- Page 1 R A L E I G H W I T H M A N U A L R E C L I N E Home Theater Seating A S S E M B LY & G E N E R A L U S E G U I D E 2175 Rev.
-
Page 2: Table Of Contents
Table of Contents What’s Inside the Box Step 1: Attach the Backrest to the Seat Base Step 2: Connect the Power Cable Step 3: Attach the Tray Table Using the Manual Control Panel Troubleshooting Guide Seat Part List Proposition 65 Information Important Safety Instructions Warranty Info &... -
Page 3: What's Inside The Box
What’s Inside the Box 1. BACKREST 2. SEAT 3. RED BAG (Includes: Power Adapter & Power Adapter Cable) 1. BACKREST 2. SEAT 3. RED BAG PAGE 2... -
Page 4: Step 1: Attach The Backrest To The Seat Base
STEP 1 Attach the Backrest to the Seat Base Slide the Backrest Female Brackets onto the Backrest Male Brackets. Push until you hear a click on both sides. This will indicate that the backrest is secured. PAGE 3... -
Page 5: Step 2: Connect The Power Cable
STEP 2 Power Adapter Power Adapter Cable Connect the Power Cable Plug the Power Adapter Cable into the Power Adapter. Connect the Power Adapter to the Power Recline Cable. Lock the two cables together. PAGE 4... -
Page 6: Step 3: Attach The Tray Table
STEP 3 Attach the Tray Table Place the Tray Table into the accessory mount. PAGE 5... -
Page 7: Using The Manual Control Panel
Using the Power Control Panel A M B I E N T M A N U A L L I G H T R E C L I N E U S B C H A R G I N G P O R T AMBIENT LIGHT CONTROL Push to turn the ambient base lighting and the lighted cupholders on or off. -
Page 8: Troubleshooting Guide
Troubleshooting Guide How come the lights on my cupholder or seat base are not lighting up? The Power Adapter has become loose or disconnected. Unplug and re-plug in the The green light on the Unplug and re-plug in Power Adapter to a wall Power Adapter should be the Power Adapter to the outlet. -
Page 9: Seat Part List
Seatcraft Raleigh with Manual Recline Seatcraft Raleigh with Manual Recline Double Arm Home Theater Seat 2175 2175-3 PRODUCTION DATE: 5/1/2017 - CURRENT BACKREST BRACKET (FEMALE) PT-LP-1412630001 CUP HOLDER INSERT LIGHTED CUPHOLDER SILICONE SC LOGO PT-LCH-402B PT-CHI-24 LIGHTED CUPHOLDER PT-LCH-402B Backrest... -
Page 10: Proposition 65 Information
Proposition 65 Information What is Proposition 65? You might have seen Proposition 65 warning labels at hotels, banks, restaurants, and even at theme parks. Proposition 65 is a California law that requires warning labels on products that may contain one of more than 800-plus chemicals or ingredients that the California Office of Environmental Health Hazard Assessment (OEHHA) has deemed to cause cancer or other reproductive toxicity. -
Page 11: Important Safety Instructions
• Do not use Seatcraft furniture in a recreational vehicle • Do not stand, sit or place extra weight on the arms, back (or other moving vehicles) while the vehicle is in motion. -
Page 12: Warranty Info & Contact Information
Warranty Information Seatcraft is proud of its high standards of quality and workmanship that go into our products. The customer is protected by the following Limited Warranty, which applies to seats under normal indoor residential use. This warranty does not apply to seats used for commercial, institutional, or other non-residential uses.
