System config
FortiGate-3000 Administration Guide
You can also use SNMP to manage the cluster by configuring a cluster interface for
SNMP administrative access. Using an SNMP manager you can get cluster
configuration information and receive traps. For a list of HA MIB fields, see
fields" on page 111
You can change the cluster configuration by connecting to the cluster and changing
the configuration of the primary FortiGate unit. The cluster automatically synchronizes
all configuration changes to the subordinate units in the cluster as the changes are
made.
The only configuration change that is not synchronized is the FortiGate host name.
You can give each cluster unit a unique host name to help to identify cluster members.
You can use the web-based manager to monitor the status and logs of individual
cluster members. See
"To view and manage logs for individual cluster units" on page
You can manage individual cluster units by using SSH to connect to the CLI of the
cluster. From the CLI you can use the execute ha manage command to connect to
the CLI of each unit in the cluster. You can also manage individual cluster units by
using a null-modem cable to connect to the primary cluster unit. From there you can
also use the execute ha manage command to connect to the CLI of each unit in the
cluster. See "To manage individual cluster units" on page 103
•

To view the status of each cluster member

•

To view and manage logs for individual cluster units

•

To monitor cluster units for failover

•

To manage individual cluster units

To view the status of each cluster member
1 Connect to the cluster and log into the web-based manager.
2 Go to System > Config > HA.
3 Select Cluster Members.
A list of cluster members appears. The list includes the cluster ID of each cluster
member as well as status information for each cluster member.
Figure 32: Example cluster members list (active-active cluster)
and "FortiGate HA traps" on page
"To view the status of each cluster member" on page 101
01-28006-0010-20041105
"HA MIB
110.
102.
for more information.
HA
and
