Graf AquaControl + User Information page 13

Now open the transparent cover of the system controls. Plug the equipment into the
mains socket (this socket must be exclusively for the equipment and be on its own
fuse). The system then runs a system check through automatically.
For the duration of the system check (approx. 10 seconds) the following signal will
be displayed in the window:
Figure 6: Display during the equipment check
The equipment type is shown on the first line and the software check in progress is
shown in the second line.
If after the initial installation check all is correct, the LCD indicator will display the
fill level (in %).
The figure 7 shows the LCD-display in the operation mode. The display shows the
filling level and the operating modes as abbreviations: "FV" and "P". These abbre-
viations correspond as follows:
FV+ :
–
FV- :
–
P+ :
–
P- :
–
Tank:
50%
Fill level in %
Figure 7: Display in the operation mode
REV 3.1
filter valve opened
filter valve closed
(pump on) house waterworks in operation
(pump off) no water currently being withdrawn
FV- P-
AQ +
Status of rain water
filter flashing valve
Status house waterworks
(pump + on / - off)
Visual check of the fill level
