Hitachi Compute Rack 220S
CRU Replacement Guide
F
F
L
AS T
IN D
IN K S
Getting Help
Contents
MK-90CRS003-01

Advertisement

Table of Contents
loading

Related Manuals for Hitachi Compute Rack 220S

Summary of Contents for Hitachi Compute Rack 220S

  • Page 1 Hitachi Compute Rack 220S CRU Replacement Guide AS T IN D IN K S Getting Help Contents MK-90CRS003-01...
  • Page 2 Hitachi, Ltd. Hitachi, Ltd., reserves the right to make changes to this document at any time without notice and assumes no responsibility for its use. This document contains the most current information available at the time of publication.

  • Page 3: Table Of Contents

    Overview ......................2-2 Location ......................2-5 Preparation ..................3-1 Basic Replacement Procedure................3-2 Unpack a spare component ................3-4 Powering off system unit ...................3-4 Sliding out the system unit for maintenance ............3-5 Removing/Installing the cover ................3-7 Contents Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 4 Notice of maintenance by maintenance person ........... 5-2 Changing a network adapter's MAC address............5-2 Restoring the Web console or Remote Console settings ........5-3 BIOS resetting....................5-3 Windows BitLocker recovery password ............... 5-4 Contents Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 5: Preface

    Convention for storage capacity values  Getting Help  Comments  Notice: The use of Compute Rack and all other Hitachi Data Systems products is governed by the terms of your agreement(s) with Hitachi Data Systems. Preface Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 6: Intended Audience

    Referenced Documents Compute Rack 220S (CR 220S) documents: Hitachi Compute Rack 220S Getting Started Giode, MK-90CRS001  Hitachi Compute Rack 220S User's Guide, MK-90CRS002 ...

  • Page 7: Document Conventions

    [ ] (square bracket) Optional values { } braces Required or expected value | vertical bar Choice between two or more options or arguments _(underline) Default value, for example, [a | b] Preface Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 8: Convention For Storage Capacity Values

    Getting Help The Hitachi Data Systems customer support staff is available 24 hours a day, seven days a week. If you need technical support log on to the Hitachi Data Systems Portal for contact information: https://portal.hds.com. Comments Please send us your comments on this document: doc.comments@hds.com.

  • Page 9: Safety Guidelines

    Safety guidelines This section contains warnings and important safety guidelines for using a Hitachi Compute Rack System. Read and understand the information in this section before removing, replacing and installing system components. This section includes the following key topics:  Safety information ...

  • Page 10: Safety Information

    This indicates a general action to take. Action by following the instructions Mandatory in this guide. Sign Unplug Power This indicates unplugging the power cable from the outlet to avoid electric cord shock and fire. Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 11: Common Precautions Concerning Safety

    Do not touch the power plug with moistened hands.  Do not place any objects around the electrical outlets in order to allow  users to quickly unplug the power cables. Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 12 After removing a power supply, install a power slot cover. Inside the power slot, some conductors are exposed. If you touch them with your hand or tool, it may cause electric shock or equipment failure. Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 13 Use peripherals, internal components, signal cables, and AC cables that  the manual describes as supported. Otherwise, compatibility issues might occur and malfunction of the peripherals, internal component, and the system unit. Also burn, smoke, or fire might occur. Safety guidelines xiii Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 14 Contact with metal edges When moving the equipment or adding parts, take care not to hurt yourself on the metal or plastic edges. You can wear cotton gloves to protect your hands. Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 15 When storing batteries, apply adhesive tape on the terminals for insulation. If the batteries are stored without insulation, the terminals can contact each other to cause a short-circuit and overheat or burst, leading to injury or fire. Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 16: Precautions Against Damage To Equipment

    Using devices other than those mentioned above would cause a failure in peripheral devices and equipment due to the difference in connection specifications. Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 17 When you change the configuration of the system unit (DIMM, fan, PCI card, or peripherals), disconnect all the power plugs and wait 30 seconds and more before the procedure. Otherwise, residual electric charge might cause malfunction. Safety guidelines xvii Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 18 When you are using an OS which requires the shut down procedure, be  sure to finish the shut down procedure before turning off the power. Otherwise, data may be lost. xviii Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 19 Reliable Earthing  Reliable earthing of rack-mounted equipment should be maintained. Pay particular attention to supply connections other than direct connections to the branch circuit (e.g. use of power strips)." Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 20: Safety And Warning Labels

    Safety and warning labels The location and content of the warning and safety labels on the CR 220S are shown here. Safety guidelines Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 21: Introduction

    Introduction This chapter describes user replacement overview for the Hitachi Compute Rack System.  User Replacement Guideline  User maintenance tasks  When a failure occurs  LED overview Introduction Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 22: User Replacement Guideline

    The LEDs are described in this chapter. User maintenance tasks The maintenance tasks described in this manual follow the Hitachi Data Systems Customer Support program. The Hitachi Data Systems self-service program allows users to perform ...

  • Page 23: When A Failure Occurs

    Replacing the parts after the spare parts arrive and Follow instructions in this checking the recovery from the failure. document to replace the failed part. Return the failed part Return the replaced parts. Introduction Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 24: Led Overview

    Operation panel Operation panel on page 1-5 Green-On Accessing HDD. Amber-On Error occurred. HDD status LED Amber-Blink* On-going data rebuild. * The LED lights green while the HDD is being accessed for rebuilding. Introduction Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 25 Green-On ACCESS LED Accessing HDD/SSD. HDD errors, fan errors, power supply errors, or other Amber-On ERROR LED hardware errors occur. SERVICE switch Press the SERVICE switch to turn on/off the SERVICE LED. Introduction Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 26 Table 1-5: Event code indicate MAINTENANCE LED Where the error occurred CPUs Memory Motherboard Power / Voltage Fans Temperature Other hardware All off Normal operation Introduction Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 27 450 W or more and less than 500 W 1 through 7 are On 500 W or more and less than 550 W 1 through 8 are On 550 W or more Introduction Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 28 The system unit doesn't start unless the SERVICE LEDs finish blinking. So you will have to wait the system to start until the LEDs finish blinking if you press the POWER switch while the SERVICE LEDs are still blinking. Introduction Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 29 LAN cable when you use the remote Management management function. interface connector For the details of the remote management function, see Remote Management User’s Guide. * The LED lights green while the HDD is being accessed for rebuilding. Introduction Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 30 Onboard LAN4: PCI bus 6, device 0, function 3 – The number of the network adapter which is the network interface  connector recognized by the device manager may not match to the network interface connector number. 1-10 Introduction Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 31 If you find the communication is unstable, turn off the system unit,  shut down the AC power by, for example, disconnecting the AC cable, wait 30 seconds or more, and then reconnect AC power and turn on the system unit. Introduction 1-11 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 32 1-12 Introduction Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 33: Replaceable Parts

    Replaceable parts This chapter describes the user replaceable parts of the CR 220S. Overview  Location  Replaceable parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 34: Overview

    Memory, 2GBx1, 1600MHz DDR3 RDIMM Memory 4GBx1, 1600 RDIMM GQ-MJ7004H4-R Memory, 4GBx1, 1600MHz DDR3 RDIMM Memory 8GBx1, 1600 RDIMM GQ-MJ7008H4-R Memory, 8GBx1, 1600MHz DDR3 RDIMM Memory 16GBx1, 1600 RDIMM GQ-MJ7016H4-R Memory, 16GBx1, 1600MHz DDR3 RDIMM Replaceable parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 35 Parts Product name Code Specification HBA, Hitachi 8Gb Dual Port, GQ-CC7841-R HBA, Hitachi 8 Gbps, Dual Port (Full Height) card Full Height HBA, Hitachi 8Gb Dual Port, GQ-CC7842-R HBA, Hitachi 8 Gbps, Dual Port (Low Profile) Low Profile LAN Card, 1Gb Dual Port...
  • Page 36 In the CR 220S, the following CRUs are non hot-swappable: – Fan. See Replacing a fan on page 4-10. – DIMM. See Replacing a DIMM on page 4-13. – PCI card. See Replacing a PCI card on page 4-19. Replaceable parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 37: Location

    GQ-UH7400NSM-R 3.5 inch HDD SAS 300GB, 10000rpm, GQ-UH7300UVHM-R 2.5 inch HDD SAS 450GB, 10000rpm, GQ-UH7450UVHM-R 2.5 inch HDD SAS 600GB, 10000rpm, GQ-UH7600UVHM-R 2.5 inch HDD SAS 900GB, 10000rpm, GQ-UH7900UVHM-R 2.5 inch Replaceable parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 38 Parts Product name Code SSD SATA 200GB, EMLC, 2.5 inch GQ-UH7200XCM-R Power supply Power Supply 800W GQ-BP2361-R Notes: 1 Hot-swappable component. 2 When an optional Rear HDD kit (ES7623-Y/ES7623-R) is installed. Replaceable parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 39 Memory 8GBx1, LV RDIMM GQ-MJ708GL3-R Memory 16GBx1, LV RDIMM GQ-MJ716GL3-R DIMM Memory 2GBx1, 1600 RDIMM GQ-MJ7002H4-R Memory 4GBx1, 1600 RDIMM GQ-MJ7004H4-R Memory 8GBx1, 1600 RDIMM GQ-MJ7008H4-R Memory 16GBx1, 1600 RDIMM GQ-MJ7016H4-R Replaceable parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 40 2 1600 RDIMM (1600 MHz) and LV RDIMM (1333 MHz DDR3) cannot be mounted together in the system unit. 3 CN7721-Y/CN7721-R and CN7723-Y/CN7723-R cannot be mounted together in the system unit. Replaceable parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 41: Preparation

    This chapter describes a preparation of replacing components of the system unit. Basic Replacement Procedure  Unpack a spare component  Powering off system unit  Sliding out the system unit for maintenance  Removing/Installing the cover  Preparation Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 42: Basic Replacement Procedure

    Remove failed part Install spare part Install spare part Rebuild/copy automatically After Replacing After Replacing Check the ERROR LED turned off Check the ERROR LED turned off Figure 3-1: Basic procedure – hot-swappable component Preparation Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 43 Push back the system unit Push back the system unit Power on Power on Check the ERROR LED turned off Check the communication is back Figure 3-2: Basic procedure – non hot-swappable component Preparation Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 44: Unpack A Spare Component

    POWER switch. In this case, wait until the power will be turned off. The fans inside the power supplies of the system unit continue  running unless the AC power source is turned off. 4. Turn off the peripherals. Preparation Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 45: Sliding Out The System Unit For Maintenance

    When do maintenance of the system unit, slide out the system unit from the rack cabinet. 1. Disconnect all the cables from the system unit. See Hitachi Compute Rack 220S Getting Started Guide. 2. Remove an optional front bezel (AU7706-Y/AU7706-R) if any. See Hitachi Compute Rack 220S Getting Started Guide.
  • Page 46 The cable clamps may be damaged. 2. Perform reverse procedure of the removal to install a front bezel and connect external cables. Sliding out the system unit from a rack cabinet. Preparation Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 47: Removing/Installing The Cover

    2. Press the two release latches and slide the front top cover toward the front of the system unit. 3. Lift up and remove the top cover from the system unit. Release latch Release latch Figure 3-5: Remove the front top cover Preparation Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 48 4. Press and slide the rear top cover toward the rear of the system unit. 5. Lift up and remove the rear top cover from the system unit. Figure 3-6: Remove the rear top cover Preparation Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 49 3. Tighten the two captive screws at the rear of the system unit. Figure 3-7: Install the rear top cover 4. Reinstall the system unit to the rack cabinet. Sliding the system unit into a rack cabinet on page 3-6. Preparation Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 50 Release latch Release latch Figure 3-8: Install the front top cover 5. Reinstall the system unit to the rack cabinet. Sliding the system unit into a rack cabinet on page 3-6. 3-10 Preparation Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 51: Replacing Parts

    This chapter describes the procedure for removing and installing components of the system unit.  Replacing an HDD/SSD  Replacing a power supply  Replacing a fan  Replacing a DIMM  Replacing a PCI card Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 52: Replacing An Hdd/Ssd

    The correspondence between the extension storage bay numbers and the bay configuration label on the side tab of the extension storage bays is as follows. Table 4-1: Extension storage bay and Bay configuration label Extension storage bay Bay configuration label Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 53 Do not make an impact on the HDD/SSD. Wait at least 30 seconds before removing the HDD. Removing the failed HDD during its motor rotating may damage other HDDs and cause unexpected failures. Figure 4-2: Remove a failed HDD (Front side) Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 54 When the HDD/SSD stops at the bottom, slowly close the lever to lock the HDD tray. NOTICE Install the replacing HDD/SSD in the same extension storage bay where the failed HDD/SSD has been removed. Otherwise, data may be lost. Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 55 HDD/SSD turns off or lights solid green. During rebuilding data in progress, the HDD status LED blinks amber. Do not turn off the power of the system unit during rebuilding data. Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 56: Replacing A Power Supply

    Do not disconnect the AC cable connected to the power supply which is operating normally. If you do, the power to the system unit will be turned off and the data may be lost. Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 57 4. Grasp the handle and push the lock tab, and then pull out the failed power supply slightly. 5. Hold the body of the failed power supply, and then pull out it straight forward. Handle Lock tab Figure 4-8: Remove a failed power supply Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 58 4. Fix the AC cable using a cable clamp attached to the power supply in order to avoid unintended disconnection. After the AC cable is fixed, push the cable clamp all the way toward the power plug. Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 59 Improper position Proper position Figure 4-10: Fixing AC cable using the cable clamp 5. Make sure that the power supply LED of installed power supply lights solid green. Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 60: Replacing A Fan

    Fan slot 2 Fan slot 7 Fan slot 3 Fan slot 8 Fan slot 4 Fan slot 9 Fan slot 5 Fan slot 10 Figure 4-11: Location of fan slot 4-10 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 61 4. Check which fan slot you need to remove the fan module from. 5. Grasp the fan, press the release latch of fan, and then lift it out of straight upward. Release latch Figure 4-12: Remove a fan Replacing parts 4-11 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 62 3. Install the front top cover of the system unit. Installing the front top cover on page 3-10. 4. Reinstall the system unit to the rack cabinet. Sliding the system unit into a rack cabinet on page 3-6. 4-12 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 63: Replacing A Dimm

    Each memory slot is indicated on the motherboard as follows. Table 4-2: Memory slot indicated on the motherboard Memory slot indicator on the motherboard CPU1_DIMM1 CPU2_DIMM1 CPU1_DIMM2 CPU2_DIMM2 CPU1_DIMM3 CPU2_DIMM3 CPU1_DIMM4 CPU2_DIMM4 CPU1_DIMM5 CPU2_DIMM5 CPU1_DIMM6 CPU2_DIMM6 Replacing parts 4-13 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 64 Pull out the cache backup cable from the through hole of the air baffle. Cache backup module Cache backup cable Through hole Cache backup cable Figure 4-14: Remove the cache backup cable 4-14 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 65 LED flat cable HDD backplane Cushion SAS cable Through hole LED flat cable SAS cable Figure 4-15: Remove the SAS cable and LED flat cable Replacing parts 4-15 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 66 Make sure you do not bend the electrolytic capacitors when  opening the lock tabs of a memory slot. Otherwise, the motherboard may be damaged. Lock tab Lock tab Figure 4-17: Remove a DIMM 4-16 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 67 Insert the DIMM vertically to the slot. Otherwise, it may cause damages to pins of the connector such as bent pins. The shape of DIMM differs depending on the Product code. Figure 4-18: Install a DIMM Replacing parts 4-17 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 68 8. Install the front top cover of the system unit. Installing the front top cover on page 3-10. 9. Reinstall the system unit to the rack cabinet. Sliding the system unit into a rack cabinet on page 3-6. 4-18 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 69: Replacing A Pci Card

    PCI slot 2 PCI slot 5 PCI slot 4 PCI slot 1 PCI slot 3 Figure 4-19: Location of PCI slot The specification of each PCI slot is as follows. Replacing parts 4-19 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 70 3. Remove the front top cover of the system unit. Removing the front top cover on page 3-7. 4. Remove the rear top cover of the system unit. Removing the rear top cover on page 3-8. 4-20 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 71 8. Pinch the tab of the slot cover, and then slide the slot cover while pulling the tab toward the PCI connectors. 9. Open the slot cover. Slot cover Slot cover PCI riser C PCI riser B Figure 4-21: Open the slot cover Replacing parts 4-21 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 72 Be careful not to fall a dummy cover because it is easy to remove. 10. Pull out the PCI card from the PCI riser. PCI riser C PCI riser B Figure 4-22: Remove a PCI card 4-22 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 73 3. Install the front top cover of the system unit. Installing the front top cover on page 3-10. 4. Reinstall the system unit to the rack cabinet. Sliding the system unit into a rack cabinet on page 3-6. Replacing parts 4-23 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 74 4-24 Replacing parts Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 75: Setup After Maintenance

     Notice of maintenance by maintenance person  Changing a network adapter's MAC address  Restoring the Web console or Remote Console setting  BIOS resetting  Windows BitLocker recovery password Setup after maintenance Hitachi Compute Rack 220S CRU Replacement Guide...

  • Page 76: Notice Of Maintenance By Maintenance Person

    Notice of maintenance by maintenance person Hitachi Data Systems basically provides the latest version of components, BIOS and firmware, when replacement is required for some components due to the system unit failure. As required, unreplaced components or parts, BIOS or firmware might be updated to the latest version.

  • Page 77: Restoring The Web Console Or Remote Console Settings

    If you change the BIOS settings from the factory defaults, note down all the changed setting values after replacement in case of failure. For system BIOS and RAID BIOS settings, see Hitachi Compute Rack 220S BIOS Guide. Similarly, BIOS settings of a PCI card might be returned to the factory defaults when replace a PCI card.

  • Page 78: Windows Bitlocker Recovery Password

    TPM board (EQ7001-Y/EQ7001-R) is installed in the system unit. Strictly manage the recovery password. If the recovery password is  lost, the OS will be unbootable or data will be inaccessible. Setup after maintenance Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 79 Hitachi Compute Rack 220S CRU Replacement Guide...
  • Page 80 Hitachi Data Systems Corporate Headquarters 2845 Lafayette Street Santa Clara, California 95050-2639 U.S.A. www.hds.com Regional Contact Information Americas +1 408 970 1000 info@hds.com Europe, Middle East, and Africa +44 (0) 1753 618000 info.emea@hds.com Asia Pacific +852 3189 7900 hds.marketing.apac@hds.com MK-90CRS003-01...
