- Page 1 Free standing cooker HGB330E.0Q [en] Instruction manual Free standing cooker...
-
Page 3: Table Of Contents
Precautions for use ......17 www.bosch-home.com and in the online shop www.bosch-eshop.com Ä... -
Page 4: Intended Use
Intended use opening of a window, or more effective 8Intended use ventilation, for example increasing the level of mechanical ventilation where present. R ead these instructions carefully. Only then I n t e n d e d u s e will you be able to operate your appliance Warning –... -
Page 5: Important Safety Information
Important safety information Never place flammable objects on the (Important safety ■ burners or store them in the cooking information compartment. Never open the appliance door if there is smoke inside. Switch off the appliance. Pull out the mains plug or switch Warning –... - Page 6 Important safety information Warning – Risk of scalding! The accessible parts become hot during ■ operation. Never touch the hot parts. Keep children at a safe distance. When you open the appliance door, hot Risk of scalding! ■ steam can escape. Steam may not be visible, depending on its temperature.
-
Page 7: Causes Of Damage
Causes of damage When replacing the cooking compartment ]Causes of damage ■ bulb, the bulb socket contacts are live. Before replacing the bulb, unplug the H ob appliance from the mains or switch off the C a u s e s o f d a m a g e circuit breaker in the fuse box. -
Page 8: Damage To The Plinth Drawer
Environmental protection Cooling with the appliance door open: Following 7Environmental protection ■ operation at high temperatures, only allow the cooking compartment to cool down with the door closed. Do not trap anything in the appliance door. Y our new appliance is particularly energy-efficient. E n v i r o n m e n t a l p r o t e c t i o n Even if the door is only left open a crack, the front of Here you can find tips on how to save even more... -
Page 9: Saving Energy With The Gas Hob
Installation and connection Open the appliance door as infrequently as possible 5Installation and connection ■ when the appliance is in use. D o not install the appliance behind a decorative door I n s t a l l a t i o n a n d c o n n e c t i o n or the door of a kitchen unit, as this may cause the appliance to overheat. -
Page 10: Electrical Connection
Installation and connection Faults in the gas installation/smell of gas For the after-sales service If you notice a smell of gas or faults in the gas Caution! installation, you must The appliance must be connected in accordance ■ with the data on the rating plate. immediately shut off the gas supply and/or close the ■... -
Page 11: Setting Up The Appliance
Installation and connection Setting up the appliance Measures to be noted during transport Secure all mobile parts in and on the appliance using an adhesive tape that can be removed without leaving any traces. Push all accessories (e.g. baking tray) into the corresponding slots with cardboard at the edges, in order to avoid damaging the appliance. -
Page 12: Getting To Know Your Appliance
Getting to know your appliance Depending on the appliance model, individual Note: *Getting to know your details and colours may differ. appliance I n this section, we will explain the indicators and G e t t i n g t o k n o w y o u r a p p l i a n c e controls. -
Page 13: Control Panel
Getting to know your appliance Control panel Here you can see an overview of the control panel. The To use the individual time-setting options, tap the design depends on the respective appliance model. button several times. The symbol that lights up corresponds to the value currently shown in large digits on the display. -
Page 14: The Cooking Compartment
Accessories The cooking compartment Inserting accessories The oven light is located in the cooking compartment. The cooking compartment has five shelf positions. The shelf positions are counted from the bottom up. Steam outlet In some appliances, the highest shelf position is The hot air from the cooking compartment escapes at marked on the cooking compartment by the grill the rear of the hob. -
Page 15: Before Using For The First Time
Before using for the first time KBefore using for the first Optional accessories Wire rack time For cookware, cake tins and ovenproof dishes, and for roasts and grilled food. B efore you can use your new appliance, you must Baking tray B e f o r e u s i n g f o r t h e f i r s t t i m e make some settings. -
Page 16: Setting The Oven's Electric Grill
Before using for the first time Check through the hole in the oven's bottom panel Cleaning the accessories that the flame is burning. If the flame is not burning, Before you use the accessories for the first time, clean repeat the process from step 3. them thoroughly with hot soapy water and a soft dish Close the oven door carefully. -
Page 17: Cooking Pans
Cooking pans ÅCooking pans C o o k i n g p a n s Burner Power Minimum Maximum [kW] cookware cookware Electric diameter diameter hotplate* Electric 1 kW 14.5 cm 14.5 cm hotplate* Wok burner* 3.5 kW 24 cm 28 cm High-output 3 kW... -
Page 18: Gas Burners
Gas burners The hotplate control should not be actuated for longer ÄGas burners than 15 seconds. If the burner does not ignite within 15 seconds, wait at least 1 minute before repeating the procedure. T his chapter explains how to set a hotplate. The table G a s b u r n e r s shows heat settings and cooking times for various Warning –... -
Page 19: Operating The Appliance
Operating the appliance Example Food Hotplate Cooking mode Chocolate, butter, Economy burner Small flame Melting margarine Stock, tinned vegetables Standard-output burner Small flame Warming Soups Economy burner Small flame Heating and keeping warm Fish Standard-output burner Between large and small flame Steaming* Potatoes and Standard-output burner... -
Page 20: The Oven's Electric Grill Can Be Set As Follows
Time-setting options The oven's electric grill can be set as follows OTime-setting options Example in the image: Electric grill setting Y our appliance has different time-setting options. Open the top cover. The top cover must remain T i m e - s e t t i n g o p t i o n s open for as long as the appliance is in operation. -
Page 21: Setting A Cooking Time
Time-setting options Setting a cooking time To cancel, use the button to reset the cooking time all the way to zero. The appliance will continue heating You can set the cooking time for your food on the without a cooking time. appliance. -
Page 22: Setting The Timer
Time-setting options Setting the time The cooking time has elapsed An audible signal sounds. The appliance stops heating. When the appliance is connected to the power supply The cooking time is shown as zero in the display. or following a power failure, the time flashes in the display. -
Page 23: Childproof Lock
Childproof lock AChildproof lock DCleaning Y our appliance is equipped with a childproof lock so W ith good care and cleaning, your appliance will retain C h i l d p r o o f l o c k C l e a n i n g that children cannot switch it on accidentally or change its appearance and remain fully functioning for a long any settings. - Page 24 Cleaning Zone Cleaning agent Zone Cleaning agent Upper glass cover* Glass cleaner: Glass hob* Care: Protective/care products for glass Clean with a soft cloth. Cleaning: Cleaning agents for glass. (depending on appli- (depending on appli- You can remove the upper glass cover for Follow the cleaning instructions on the packag- ance model) ance model)
-
Page 25: Keeping The Appliance Clean
Cleaning Keeping the appliance clean Zone Cleaning agent Accessories Hot soapy water: Always keep the appliance clean and remove dirt Soak and then clean with a dish cloth or a immediately so that stubborn deposits of dirt do not brush. build up. -
Page 26: Rails
Rails the two hooks must be inserted fully into the upper pRails holes. Now move the frame slowly and carefully downwards and insert in the lower holes (figure D). Insert both frames into the side walls of the oven W ith good care and cleaning, your appliance will retain R a i l s (figure E). -
Page 27: Appliance Door
Appliance door Attaching the door qAppliance door Reattach the oven door in the reverse sequence to removal. W ith good care and cleaning, your appliance will retain A p p l i a n c e d o o r When attaching the oven door, ensure that both its appearance and remain fully functional for a long hinges are inserted straight into the opening... -
Page 28: Upper Glass Cover
Trouble shooting Upper glass cover 3Trouble shooting Before opening the top cover, remove any spills with a cloth. I f a fault occurs, there is often a simple explanation. T r o u b l e s h o o t i n g Use glass cleaner if possible. -
Page 29: Replacing The Bulb In The Oven Ceiling Light
Customer service Replacing the bulb in the oven ceiling light 4Customer service If the bulb in the oven light fails, it must be replaced. Heat-resistant, 25 watt spare bulbs can be obtained O ur after-sales service is there for you if your appliance from our after-sales service or a specialist retailer. -
Page 30: Tested For You In Our Cooking Studio
Tested for you in our cooking studio A lot of steam can build up in the cooking Note: JTested for you in our compartment when cooking food. cooking studio Your appliance is very energy-efficient and radiates very little heat to its surroundings during operation. Due to the high difference in temperature between the H ere, you can find a selection of dishes and the ideal appliance interior and the external parts of the... -
Page 31: Baking Tips
Tested for you in our cooking studio Several small baked items on the baking Accessories Level Temperature in °C Cooking time in minutes sheet (lower gas burner on the oven) Sesame seed rings Baking sheet 60-80 Puff pastry strudel Baking sheet 50-70 Yufka dough strudel Baking sheet... -
Page 32: Tips For Roasting And Grilling
Tested for you in our cooking studio Dish Weight Accessories and oven- Level Temperature Cooking time in min- ware in °C, grill set- utes ting Fish fillets (4 pieces) 0.5 kg Wire rack 260-270 20-30 Toast Toasts, browned (9 slices) Wire rack 260-270 Toasts with filling, browned from above... - Page 36 *9001302670* 9001302670 000205(C)
