Low Voltage - B-K lighting PS Installation Instructions Manual

with
Installation Instructions
TRANSFORMER HOUSING MUST BE INSTALLED ABOVE GRADE.
TRANSFORMER HOUSING INSTALLED BELOW GRADE WILL VOID WARRANTY
Anchor Base Installation
1. Determine suitable anchors (By Others) to
attach anchor base to architectural surface.
2. Place provided template in final mounting
position according to designed lighting plan.
3. Drill holes into surface for maximum 7/16"
120V 12V
fasteners (By Others) on locations illustrated Remote
on template. Base mounting hole locations is
Transformer
1-1/2" on center by 3-1/2" on center apart.
COM COM
120V 12V
Integral
Transformer
COM COM
GROUND GROUND
WIRING DIAGRAM
Integral Transformer
6. Use waterproof wire
(By Others) to make watertight connections
from transformer primary leads to branch circuit
wires. Connect incoming ground to ground wire
provided in fixture body. See wiring diagram.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
& Low Voltage
TECHNOLOGY
TECHNOLOGY
4. Pull low voltage wire or pull branch circuit
wires necessary for installation (By Others)
through anchor base.
Anchor base can accommodate up to two (2)
1/2" conduits.
Fixture
Fixture
7. Place fixture on anchor base and tighten four
(4) #10-32 stainless steel button head cap
screws using a 1/8" Allen wrench.
connectors
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX 559.438.5900
www.bklighting.com • info@bklighting.com
PS™ / BS™/ PSL™ / BSL™
PROJECT:
BS-LED
S000891
TYPE:
120V
Transformer
COM
WIRING DIAGRAM
120V
Remote Transformer
Transformer
5. Make watertight connections from remote
transformer to fixture source
waterproof wire connectors (By Others). See
COM
wiring diagram.
GROUND
8. Use 1/8" Allen wrench to loosen #10-24 stainless
faceplate screws to remove faceplate. for access
to source.
RELEASE DATE
5-23-18
12V
Remote
Fixture
COM
12V
Integral
Fixture
leads using
COM
GROUND
REFERENCE NUMBER
INS000733
