Fortinet FortiGate 3810A-LENC Quick Start Manual

LED State
Green
Power
Off
Green
Status Flashing Green
Off
Green
Port 1 to 8
Flashing
(Right LED)
Green
Off
Green
Port 1 to 8
Amber
(Left LED)
Off
Green
Port 9 and 10
Flashing Green
Visit these links for more information and documentation for your Fortinet product.
• Technical Documentation - http://docs.forticare.com
• Fortinet Knowledge Center - http://kc.forticare.com
• Fortinet Technical Support - http://support.fortinet.com
Package Contents
Connector
Ports 1 to 8
Ports 9 and 10
CONSOLE
USB
ASM1
3810A -LENC
ASM2
USB
Esc Enter
CONSOLE
STATUS
POWER
Optional RJ-45 to DB-9 cable connects
to serial port on management computer
Straight-through Ethernet cables
connect to the Internet or other
networks
Connecting
Connect the following to the FortiGate unit. Ensure the FortiGate unit is placed on a stable
surface or install in a standard 19 inch rack.
• Insert a network cable to port 1. Insert the other end to the router connected to the Inter-
net, or to the modem.
• Connect a network cable to the Internal port. Insert the other end to a computer or
switch.
• Connect the AC Power Cord to the Power Supply.
• Connect the redundant DC Power Supply to the FortiGate unit if applicable.
• Connect the Power Cord to a surge protected power bar or power supply.
Configuration Tools
Web-based manager
The FortiGate web-based manager is an easy to use management tool.
Use it to configure the administrator password, the interface and default gateway addresses,
and the DNS server addresses.
Requirements:
• An Ethernet connection between the FortiGate unit and management computer.
• A web browser such as FireFox or Internet Explorer on the management computer.
Description
The FortiGate unit is on.
The FortiGate unit is running abnormally.
The FortiGate unit is running normally.
The FortiGate unit is running abnormally.
The FortiGate unit is off.
The correct cable is in use and the connected equip-
ment has power.
Network activity at this interface.
No link established.
Connection at 1000 Mb
Connection at 100 Mb
Connection at 10 Mb
The correct cable is in use and the connected equip-
ment has power.
Network activity at this interface.
Type Speed Protocol Description
RJ-45 1000 Base-T Ethernet
LC SFP 1000Base-SX Ethernet
RJ-45 9600 bps RS-232
8/N/1 serial
USB USB
ADM1
ADM2
9 10
1 2 3 4 5 6 7 8
AUX
Fiber optic cable connects
to internal network or Internet
Power cables connect
to power outlets
QuickStart Guide
Esc
© Copyright 2008 Fortinet Incorporated. All rights reserved.
Products mentioned in this document are trademarks or registered trademarks
of their respective holders.
Regulatory Compliance
FCC Class B Part 15 CSA/CUS
6 June 2008
Copper gigabit connection to 10/100/1000 copper networks.
Multimode fiber optic connections to gigabit optical networks for small packet performance
required for voice, video and other multimedia streaming applications.
Optional connection to the management computer. Provides access to the command line
interface (CLI).
Optional connection to a USB key for firmware backup and installation.
Straight-through
and cross over
Ethernet cables
Power alarm
reset button
Power Cable
Optional RJ-45 to DB-9 cable connects
to serial port on management computer
Command Line Interface (CLI)
The CLI is a full-featured management tool. Use it to configure the administrator password,
the interface addresses, the default gateway address, and the DNS server addresses. To
configure advanced settings, see the Tools and Documentation CD included with the
FortiGate unit.
Requirements:
• The RJ-45 to DB9 serial connection between the FortiGate unit and management com-
puter.
• A terminal emulation application (HyperTerminal for Windows) on the management
computer.
ASM1
3810A -LENC
ASM2
USB
Enter 1 2 3 4
CONSOLE AUX
STATUS
POWER
x2 SFP
Transceivers
RJ-45 to
Tools and Documenation
DB-9 Serial Cable
Rack-Mount Brackets
ASM1
3810A -LENC
ASM2
USB
Esc Enter 1 2 3 4 5
CONSOLE AUX
STATUS
POWER
Straight-through Ethernet cables
connect to the Internet or other
networks
FortiGate-3810A-LENC
ADM1
ADM2
9 10
5 6 7 8
01-30006-0478-20080606
QuickStart Guide
FortiGate-30B
ASM1 ADM1
3810A -LENC
ASM2 ADM2
Esc Enter USB 1 2 3 4 5 6 7 8 9 10
CONSOLE AUX
STATUS
POWER
FortiGate
Copyright 2008 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
