Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
IA34-415
IA34-406
HARDWARE LIST: IA34-415
Description
No.
A Bolt Ø5/16"*2"
B Bolt Ø5/16"*1-1/2"
C Bolt Ø1/4"*1-1/4"
D Lock Washer Ø5/16"
E Flat Washer Ø5/16" *3/4"
F Lock Washer Ø1/4"
G Flat Washer Ø1/4" *3/4"
H Allen Wrench 4mm
HARDWARE LIST: IA34-406
Description
No.
I Hanger Bolt Ø5/16"*3"
J Half Moon Washer 5/16"
K Hex Nut Ø5/16"
L Hex Wrench 90*25*2mm
M Wood Screw M4*1-1/4"
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/4
ITEM NO: IA34-415/406/407
R
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
IA34-407
Sketch Quantity
6 PCS
4 PCS
4 PCS
10 PCS
10 PCS
4 PCS
4 PCS
1 SET
Sketch Quantity
8 PCS
8 PCS
8 PCS
1 PC
10 PCS
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
KING PANEL BED-ROSALIE CHESTNUT
All Beds need to be set up in the exact final
location so that after full assembly it will not
need to be moved. Moving the bed will cause
the support legs to move out of perpendicular
(90 degree), weaken the support system, and
may allow the bed to collapse.
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
UTILITY KNIFE (FOR CAL KING)
COMPONENTS LIST: IA34-415
Description
No.
1 Headboard
2 Left Leg
3 Right Leg
4 Wood Stretcher
5 Center Support Leg
COMPONENTS LIST: IA34-406
Description
No.
1 Bed rails
2 Slats
COMPONENTS LIST: IA34-407
Description
No.
1 Footboard
2 Support leg (for slats)
Sketch Quantity
1 PC
1 PC
1 PC
1 PC
1 PC
Sketch Quantity
2 PCS
5 PCS
Sketch Quantity
1 PC
5 PCS
06-19-2018
