FOOTREST INSTRUCTIONS
These instructions are only for installing the included
footrest on the RS Hawk Deluxe (PN 81509).
ALWAYS refer to the 2009 Raptor Series Hang-
On Written Instructions for warnings and useage
instructions.
1
PARTS LIST
Please call 256-353-0634 or visit http://www.summitstands.com/contactus/
if you have any questions, if you need replacement parts, or if you have any missing parts.
BOX CONTENTS
In addition to the items lised on Page 2 of the 2009
Raptor Series Instructions, your treestand should
include the following:
PN
40123
22029
10903
22029 - FOOTREST HARDWARE KIT
PN
10601
10612
10640
10641
10635
10668
10122
NOTICE
DESCRIPTION
FOOTREST BAR
FOOTREST HARDWARE PACKET
CABELA'S EZ ARM BOWHANGER
CABELA'S MONSTER BUCKS XIV DVD
DESCRIPTION
1 3/4" BOLT, 1/4x20
LOCK NUT, 1/4x20
LONG SHANK BUSHING
SHORT SHANK BUSHING
SELF TAPPING SCREW
FOOTREST BUMPER
FOOTREST MOUNTING BRACKET
QTY
1
1
1
1
QTY
2
2
4
2
4
2
2
FORM# 18006
