Installer's Guide
Side Discharge AC Models
For coastal applications where units are installed within one (1) mile of salt water, epoxy coated models are recommended.
These models have an 8 week lead time after order.
4A7L6018A1000A
4A7L6024A1000A
4A7L6030A1000A
4A7L6036A1000A
4A7L6042A1000A
4A7L6048A1000A
4A7L6060A1000A
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and
air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
October 2018
E E p p o o x x y y C C o o a a t t e e d d M M o o d d e e l l
4A7L6018A1COTA
4A7L6024A1COTA
4A7L6030A1COTA
4A7L6036A1COTA
4A7L6042A1COTA
4A7L6048A1COTA
4A7L6060A1COTA
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
1 1 1 1 - - A A C C 4 4 0 0 D D 1 1 - - 1 1 E E - - E E N N
N N o o t t e e : : "Graphics in this document are for
representation only. Actual model may differ in
appearance."
