new sheet named above. You may now move between the new sheet and the old sheet by clicking the sheet tabs that appear just below the chart display.
  • Page 83 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor If you have previously clicked the As object in: radio button, the chart will appear on the existing sheet. Finally, click File, then Save to store the chart. Once the chart has been created, you may wish to rescale it, title it, and print it. These features are detailed in Microsoft Excel Help and are beyond the scope of this document.
  • Page 84 Series D12 LEL Gas Transmitter with Catalytic Bead Sensor Product Warranty Analytical Technology, Inc. (Manufacturer) warrants to the Customer that if any part(s) of the Manufacturer's equipment proves to be defective in materials or workmanship within the earlier of 18 months of the date of shipment or 12 months of the date of start-up, such defective parts will be repaired or replaced free of charge.
