ARDETEM TPIs 2T User Handbook Manual

Module of 2 logic inputs

Advertisement

MODULE OF 2 LOGIC INPUTS
ÉTUDES ET RÉALISATIONS
TPIs 2T
ÉLECTRONIQUES / INSTRUMENTATIONS / AUTOMATISME
Route de Brindas - Parc d'activité d'Arbora - N°2
69510 - Soucieu en Jarrest
FRANCE
version 02.02
Tél. 04 72 31 31 30 - Fax 04 72 31 31 31
Tel. Intern. 33 4 72 31 31 30 - Fax Intern. 33 4 72 31 31 31
Software SlimSet
User handbook
http: //www.ardetem.com - e-mail: info@ardetem.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPIs 2T and is the answer not in the manual?

Questions and answers

Summary of Contents for ARDETEM TPIs 2T

  • Page 1 02.02 Tél. 04 72 31 31 30 - Fax 04 72 31 31 31 Tel. Intern. 33 4 72 31 31 30 - Fax Intern. 33 4 72 31 31 31 Software SlimSet User handbook http: //www.ardetem.com - e-mail: info@ardetem.com...
  • Page 2 Summary UE conformity declaration 1 . INTRODUCTION 1.1 General features 1.2 Features of the inputs 2 . CONFIGURATION OF THE NETWORK DIMENSIONS - MOUNTING 4 . CONNECTINGS...
  • Page 3 Before any installation or maintenance work, make sure the power supply Name: Measure concentrator of the instrument is cut. TPIs 2T Type: This symbole indicates that the module is protected by a double or reinforced isolation.
  • Page 4 1. INTRODUCTION Compliance with standards: Directive EMC 2004/108/CE ....EN 61326-1 • The TPIs 2T is a module of 2 logic inputs, extra narrow (7.2mm) designed Directive LV 2014/35/UE ....EN 61010-1 for DIN rail mounting. Standard for CSA electrical safety..CSA C22.2 14-13 ............UL 508 17th ed.
  • Page 5 2. CONFIGURATION OF THE NETWORK Possible measure number Type of measure Status logic input 1 Status logic input 2 First start by launching the configuration software SlimSet. Logical result «or» between logic input 1 The purpose is to define your network using the software. and logic input 2 1) Connect a USB cable on the first instrument of the bus (the most on the left Logical result «and»...
  • Page 6 3. DIMENSIONS, MOUNTING ‚ Assembling of the footings Dimensions:..........7.2 x 114 x 114 mm on the rail Housing: ..........self-extinguishing of PBT Terminals: ..........screwed connections (2.5mm², flexible or rigid) Screw thread .......... M3 Max. tightening torque......0.5Nm / 4.5in.lbs BEWARE: Min.
  • Page 7 • INSTALLATION IN AREA 2 (IECEx, ATEX) • INSTALLATION IN DIVISION 2 (cFMus) Class I, Div.2, Groups A,B,C,D T4 II3G Ex nA IIC T4 Gc (GB) The product must be installed by qualified staff, competent on the directives The product must be installed by qualified staff, competent on the directives and the regulation applicable to the division 2.
  • Page 8 4. CONNECTINGS 24VDC LED «master» ±30% communication LED «voltage presence» contact 2 logic 2 namur 2 contact 1 logic 1 namur 1 NPN 1 NPN 2 PNP 1 PNP 2...
