ARDETEM TPIs 4R User Handbook Manual

Module of 4 relay outputs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
ÉTUDES ET RÉALISATIONS
ÉLECTRONIQUES / INSTRUMENTATIONS / AUTOMATISME
Route de Brindas - Parc d'activité d'Arbora - N°2
69510 - Soucieu en Jarrest
FRANCE
Tél. 04 72 31 31 30 - Fax 04 72 31 31 31
Tel. Intern. 33 4 72 31 31 30 - Fax Intern. 33 4 72 31 31 31
http: //www.ardetem.com - e-mail: info@ardetem.com
MODULE OF 4 RELAY OUTPUTS
TPIs 4R
TPIs 4R-C (option calculations)
TPIs 4R version 02.02
TPIs 4R-C version 02.04
Software SlimSet
User handbook

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPIs 4R and is the answer not in the manual?

Questions and answers

Related Manuals for ARDETEM TPIs 4R

Summary of Contents for ARDETEM TPIs 4R

  • Page 1 MODULE OF 4 RELAY OUTPUTS ÉTUDES ET RÉALISATIONS TPIs 4R ÉLECTRONIQUES / INSTRUMENTATIONS / AUTOMATISME TPIs 4R-C (option calculations) Route de Brindas - Parc d’activité d’Arbora - N°2 69510 - Soucieu en Jarrest FRANCE TPIs 4R version 02.02 Tél. 04 72 31 31 30 - Fax 04 72 31 31 31 Tel.
  • Page 2 Summary UE conformity declaration 1 . INTRODUCTION 1.1 General features 1.2 Functions 2 . CONFIGURATION OF THE NETWORK DIMENSIONS - MOUNTING 4 . CONNECTINGS 5 . ANNEXE: CALCULATIONS (OPTION C)
  • Page 3 Before any installation or maintenance work, make sure the power supply Name: Measure concentrator of the instrument is cut. TPIs 4R Type: This symbole indicates that the module is protected by a double or reinforced isolation.
  • Page 4 1.1 General features 1. INTRODUCTION Listed • The TPIs 4R is a module of 4 relay outputs, extra narrow (7.2mm) designed Installation in ATEX / IECEx area 2 for DIN rail mounting. Installation in division 2 cFMus • It belongs necessarily to a local network made up of converters and modu- les (one of the converters is the «master», the TPIs 4R is always «slave»).
  • Page 5 The hysteresis is active on switching to the status «off alarm». Option Reference of the TPIs • Mode setpoint: Calculations (C) TPIs 4R C 1 setpoint configurable over the whole measure range • Mode window: 2. CONFIGURATION OF THE NETWORK 2 setpoints configurable over the whole measure range •...
  • Page 6 Instructions for assembling on 35mm DIN rail according to EN 60715 for each of the outputs of the output modules (TPIs 4R, TPIs 2A/4A ...) you must define the converter associated with this output, as well as the measure associated with this output.
  • Page 7 ƒ „ • INSTALLATION IN DIVISION 2 (cFMus) Class I, Div.2, Groups A,B,C,D T4 Mounting Unmounting (GB) The product must be installed by qualified staff, competent on the directives and the regulation applicable to the division 2. It must be installed in an additional protecting enveloppe ensuring a protection at least of the type IP54.
  • Page 8 5. ANNEXE: CALCULATIONS ( OPTION C ) 4. CONNECTINGS With the option C you can have on the TPIs 4R-C 10 calculation formulas, programmable in a dynamic way, using operators, pre-defined functions, col- lected measures, external registers of the TPIs 4R-C and 16 programmable constants.

This manual is also suitable for:

Tpis 4r-c
