- Page 1 PLAQUE MFM0680 UNDERWATER LIGHT Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Preface ............................... 3 Features ............................. 3 Precautions ............................3 Controls and Connectors ........................4 Underwater Light PLAQUE MFM0680 ..................4 Power Supply Unit MPS021000 / MPS021500 ................5 Installation ............................6 Underwater Light PLAQUE MFM0680 ..................6 Power Supply Unit MPS021000 / MPS021500 ................7 Appearance ............................ -
Page 3: Preface
PREFACE PRECAUTIONS The PLAQUE series underwater lights are • The underwater light has to be installed and designed to use the latest LED lighting used in accordance with the instructions of technology for flush-mount installation where this manual only. the most important are low-profile casings to •... -
Page 4: Controls And Connectors
CONTROLS AND CONNECTORS Underwater Light PLAQUE MFM0680 (1) Optical window The 6 mm depth tempered glass optical window. (2) Underwater light casing Aluminium bronze casing with fixing holes and cable gland. (3) Fixing assembly The fixing nut, washer and screws to fix the underwater light on the hull. (4) Cable The 4-pole multi-core cable to connect the power supply unit. -
Page 5: Power Supply Unit Mps021000 / Mps021500
Power Supply Unit MPS021000 / MPS021500 (1) LIGHT Terminal-block connector to connect the LED underwater light using 4-pole multi-core cable. (2) CONTROL Terminal-block connector to connect optional remote control unit or switch. (3) DC IN Terminal-block connector to connect 24Vdc power supply. (4) DC OUT Terminal-block connector to connect to the DC IN connector of another power supply unit. -
Page 6: Installation
INSTALLATION The underwater light kit consists of the following components: • Underwater Light PLAQUE MFM0680 • Power Supply Unit MPS021000 / MPS021500 • Washer • Fixing nut with 4 screws M8 and bonding screw M4 • 2 x cable gland M12 •... -
Page 7: Power Supply Unit Mps021000 / Mps021500
Note: • To install the underwater light on the steel hull it is highly recommended to use the optional isolation board (not included) between the hull and underwater light casing to prevent galvanic corrosion. Note: • Do not overtighten the screws M8 as this can result in hull or underwater light damage. Bonding The underwater light has to be connected to the vessels bonding and cathodic protection using a pre- tinned wire a minimum of 8 AWG (8.36 mm... - Page 8 A power supply unit of another underwater light can be connected to the DC OUT terminal-block connector. Note: • Only one additional power supply unit of the same model number can be connected to the DC OUT terminal-block connector and suitable power supply cable should be used. The appurtenant cap should be removed from the casing and enclosed cable gland M12 should be inserted.
-
Page 9: Appearance
APPEARANCE TECHNICAL SPECIFICATIONS LED Underwater Light PLAQUE MFM0680 Power requirement 1 A / 1.5A Lens angle 50° Optical window 6 mm depth tempered glass Luminous flux 3.500 lm (white) White color temperature 6.000 - 10.000 K Operating temperature -10°C - +50°C Casing Aluminium bronze (AB2) Protection... -
Page 10: Warranty
WARRANTY 1. The equipment manufactured by ASTEL d.o.o. is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY according to IEC Guide 22 and EN 45014 Manufacturer's Name: ASTEL, Podjetje za projektiranje, proizvodnjo in trgovino, d.o.o. Manufacturer's Address: Dutovlje 138 6221 Dutovlje Slovenija declares that the products Item, Product Name and Model Number: 1. Underwater Light PLAQUE MFM0680 with Power Supply Unit MPS021000 / MPS021500 conform to the following Product Specifications: EMC:... - Page 12 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 info@astel-marine.com E-mail: www.astel-marine.com Web:...
