TCL ALCATEL Idol4 S Repair Document

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TCL
L2 Repair Document
Communication Ltd.
Idol4 S
ALCATEL 6070K/Y/O
Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior
notice on the characteristics of described equipments.
Rev.
Page
1.2
1/85
ALCATEL 6070K/Y/O Level 2 Repair Document
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

Advertisement

Table of Contents
loading

Related Manuals for TCL ALCATEL Idol4 S

Summary of Contents for TCL ALCATEL Idol4 S

  • Page 1 L2 Repair Document Communication Ltd. Idol4 S ALCATEL 6070K/Y/O Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior notice on the characteristics of described equipments. Rev. Page 1/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 2 L2 Repair Document Communication Ltd. 2016/6/15 Update Xiaolong Yang 2016/5/6 Update Xiaolong Yang 2016/3/28 Draft creation Xiaolong Yang Rev. Date Modification description Prepared By Checked By Approved By Rev. Page 2/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 3: Table Of Contents

    L2 Repair Document Communication Ltd. Content Level 2 repair process ....................5 Warranty Check and Visual Inspection ..............6 2.1 Warranty confirmation of L1..................6 2.2 Visual mechanical check ..................7 2.3 Pretest ........................8 Battery ........................17 3.1 Battery information ....................17 3.2 Battery test ......................
  • Page 4 L2 Repair Document Communication Ltd. 6.3 Display issue ......................68 6.4 Vibrator issue ......................69 6.5 Touch panel issue ....................70 6.6 SIM recognize issue ....................71 6.7 TF card recognized issue ..................72 6.8 Main camera issue ....................73 6.9 Sub camera issue ....................

  • Page 5: Level 2 Repair Process

    L2 Repair Document Communication Ltd. 1 Level 2 repair process Star Visual Inspection Warranty Check Pretest & Failure confirm Back up user data SW Upgrade Function Disassembly L2 Repair PCBA Replace Rete Reassembly Rete Restore User Information Record in BIG Rev.

  • Page 6: Warranty Check And Visual Inspection

    L2 Repair Document Communication Ltd. 2 Warranty Check and Visual Inspection 2.1 Warranty confirmation of L1  IMEI sticker check: 1) Power on the handset, enter *#06# 2) If the IMEI sticker in the back casing is not lost: We should make sure that the IMEI number MUST be the same with the one on the IMEI sticker; if not, it‟s out of warranty policy.

  • Page 7: Visual Mechanical Check

    L2 Repair Document Communication Ltd. 2.2 Visual mechanical check Mechanical warranties check items: Corrosion  Corrosion on the USB connector, SIM connector, and other metal surfaces。 Hole (diameter > 1mm)  Holes on any surface, including the front casing, furnished frame, battery cover, touch Lens, keypad…...

  • Page 8: Pretest

    L2 Repair Document Communication Ltd.  External physical damage relating to abnormal use, like front case and frame opened Others  Damage caused by disassembly ,wrong part assembly, loss of components  Use in abnormal environment like high temperature causing plastic melts 2.3 Pretest Check that the SIM card is set correctly.
  • Page 9 L2 Repair Document Communication Ltd. Press “Pass” to continue.  AACLC I. It will show “Flag: AAC” “GPIO: AAC” if it functions well; Press “Pass” to continue.  SMARTPA CAL I. It will running the test automatically and show “TOP OK; BOTTOM OK; SmartPA Test PASS”...
  • Page 10 L2 Repair Document Communication Ltd. I. Hover your finger above the corresponding position according to instructions, and then it will turn green if it functions well; Press “Pass” to continue.  You will see the LCD display three colors: RED, GREEN and BLUE if it functions well; Press “Pass”...
  • Page 11 L2 Repair Document Communication Ltd. Press “Pass” to continue.  Front Camera Press “Pass” to continue if the front camera functions well.  Main Camera Press “Pass” to continue if the main camera functions well.  PDAF Camera Press “Pass” to continue if the PDAF camera functions well. ...
  • Page 12 L2 Repair Document Communication Ltd. Press “Pass” to continue; III. You will hear a voice prompt which introduces some emergency call numbers from the bottom receiver if it functions well; Press “Pass” to continue; V. You will hear a voice prompt which introduces some emergency call numbers from the top speaker if it functions well;...
  • Page 13 L2 Repair Document Communication Ltd. functions well; Press “Pass” to continue.  Memory Card Insert SD card and the phone will detect it if it functions well; Press “Pass” to continue.  USB/Charger I. Insert USB cable according to instruction and it will say “USB cable checked”, “USB: OK”, “Charger: OK”, “Current: xxx”...
  • Page 14 L2 Repair Document Communication Ltd. V. Make a noise near the headset mic, you will hear it from headset if it functions well; VI. Press “Pass” to continue; VII. Remove headset according to the instruction and press “Pass” to continue. ...
  • Page 15 L2 Repair Document Communication Ltd. III. The compass will always point north whatever the phone is put at which direction if it functions well; IV. Press “Pass” to continue.  Light Sensor I. It will show the value of ambient light and the value will change according to the phone‟s environment (Bright or Dark), then it will say “dark: OK”, “bright: OK”...
  • Page 16 L2 Repair Document Communication Ltd. Press “Pass” to continue.  Bluetooth Bluetooth will search automatically and it will display device address if it functions well; Press “Pass” to continue.  Wifi I. It will search for WIFI hotspot and it will display searched result on the screen if it functions well;...

  • Page 17: Battery

    L2 Repair Document Communication Ltd. I. You will see the hardware information on the screen, such as the G-sensor, E-compass and so on. Press “Pass” to continue.  Battery Level You will see the percentage information and the charging information on the screen. Press function key “Back”...
  • Page 18 L2 Repair Document Communication Ltd. Battery feature Model Element Capacity Battery Li Lithium 3000mAh Battery life The bellowing table shows the nominal battery life respectively in standby and talking mode. These typical values are expressed in normal temperature with battery initially full charged and under good ratio coverage.

  • Page 19: Battery Test

    L2 Repair Document Communication Ltd. Battery charge time For a normally discharged battery which has not been stored for long time, the charge time listed as below table. Mode Typical Charge time 100mins Power pack Lithium Note: If the battery is new, charge it before use. Battery icon will appear after charging a short time. b) If the battery is deeply discharged, battery icon will appear after charging several minutes and accompany with a slight sound.

  • Page 20: Battery Specification

    L2 Repair Document Communication Ltd. Following fixed battery icon display : After charging (charger connected) Table - Battery charge status on handset 2) If the display does not light on or battery icon does not flash when the charger or the cell phone‟s charge function is defective with mechanical or electronics.

  • Page 21: Software Download

    L2 Repair Document Communication Ltd. Cell model CSL376776 TLp030F1 Pack model Nominal voltage 3.84V Battery capacity 3000mAh (Minimum) Fully charged battery is discharged with current 0.2C from 4.40V to 3.00V Charge Charge method CC - CV (Constant current - Constant voltage) Operating temp.

  • Page 22: Install Driver

    L2 Repair Document Communication Ltd. ⑶ A USB cable. 4.2 Install driver At the final step of SUGAR setup procedure, it will remind you to install driver. Please select “Yes”, and then the driver will be installed. Install driver finish: Rev.

  • Page 23: Sw Download Process

    L2 Repair Document Communication Ltd. 4.3 SW download process Ⅰ. Power off the handset and connect it with PC by USB cable, and then open “Sugar QCT_SP” v10.3.0 (you can get the latest version from TS website: https://css.tclmobile.cn/). “Sugar QCT_SP” login window looks like follow picture.
  • Page 24 L2 Repair Document Communication Ltd. Input „User name‟ and „Password‟, and then press “OK” to log on. Ⅱ. Use “Get Status” function to check current SW vision, available version from server and handset info such as IMEI, PTM, CU ref, data code, etc. Select the product models –...
  • Page 25 L2 Repair Document Communication Ltd. Press “Get Status” button. Rev. Page 25/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 26 L2 Repair Document Communication Ltd. Remark：You can get “Date code” of the headset by using “Get Status” function. Rev. Page 26/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 27 L2 Repair Document Communication Ltd. III. Power off the handset and reconnect it with PC by USB cable, then click “Upgrade”, upgrade process will start automatically. IV. Upgrade finished. The phone will turn on automatically if the download is finished successfully. Rev.

  • Page 28: Disassembly And Assembly Alcatel 6070

    L2 Repair Document Communication Ltd. 5 Disassembly and assembly ALCATEL 6070 5.1 ESD Safety Please wear static loop or static glove 5.2 Disassembly tool You may use the following tools during the disassembly and reassembly procedure: Rev. Page 28/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved.
  • Page 29 L2 Repair Document Communication Ltd. Screwdriver Pry bar Tweezers Plastic Flake SIM Card Tray Pin Soldering iron Suction cup Hot wind gun Model: ANSA1-21 Measurement: 26*19*11(cm) Digital heating table The fixture adapter of heating battery cover (for Idol 4S) PN: WAA61K0U7001 Rev.

  • Page 30: Disassembly Process

    L2 Repair Document Communication Ltd. 5.3 Disassembly process The steps of disassembly ALCATEL 6070 are as below. Step1: Separate the SIM tray first by using SIM Card Tray Pin. Step2: Separate the back cover. Way 1: Use digital heating table to separate the back cover (1) Put the fixture adapter of heating battery cover on the digital heating table;...
  • Page 31 L2 Repair Document Communication Ltd. (2) Turn on the digital heating table; (3) Set the target temperature of the digital heating table at 75℃; Current temperature Target temperature Adjust the temperature to up/down Set key Rev. Page 31/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved.
  • Page 32 L2 Repair Document Communication Ltd. ① Press the set key ② Adjust the temperature to 75℃ Rev. Page 32/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 33 L2 Repair Document Communication Ltd. ③ Press the set key to confirm (4) After the current temperature reach 75℃, put the Idol 4S on the platform for 3min; Rev. Page 33/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 34 L2 Repair Document Communication Ltd. Rev. Page 34/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 35 L2 Repair Document Communication Ltd. (5) Take Idol 4S out from the digital heating table, pull up the battery cover with the suction cup (the largest angle between front casing and battery cover do not exceed 30° ), and then use the plastic flake to slide along the left/right side of battery cover carefully (the depth of flake infix at 1mm)
  • Page 36 L2 Repair Document Communication Ltd. Way 2: Use hot wind gun to separate the back cover level Ⅲ 75 ℃. (1) Turn on the hot wind gun to and adjust the temperature of hot wind gun to Adjust the temperature to up/down Turn on the wind to Level Ⅲ...
  • Page 37 L2 Repair Document Communication Ltd. Level: 3, Height: 15mm, Time: about 30s) Heating area 15mm (3) Pull up the battery cover with the suction cup (the largest angle between front casing and battery cover do not exceed 30° ), and then use the plastic flake to slide along the left/right side of battery cover carefully (the depth of flake infix at 1mm).
  • Page 38 L2 Repair Document Communication Ltd. (4) Adjust the temperature of hot wind gun to 130℃. Adjust the temperature to up/down (5) Use hot wind gun to heat up the edges of top/bottom side uniformly (Notice: temperature: 130℃, Air Level: 3, Height: 15-30mm, Time: about 30s) Rev.
  • Page 39 L2 Repair Document Communication Ltd. Heating area 15mm-30mm (6) Insert pry bar and separate battery cover and furnished frame carefully. Rev. Page 39/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 40 L2 Repair Document Communication Ltd. Rev. Page 40/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 41 L2 Repair Document Communication Ltd. Step3: Remove the PET deco with tweezers. Step4: Take off 13 screws with screwdriver. (Screw torque: 0.6± 0.10kgf.cm)There are 2 kinds of screws as below (Remark: There have two box conductive rings under the screw in yellow circle).
  • Page 42 L2 Repair Document Communication Ltd. ① ② ① ③ ② ② ② ① ① ① ① ① ① ① ③ Rev. Page 42/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 43 L2 Repair Document Communication Ltd. Step5: Remove the TOP/BOTTOM speak box with tweezers. Pry up the top speaker box from here Step 6: Disconnect several FPCs connector and coaxial cable with tweezers, and then pry up the main PCBA and remove it from front casing. HAC FPC Audio jack FPC connector...
  • Page 44 L2 Repair Document Communication Ltd. Rev. Page 44/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 45 L2 Repair Document Communication Ltd. Step 7: Remove the battery from front casing. There are 3 battery stickers between battery and front refer to below picture casing ( (1) Pull the battery sticker horizontally and stick it to pry bar. Rev.
  • Page 46 L2 Repair Document Communication Ltd. (2) Press the battery carefully and spin pry bar slowly, then pull out the battery sticker completely. (3) Repeat these steps until all of battery stickers are pulled out, and then remove battery from front casing.
  • Page 47 L2 Repair Document Communication Ltd. For this method, you can refer to the video: disassemble battery for Idol4 Or you can remove the battery by using the JIG (PN: WAA34D0QJ003). Rev. Page 47/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 48 L2 Repair Document Communication Ltd. For details, please refer to the video which located in CSS web, find the video search in CSS as below. Note: Potential for fire or burning. Do not puncture, crush, or heat the battery. Strictly avoid using sharp tool to pry up battery.
  • Page 49 L2 Repair Document Communication Ltd. Remove vibrator by Soldering iron. (Temperature：Lead-free technology 330℃± 10℃，time：2~3 seconds) Step 9: Remove Sidekey FPC, HAC FPC, Audio jack FPC, front camera rubber, volume key and power key with tweezers. Rev. Page 49/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved.
  • Page 50 L2 Repair Document Communication Ltd. Step 10: Remove main camera and front camera by tweezers and push out camera deco with pry bar. Rev. Page 50/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 51 L2 Repair Document Communication Ltd. Notice: If only replace the camera lens which has scratch or crack (not to disassemble battery cover), please put the camera lens downward and remove the shards of camera lens with tweezers carefully, then replace a new one. Rev.
  • Page 52 L2 Repair Document Communication Ltd. Step 11: Disassemble complete. Remark： For details of disassembly steps, please refer to the file “Disassembly of Idol 4S” on CSS. Repair tips -> Video: Rev. Page 52/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 53: Reassembly Process

    L2 Repair Document Communication Ltd. 5.4. Reassembly Process Please make reference to the disassembly process for assembly reverse an order of the disassembly steps. Jig list: description Picture WAA00002U002 Press battery cover after assembly WAA61K0HU002 paste adhesive paper jig WAA61K0TG002 Back cover press adaptor Rev.
  • Page 54 L2 Repair Document Communication Ltd. Attention:  When assembling main PCBA, make sure that main camera, front camera, sidekey FPC, HAC FPC, Audio jack FPC, front camera rubber, volume key and power key are well installed firstly;  When assembling battery, make sure that sub FPC and coaxial cable are well installed firstly; ...
  • Page 55 L2 Repair Document Communication Ltd. box conductive ring,Idol4 S,φ3.10 ③ BLA61K0013C0 mm,T0.15,SPTE+JH306SP,N/A,LAIMU Rev. Page 55/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 56 L2 Repair Document Communication Ltd. ① ② ① ③ ② ② ② ① ① ① ① ① ① ① ③  Assemble the foam of back cover （1）Stick top box batt foam (PN: BPA61K0010C0) and bot box batt foam (PN: BPA61K0007C0) Rev.
  • Page 57 L2 Repair Document Communication Ltd. Top box batt foam (PN: BPA61K0010C0) Bot box batt foam (PN: BPA61K0007C0) Rev. Page 57/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 58 L2 Repair Document Communication Ltd. (2) Place the battery deco foam B (PN: BPA61K0002C0) and battery deco foam D (PN: BPA61K0009C0) on the JIG (PN: WAA61K0HU002), then fix them on the positioning column. Battery deco foam B Battery deco foam D Positioning column (PN: BPA61K0002C0) (PN: BPA61K0009C0)
  • Page 59 L2 Repair Document Communication Ltd. (4)Remove battery cover away. Rev. Page 59/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 60 L2 Repair Document Communication Ltd. (5) Place the battery deco foam A (PN: BPA61K0008C0) and battery deco foam C (PN: BPA61K0006C0) on the JIG, then fix them on the positioning column. Battery deco foam C (PN: BPA61K0006C0) Positioning column Battery deco foam A (PN: BPA61K0008C0) (6) Place the battery cover on the JIG and press it for a few seconds Rev.
  • Page 61 L2 Repair Document Communication Ltd. (7) Remove battery cover away. Rev. Page 61/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 62: Disassembly Process Evaluation

    L2 Repair Document Communication Ltd.  Assemble the battery cover with the JIG (PN: WAA61K0TG002) for Idol 4S, (Pressure: 40KG, Time: 30s) Remark: For details of this JIG, please refer to the file “Assemble and press the battery cover of Idol 4S”...

  • Page 63: Disassembly Complete

    L2 Repair Document Communication Ltd. Time for Jigs for Spare part Difficulty Class Remark disassembly disassembly Hot wind gun Battery cover suction cup Class 3 Plastic Flake PET deco Tweezers Class 1 Screws Screwdriver Class 1 Top/Bottom speak box Tweezers Class 1 Tweezers Main PCBA...
  • Page 64 L2 Repair Document Communication Ltd. Rev. Page 64/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 65: Level 2 Repair

    L2 Repair Document Communication Ltd.  Please get the latest L2 SPL in Forlog system. 6 Level 2 repair This chapter describes the Level 2 repair that can be done without any diagnostic equipment. All these repairs only refer to the hardware part. In case the Level 2 repair can‟t solve the problem, or the PCBA is damaged, exchange the PCBA.

  • Page 66: Power On Issue

    L2 Repair Document Communication Ltd. 6.1 power on issue Power on failure Charge for 15 minutes, check whether can power on Check whether the connection Reassemble battery b e t w e e n battery a n d battery connector is good Replace it with a new Check whether battery status is good battery...

  • Page 67: Charge Issue

    L2 Repair Document Communication Ltd. 6.2 Charge issue Charging failure Check whether the voltage of the Replace battery battery is 0V and Charge for 15 minutes, check whether battery is good. r e p l a c e b a t t e r y C h e c k w h e t h e r b a t t e r y connector is good connector...

  • Page 68: Display Issue

    L2 Repair Document Communication Ltd. 6.3 Display issue Display failure Check whether the connection Reassemble LCD b e t w e e n LCD a n d LCD connector is good Reweld or replace LCD Check whether LCD connector is connector normal C h e c k w h e t h e r LCD i s...

  • Page 69: Vibrator Issue

    L2 Repair Document Communication Ltd. 6.4 Vibrator issue Vibrating function failure C h e c k w h e t h e r t h e c o n n e c t i o n Reweld Vibrator between Vibrator and PCBA is good Check whether Vibrator is Change Vibrator normal...

  • Page 70: Touch Panel Issue

    L2 Repair Document Communication Ltd. 6.5 Touch panel issue Touch function failure Check whether the connection Reassemble TP between TP and TP connector is good C h e c k w h e t h e r T P i s n o r m a l ( i n t e r c h a n g e Change TP method)

  • Page 71: Sim Recognize Issue

    L2 Repair Document Communication Ltd. 6.6 SIM recognize issue S I M c a r d c a n ’ t b e recognized Re-assemble or change Check whether the SIM card is SIM card good C h e c k w h e t h e r S I M c a r d Re-weld or change SIM connector is good card connector...

  • Page 72: Tf Card Recognized Issue

    L2 Repair Document Communication Ltd. 6.7 TF card recognized issue T F c a r d c a n ‟ t b e recognized Check whether the TF card is Change TF card good C h e c k w h e t h e r t h e T F c a r d Re-weld or change TF connector is good card connector...

  • Page 73: Main Camera Issue

    L2 Repair Document Communication Ltd. 6.8 Main camera issue Main camera function failure Check whether the connection Reassemble main camera between main camera and main camera connector is good Check whether main camera is Replace main camera normal C h e c k w h e t h e r m a i n c a m e r a Reweld or replace Main connector is normal camera connector...

  • Page 74: Sub Camera Issue

    L2 Repair Document Communication Ltd. 6.9 Sub camera issue Sub camera function failure Check whether the connection Reassemble sub camera between sub camera and sub camera connector is good Check whether sub camera is Replace sub camera normal C h e c k w h e t h e r s u b c a m e r a R e w e l d o r r e p l a c e s u b connector is normal camera connector...

  • Page 75: Mic Issue

    L2 Repair Document Communication Ltd. 6.10 MIC issue No sound emitting or sometimes no sound emitting/ noises were heard by other side during the call /recording function failure / Check whether the connection Reassemble or replace between main FPC and main main FPC FPC connector is good Check whether MIC is normal...

  • Page 76: Speaker Issue

    L2 Repair Document Communication Ltd. 6.11 Speaker issue N o r i n g i n g /play music failure o r hands free sound failure C h e c k w h e t h e r t h e c o n n e c t i o n Reassemble speaker between speaker and PCBA is good Replace speaker...

  • Page 77: Usb Connector Issue

    L2 Repair Document Communication Ltd. 6.12 USB connector issue Charging failure R e w e l d o r r e p l a c e USB Check whether USB connector connector is normal Check whether the connection Reassemble or replace between sub FPC and sub sub FPC FPC connector is good...

  • Page 78: Other Component Exchange

    L2 Repair Document Communication Ltd. software version. Send the NG PCBA with record sticker back to L3 repair center with the recommended packaging method, Note: packaging method please refer item “APPENDIX 1 Packaging Requirements”. 8 Other component exchange The other components exchange such as Antenna bracket Vibrator Speaker...
  • Page 79 L2 Repair Document Communication Ltd. Cosmetic aspect of the handset, The Software Technical sticker state on the Board Switch on the handset Default welcome message Press *#2886# on the idle screen to start the auto test Rev. Page 79/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved.

  • Page 80: Appendix 1 Packaging Requirements

    L2 Repair Document Communication Ltd. APPENDIX 1 Packaging Requirements Any L3 PCBA which has appearance like below cases is not acceptable.  1) The PCBA which shielding cover is rusty or distortion, copper peel off; × × ×  2) Smudge on PCBA, such as soldering flux, rudimental glue, handwriting, burn, scratch and so on ; ×...
  • Page 81 L2 Repair Document Communication Ltd. × × × ×  3) Symptom sticker, high temperature adhesive or nonstandard label on PCBA; Note: Rev. Page 81/85 ALCATEL 6070K/Y/O Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 82 L2 Repair Document Communication Ltd. a. Nonstandard label means broken label, label with handwriting, dirty label, label pasted in the wrong place, etc. b. L2E label, IMEI label and PCBA label are acceptable to be kept on PCBA only under the condition that these labels are intact, clean and smoothly pasted in the right place) ×...
  • Page 83 L2 Repair Document Communication Ltd.  4) PCBA with liquid or mildew. × 2. PCBA label must be retained on the PCBA. Clean and intact IMEI label should be retained on the PCBA. √ √ IMEI label PCBA label Note： Ⅰ.
  • Page 84 L2 Repair Document Communication Ltd. × √ Choose box according to shipping quantity. Each slot usually put 4 or 5pcs. (4pcs for big one and 5pcs for small one). Meanwhile, use Wrinkled tape (marking the material code and qty) to distinguish the PCBA of different code.
  • Page 85 SPAIN Pisco (eg.) 2AYGES1 power on If you have any question or problem, please feel free to contact us Thanks for your cooperation. TCL Communication Ltd. Global Customer Service TS Dept. May 6 , 2016 Rev. Page 85/85 ALCATEL 6070K/Y/O Level 2 Repair Document...
