TECHNICAL REFERENCE
microSync
HR102/DC
January 7, 2022
Meinberg Funkuhren GmbH & Co. KG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroSync and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meinberg MicroSync

Summary of Contents for Meinberg MicroSync

  • Page 1 TECHNICAL REFERENCE microSync HR102/DC January 7, 2022 Meinberg Funkuhren GmbH & Co. KG...

  • Page 3: Table Of Contents

    1 Imprint 2 microSync Introduction 3 Technical Specifications microSync Chassis 4 Important Safety Information Important Safety Instructions and Protective Measures ......
  • Page 4 11 RoHS and WEEE 12 Declaration of Conformity Date: January 7, 2022 microSync...

  • Page 5: Imprint

    1 Imprint 1 Imprint Meinberg Funkuhren GmbH & Co. KG Lange Wand 9, 31812 Bad Pyrmont, Germany Phone: + 49 (0) 52 81 / 93 09 - 0 Fax: + 49 (0) 52 81 / 93 09 - 230 Website: https://www.meinbergglobal.com...

  • Page 6: Microsync Introduction

    2 microSync Introduction microSync is a multipurpose synchronization solution with compact design and high performance. The mi- croSync system provides multiple output signals and allows synchronization of both NTP clients and PTP slaves. The device has four 100/1000 MBit network interfaces and can provide both, optical and electrical network connections by using SFP modules.

  • Page 7: Technical Specifications Microsync Chassis

    3 Technical Specifications microSync Chassis 3 Technical Specifications microSync Chassis Protection Rating: IP30 Operating Temperature: –20 to 55 C (–4 to 131 F) As tested per IEC 60068-2-1, Cold: –40 C (–40 F) As tested per IEC 60068-2-2, Dry Heat: 85 C (185 F) Storage Temperature: –30 to 70 C (–22 to 158 F)

  • Page 8: Important Safety Information

    ATTENTION! This signal word refers to a procedure or other action that may result in product damage or the loss of important data if not observed or if improperly performed. Date: January 7, 2022 microSync...

  • Page 9: Used Symbols

    Dieses Produkt fällt unter die B2B Kategorie. Zur Entsorgung muss es an den Hersteller übergeben werden. This product is handled as a B2B-category product. To ensure that the product is disposed of in a WEEE-compliant fashion, it must be returned to the manufacturer. microSync Date: January 7, 2022...
  • Page 10 The product manuals are provided on a USB flash drive delivered with the system. The manuals can also be downloaded from the Meinberg website at https://www.meinbergglobal.com, where you can enter your system name into the search box at the top of the page to find the relevant manual. Alternatively, contact Meinberg Support for further assistance.

  • Page 11: Security During Installation

    For safety reasons, the device with the highest mass should be installed in the lowest position of the rack. Other devices must be placed from the bottom to the top. The device must be protected against mechanical stress such as vibration or shock. microSync Date: January 7, 2022...
  • Page 12 17 AWG – 13 AWG The device must be supplied with a suitable disconnector (switch). The separation device must be easily accessible, placed near the device and marked as a separation device for the unit. Date: January 7, 2022 microSync...

  • Page 13: Safety Information On Sfp Modules

    fiber optic or electrical connection. The safety information below must be read and heeded before installing an SFP module in a Meinberg device, before setting up a Meinberg device equipped with SFP modules for use, or before performing maintenance on such a Meinberg device.

  • Page 14: Connection Of Protective Earth Conductor/Grounding

    If your device is connected to an Uninterruptible Power Supply (UPS), it will remain operational even after pulling the UPS power cable from the mains socket. In this case, you will need to shut down your UPS in accordance with the user documentation of your UPS system. Date: January 7, 2022 microSync...

  • Page 15: Safety During Maintenance

    • Never dispose of the battery in a mechanical crusher or shredder, or in an open fire or furnace. • Please consult your local waste disposal regulations for information on how to dispose of hazardous waste. microSync Date: January 7, 2022...
  • Page 16 The battery is used to power components such as the RAM and the reserve real-time backup clock for the reference clock. If the battery voltage drops below 3 V DC, Meinberg recommends having the battery replaced. If the battery voltage drops below the specified minimum, the following behavior may be observed in the reference clock: •...

  • Page 17: Cleaning And Care

    ESD-proof bags that are crumpled or have holes cannot provide effective protection against electrostatic discharges. ESD-proof bags must have a sufficient electrical resistance and must not be made of conductive metals if the device has a lithium battery fitted on it. microSync Date: January 7, 2022...

  • Page 18: Return Of Electrical And Electronic Equipment

    When disposing of your old equipment, please use the national return or collection systems available to you. Alternatively, you may contact Meinberg, who will provide further assistance. The return of electronic waste may not be accepted if the device is soiled or contaminated in such a way that it potentially presents a risk to human health or safety.

  • Page 19: Microsync Hr102/Dc - Connectors

    5 microSync HR102/DC - Connectors 5 microSync HR102/DC - Connectors 5.1 GPS Antenna Antenna input GNS: Antenna circuit electrically isolated Dielectric strength: 1000 V Mixed frequency Reference clock to antenna (GPS-converter): 10 MHz IF frequency Antenna (GPS-converter) to reference clock: 35.4 MHz...

  • Page 20: Programmable Pulse Output

    PTTI 1PPS 5.3 Time Code AM (modulated) Output Signal outputs: Unbalanced sine wave-signal Signal level: / 1 V (MARK/SPACE) into 50 Ohm Carrier frequency: 1 kHz (IRIG-B) Connection type: BNC female Cable: shielded coax line Date: January 7, 2022 microSync...

  • Page 21: Frequency Synthesizer Output

    5 microSync HR102/DC - Connectors 5.4 Frequency Synthesizer Output Output signal unbalanced sinusoidal signal Frequency output: 0,1 Hz - 10 MHz F. Synth Out Signal Level: into 50 Connection type: BNC, female Cable: shielded coax line 5.5 RS-232 COMx Timestring...

  • Page 22: Status Indicators - Cpu And Receiver

    No synchronization resp. no antenna connected or short circuit on the antenna line green: Antenna connected and clock is synchronized green: Positioning complete Init blue: Initialisation phase green: "warmed up" - oscillator is adjusted —————————————————————————– Date: January 7, 2022 microSync...

  • Page 23: Usb Interface

    5 microSync HR102/DC - Connectors 5.7 USB Interface Signal Signal Type Connector —————————————————————————– USB Terminal USB-to- Micro-USB Type B serial console USB Host USB connector USB Type A management CPU 5.8 LAN Network Interfaces Gigabit Ethernet (GbE), 100/1000 MBit - SFP...
  • Page 24 Available SFP Modules SFP Tranceivers Recommended and Tested by Meinberg Output Type Manufacturer Designation Multi Mode: Avago AFBR-5710PZ Finisar FTLF8524P3BNL Single Mode: Avago AFCT-5710PZ Finisar FTLF1318P3BTL RJ-45: Avago ABCU-5740RZ Finisar FCLF8521P2BTL WARNING! Prevention of Eye Injuries Fiber optic SFP modules that are not compliant with the definition of a Ÿ...

  • Page 25: Dmc X2 Terminal Connector

    5 microSync HR102/DC - Connectors 5.9 DMC X2 Terminal Connector Note: The connector on the device side and the connection socket of the X2 terminal are provided with coding pins to avoid confusion with the X1 connection terminal. Pin 1...

  • Page 26: Fiber Optic - Programmable Pulse Output

    Serial Time String 10 MHz Frequency Synthesizer Frequency PTTI 1PPS ATTENTION! The optical interface contains a light-emitting diode (LED). Optical interfaces connected should always have the protective cap placed on them when not in use. Date: January 7, 2022 microSync...

  • Page 27: Dmc X1 Terminal Connector / Dc Power Supply

    5 microSync HR102/DC - Connectors 5.11 DMC X1 Terminal Connector / DC Power Supply Note: The connector on the device side and the connection socket of the X1 terminal are provided with coding pins to avoid confusion with the X2 connection terminal.
  • Page 28 "NC" is active. Technical Specification Switching Voltage max: 60 V DC Error Mode: CO - NC connected (normally closed) Switching Current max: 400mA Switching Load max: 24 W Response Time: ca.2ms Date: January 7, 2022 microSync...

  • Page 29: Gnss Satellite Navigation

    At an orbital altitude of 23,222 km above the Earth’s surface, the satellites require around 14 hours for a full orbit. microSync Date: January 7, 2022...

  • Page 30: Time Zones And Daylight Saving Time

    GPS receivers to be synchronized internally with the international UTC timescale. The receiver’s microprocessor can identify any time zone based on UTC time and automatically apply Day- light Saving Time adjustments over several years if so configured by the user. Date: January 7, 2022 microSync...

  • Page 31: Installation Of The Gps Antenna

    • clear view towards equator (if clear view of 8 not possible) or • clear view between 55th north and 55th south parallels (satellite orbits). Problems may arise if all of these views are obstructed, as four satellites must be located to calculate a new position. microSync Date: January 7, 2022...
  • Page 32 Type-N (Male) If installed in a waterproof housing, the MBG S-PRO Type-N (Female) can be installed outdoors. However, Meinberg recommends installing the surge protector indoors—as closely to the entrance point of the antenna cable as possible—in order to minimize the risk of surge damage (such as that caused by lightning strike).
  • Page 33 The next step is to connect the supplied coaxial cable from the surge protector to the receiver. Type-N (Female) Type-N (Male) Receiver Optional Antenna Splitter SMA (Male) SMA (Female) BNC (Male) BNC (Female) Type-N (Male) Type-N (Female) microSync Date: January 7, 2022...
  • Page 34 When using a different type of coaxial cable, please use the "By Delay" option. You will need to calculate the delay yourself using the information provided in the product specifications provided by the manufacturer of your coaxial cable. Date: January 7, 2022 microSync...

  • Page 35: Starting Of Operation

    The software is delivered on the USB stick included in the scope of delivery and does not need to be in- stalled or copied on the PC. The Meinberg Device Manager can be started directly from the USB data carrier.

  • Page 36: Initial Network Configuration

    USB stick. You can always download the latest version from our website: https://www.meinbergglobal.com/english/sw/mbg-devman.htm If the network settings of your PC do not allow a connection to the microSync system, you have to adjust the settings of your network adapter. At delivery the microSync system has the following network settings: IP v4 address 192.168.19.79...

  • Page 37: Network Configuration With The Mbgoswizard

    Another way for initial configuration of the IP address of the microSync is the serial USB interface. You can connect the USB port on the PC with the micro-USB port on the microSync using a standard USB ca- ble, as used for many mobile phones. Via the system settings of your PC you can now find out which COM port is being used.

  • Page 38: Initial Start Of Operation

    Meinberg Device Manager software directly on the USB stick: USB Drive/Software/MbgDevMan/mbgdev- man_portable/mbgdevman.exe. By clicking on the Search Devices button, all available microSync systems that have a serial or a network connection are recognized by the Meinberg Device Manager and will be listed then.
  • Page 39 User and Password fields are already filled out. Silent Login You have the option that the Meinberg Device Man- ager does not ask for a user name and password every time you log in. Custom Alias Assign a custom alias for better identification of indi-...

  • Page 40: Technical Appendix

    Framing: 7E1, 7E2, 7N2, 7O1, 7O2, 8E1, 8N1, 8N2, 8O1 Default Setting: COM 0: 19200, 8N1 Meinberg Standard time string, per second Time Code Outputs: Unbalanced modulated sine wave signal: (MARK), 1 V (SPACE) into 50 PWM DCLS-signal: TTL into 50...
  • Page 41 L1C/A Galileo: E1B/C Cable length: max. 300 m (RG58 coax-cable) Antenna Connector: BNC female Power Supply 15 V DC, continuous short circuit protection, automatic recovery for Antenna: isolation voltage 1000 VDC, provided via antenna cable microSync Date: January 7, 2022...

  • Page 42: Configuration Options

    9.2 Configuration Options Receiver Options RECEIVER TYPE SIGNAL TYPE VALUE CONNECTOR Meinberg GPS IF, 12-channel IF (Meinberg Antenna)) 15 V DC Meinberg GNS-UC GPS/Galileo IF IF (Meinberg Antenna)) 15 V DC GNSS (GPS, GLONASS, Galileo, BeiDou), 72-channel L1/E1/B1 band 5 V DC...

  • Page 43: Technical Appendix: Gps Antenna + Accessories

    10 Technical Appendix: GPS Antenna + Accessories 10 Technical Appendix: GPS Antenna + Accessories Physical Dimensions: microSync Date: January 7, 2022...
  • Page 44 Type-N Female Form Factor: ABS Plastic Case for Outdoor Installation IP Rating: IP66 Humidity: 95 % Temperature Range: -40 C to +85 C (-40 to 185 F) Weight: 1.6 kg (3.53 lbs), Including Mounting Kit Date: January 7, 2022 microSync...

  • Page 45: Antenna Cable

    If this message appears, the clock must be switched off and the cause of the problem must be eliminated before the clock can be switched back on. The supply voltage for the antennas/converter unit is around 15 V DC with the antenna connected. microSync Date: January 7, 2022...

  • Page 46: Technical Specifications: Mbg S-Pro Surge Protection

    5 A (25 C) Effective Operating Current: IC at UC Rated Discharge Current: In (8/20) s (Core-Earth) 20 kA In (8/20) s (Core-Shield) 20 kA Total Surge Current: (8/20) s 20 kA (10/350) s 2.5 kA Date: January 7, 2022 microSync...
  • Page 47 The original product page of the supplier (see link) of the CN-UB-280DC-BB surge protector is the source of the specifications above. Please refer to the manufacturer’s product page at the following link for detailed specifications as well as a variety of product-specific documents: https://www.phoenixcontact.com/online/portal/gb/?uri=pxc-oc-itemdetail:pid=2818850 microSync Date: January 7, 2022...

  • Page 48: Mbg S-Pro: Physical Dimensions

    10.3.1 MBG S-PRO: Physical Dimensions 15,8 10.3.2 Installation and Grounding Date: January 7, 2022 microSync...
  • Page 49 WEEE-compliant fashion, it must be returned to the manufacturer. Any transportation ex- penses for returning this product (at end-of-life) must be covered by the end user, while Meinberg will bear the costs for the waste disposal itself. microSync...
  • Page 50 12 Declaration of Conformity Declaration of Conformity Doc ID: microSync HR102/DC-January 7, 2022 Hersteller Meinberg Funkuhren GmbH & Co. KG Manufacturer Lange Wand 9, D-31812 Bad Pyrmont erklärt in alleiniger Verantwortung, dass das Produkt, declares under its sole responsibility, that the product...
