Fostex VF80 Specifications

20900-FostexVF80sell/Sorenson
VF80 Digital Power T ool

Main Features

DIGITAL MIXER
New A.S.P.+ digital channel
effects. 44 effect types
including stunning amp
simulations & distortion
Mastering Mode (using tracks 7
& 8) with EQ, compressor and
effects
10 preset Mastering Libraries:
Flat, Wet Mix, Light Mix, Live
Mix, Pop Mix, Dance, Hard, 70's,
Hall and Lo-Fi modes
2 x inputs with phantom
powered balanced XLRs and
unbalanced 6mm jacks. Trim
controls, on/off switches and
peak LED indicators
Stereo Out
7 x track faders and 1 x Master
fader (stereo buss) - all 60mm
Full MTC/MMC compliance,
MIDI clock & song position
pointer
2-band EQ on channels 1-6
(shelving type) plus 36 EQ
presets
99 mix scene memory per
program with title edits
Non-destructive, non linear
Copy/Move-Paste / Erase audio
editing
Jog wheel audio scrubbing
with wave-form display
Clipboard data available to be
pasted to the same, another, or
multiple tracks and automatically
repeated up to 99 times.
S/P DIF digital I/O
DIGITAL RECORDER
Full digital 8-track multitrack
recorder
Optional internal CD-R/RW
drive for mastering & back-up
8 recording tracks plus 16
additional ghost tracks for
multiple takes. 24 recording
tracks in total
No compression recording to
internal, user upgradable,
3.5" E-IDE hard disc
Up to 7.8 hours of 8 track
recording on 20GB hard disc
.WAV file import/export (via CD)
6/6/02 11:27 AM Page 1
U U P P G G R R A A D D A A B B L L E E H H A A R R D D D D R R I I V V E E
The removable plate on the
underside of a VF80 allows
you to change the internal
E-IDE hard drive. A larger
hard drive means more
recording time.
Visit w w w w w w . . f f o o s s t t e e x x . . c c o o . . j j p p for a
list of compatible drives.
D D I I G G I I T T A A L L M M U U L L T T I I T T R R A A C C K K E E R R
This 8-Track Digital Power Tool is in the
tradition of its 16-Track predecessor, the VF160.
It's an all-in-one solution to today's recording
needs—a digital hard disk recorder, digital mixer
with built-in effects, a digital editor with cut,
copy, paste functions, and a digital mastering
device with optional built-in CD burner..
And if you're a guitar player,
love the dedicated guitar inputs and simulation-
effects controls. These are not just overworked
tone controls, these are useful, power ful
algorithms that will help you create new sounds.
I I N N T T U U I I T T I I V V E E O O P P E E R R A A T T I I O O N N
The VF80 is just so easy to operate. Large illuminated
buttons change color depending on mode of operation,
60mm faders offer precise tracking and a clear backlit
LCD display make for easy sound editing and feature
selection.The bounce feature makes for easy 'single
button push' mix-down.
you're really going to
F F L L E E X X I I B B L L E E I I N N P P U U T T S S T T A A G G E E
Both inputs have balanced and
unbalanced connectors, trim control
and switchable +48V phantom power.
* * O O P P T T I I O O N N A A L L C C D D - - R R / / R R W
Y ou can retro-fit your VF80 with an
optional CD-R/RW drive which will
allow you to master digital audio CD's.
But that's not all. Hard disc data can
also be backed up to data CDs.
WAV file import and export is
supported via CD media.
O O N N E E - - B B U U T T T T O O N N B B O O U U N N C C I I N N G G
The bounce function allows audio from
tracks 1 through 6 to be bounced to
tracks 7/8 at the touch of a button.
W
D D E E D D I I C C A A T T E E D D M M A A S S T T E E R R I I N N G G E E F F F F E E C C T T S S
Y ou can add dedicated digital master
effects whilst mastering tracks 7 & 8 to
external stereo recorder or internal CD.
