- Page 1 S O L S T I C E Home Theater Seating A S S E M B LY & G E N E R A L U S E G U I D E 2260-E Rev. 4-13-2018...
-
Page 2: Table Of Contents
Table of Contents What’s Inside the Box Step 1: Connect the Power Headrest and Lumbar Cables Step 2: Attach the Backrest to the Seat Base Step 3: Connect the Power Cable Step 4: Attach the Tray Table Using the Power Control Panel Troubleshooting Guide 8-10 Seat Part List... -
Page 3: What's Inside The Box
What’s Inside the Box 1. BACKREST 2. SEAT 3. RED BAG (Includes: Power Adapter & Power Adapter Cable) 1. BACKREST 2. SEAT 3. RED BAG PAGE 2... -
Page 4: Step 1: Connect The Power Headrest And Lumbar Cables
STEP 1 Connect the Power Headrest and Lumbar Cables Connect the Powered Headrest Female Cable to the Powered Headrest Male Cable. Connect the Powered Lumbar Female Cable to the Powered Lumbar Male Cable. Lock both cables together. PAGE 3... -
Page 5: Step 2: Attach The Backrest To The Seat Base
STEP 2 Attach the Backrest to the Seat Base Slide the Backrest Female Brackets onto the Backrest Male Brackets. Push until you hear a click on both sides. This will indicate that the backrest is secured. PAGE 4... -
Page 6: Step 3: Connect The Power Cable
STEP 3 Power Adapter Power Adapter *SoundShaker Cable Cable Optional Connect the Power Cable Plug the Power Adapter Cable into the Power Adapter. Connect the Power Adapter to the Power Recline Cable. Lock the two cables together. PAGE 5... -
Page 7: Step 4: Attach The Tray Table
STEP 4 Attach the Tray Table Open the in-arm storage to find your Tray Table. Place the Tray Table into the accessory mount. PAGE 6... -
Page 8: Using The Power Control Panel
Using the Power Control Panel A M B I E N T M E M O R Y L I G H T H O M E B U T T O N U S B C H A R G I N G P O R T P O W E R E D P O W E R E D... -
Page 9: Troubleshooting Guide
Troubleshooting Guide Why isn’t my chair reclining? The Power Adapter has become loose or disconnected. Unplug and re-plug in the The green light on the Unplug and re-plug in Power Adapter to a wall Power Adapter should be the Power Adapter to the outlet. - Page 10 Troubleshooting Guide Why isn’t my chair’s power lumbar functioning? The Powered Lumbar Cables have become loose or disconnected. Unplug and re-plug Unplug and re-plug in The green light on the Unplug and re-plug in the Powered Lumbar the Power Adapter to Power Adapter should the Power Adapter to Cables to each other.
- Page 11 Troubleshooting Guide How do I remove the backrest from the seat base? The Backrest Female Bracket has a locking tab. Pull up on the locking tab on the Backrest Female Bracket and firmly pull the backrest upward. Where do I connect the SoundShaker cable? Connect an optional SoundShaker amplifier kit to the SoundShaker cable.
-
Page 12: Seat Part List
Seatcraft Solstice with Power Recline Seatcraft Solstice with Power Recline Double Arm Home Theater Seat 2260-E 2260-3E PRODUCTION DATE: 5/1/2017 - CURRENT POWER HEADREST MECHANISM ARMREST ALIGNERS BRACKET OF KD BACKREST FEMALE BRACKET PT-P14-L & PT-P14-R PT-1412630001 PT-EAS16001 HINGE FOR ARMREST... -
Page 13: Warranty Info & Contact Information
Warranty Information Seatcraft is proud of its high standards of quality and workmanship that go into our products. The customer is protected by the following Limited Warranty, which applies to seats under normal indoor residential use. This warranty does not apply to seats used for commercial, institutional, or other non-residential uses.
