Range Road RR5022, RR5026, RR5029 & RR5032
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before
operating. Failure to follow the safety rules and other basic safety precautions may result in
serious personal injury.
Range Road Enterprises Ltd
Box 944
Eckville AB T0M 0X0
www.range-road.ca
Saw Mill
Owner's Manual

Advertisement

Table of Contents
loading

Summary of Contents for Range Road RR5022 Series

  • Page 1 Range Road RR5022, RR5026, RR5029 & RR5032 Saw Mill Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
  • Page 2: Intended Use

    INTENDED USE The Range Road Saw Mill is portable and versatile which makes it a great tool for any lumber project. It has the capabilities of sawing logs up to 22”, 26” or 29” in diameter, 7” thick and a cutting length of 125”.
  • Page 3: Work Area

    Store idle saw mill. When saw mill is not in use, store it in a secure place out of the reach of children. Inspect it for good working condition prior to storage and before re-use. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 4: Important Safety Information

    Engine exhaust contains carbon monoxide. This is a poison you cannot see or smell. NEVER use gas engines indoors EVEN IF doors and window are open. Only use OUTSIDE and far away from windows, doors and vents. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 5 Caution is necessary when near the engine’s magneto or recoil starter. 6) Use only accessories that are recommended by Range Road for your model. Accessories that may be suitable for one piece of equipment may become hazardous when used on another piece of equipment.
  • Page 6: Service Precautions

     Maintain all labels on the saw mill. These show important information. If unreadable, missing or damaged, contact Range Road for a replacement.  Have the equipment serviced by a qualified repair person using only OEM replacement parts. This will ensure that the safety of the saw mill is maintained.
  • Page 7 2) The two long boxes at the bottom of the crate are the rail parts. Open these boxes and you will see a small white box, open and take out the bolts and nuts for mounting the rails. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 8 For any Sawmill to cut square and straight all pieces have to be squared to each other and level. Use the adjusting feet to level one rail and then make sure the second rail is level with the first one. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 9 6) Check your width measurement again: RR5022 & RR5026 845mm (33 ¼”) 902mm (35 ½”) RR5029 1008mm (39 11/16”) RR5032 Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 10 9) Mount and tighten centre log support cross tube. 10) Put the levelling feet on next 2 rails and put them in position at the centre log support cross tube. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 11 13) Check to make sure rails are the correct distance apart at both ends and put on the end log support cross tube, do not tighten the bolts. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 12 16) Take the 2 galvanized square posts (View 2 #25) with the pulleys on them and place them into the head unit square tubes, remove the bolts and pulleys, pay attention to where the pulley spacers go, place these to the side. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 13 17) Cut the cardboard at the base of the tube so they can go through to the floor 18) Tighten the T-handles to lock the tubes in place 19) Loosen the 4 corner bolts on the top frame Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 14 21) Tighten all 4 corner bolts to hold posts in place. 22) Lift and rotate the top frame so it is right side up and position it at head unit. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 15 24) Put the back cover on the water tank side and put the bolts in 25) Place spacers and pulleys on bottom bolts, pulley circlips face the spacers, put nuts and washers on but do not tighten up. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 16 26) Lift complete head unit out of crate 27) Mount left and right roller assemblies onto the galvanized tubes, snug bolts up but do not tighten them. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 17 28) Position head unit over track and line rollers up so that the track sits in the roller groove, set head unit onto tracks. 29) Tighten all 8 bolts on roller frames Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 18 Install roller stops at all 4 frame corners 31) Mount control handle at preferred working height on right hand post, making sure throttle cable is not twisted, tighten all 4 bolts. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 19 16mm bolt, put the copper tube through, aiming it towards the blade and snug the bolt up. 34) Support the head unit and undo the T-handles, gently lower the head unit so it sits unsupported on the posts. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 20 35) Wind the lift handle so that the pulley arms are all the way in, then find the two stubs on the inside of the top plate behind the pulley arm, place a cable loop over 1 stub and run cable around pulleys and down to head unit. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 21 Use handle to lift the head unit 152mm – 205mm (6” – 8”) and place a level on the top of blade cover, adjust cables until head is level. Measure distance from the blade log support on each side to double check that head unit is level. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 22 38) Install T-handles into track cross supports to hold the log supports in place, adjust bracket on head unit so that the blade is protected if the head is lower than the log support Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 23 Continue making small adjustments until the Blade stays centered. AFTER any adjustment, tighten Bolts 96A and 96B and nuts 98A and 98B. 39) Install Throttle control (40) on Push Handle (46) as shown in Figure Q. Figure Q: Throttle Control Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 24 Cable. Anchor Bolts (159) until the distance between the ends of the Blade and the top of the Middle Support (8) are the same as shown in Figure S. NOTE: Use a tape measure to verify distances. Figure S: Blade Adjustment Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 25: Engine Operation

    D) Read the Equipment Operation section that follows 1. Start and operate the engine according to the provided engine manual. 2. Replacement engine operating instructions can be obtained from the engine manufacturer. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 26: Equipment Operation

    NOTE: Make sure the Log Clamp Assembly (20) does NOT interfere with the Saw Blade when sawing. The Log Clamp Assembly (20) should be lower than the Saw Blade at all times. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 27 16. Adjust the Throttle to bring the Blade up to speed. The Locking Ring can be turned to lock the throttle in place. Figure W: Throttle Control 17. Throttle speed may need to be increased when the Saw is under load. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 28 4. Cover and store in dry, well-ventilated area out of reach of children. 5. For cold weather operation, store the equipment in a cool dry area to prevent condensation and premature wear. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0...
  • Page 29 Remove stray branches that prevent Teeth filled with debris. proper positioning. 4. Clean debris off blade. Follow all safety precautions whenever diagnosing or servicing the equipment or engine. Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 30 Parts List Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 31 Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 32 Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 33 Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 34 Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
  • Page 35: Please Read The Following Carefully

    Note: Some parts are listed and shown for illustration purposed only, and are not available individually as replacement parts. WARRANTY One-year limited warranty For technical questions, please visit www.range-road.ca www.range-road.com Range Road Enterprises Ltd Box 944 Eckville AB T0M 0X0 www.range-road.ca...
