Traffic Log; Event Log - Fortinet FortiGate FortiGate-200A Administration Manual

Log config
358
Figure 183:Example traffic and event log filter settings

Traffic log

The Traffic Log records all the traffic to and through the FortiGate interfaces. You can
configure logging for traffic controlled by firewall policies and for traffic between any
source and destination addresses. You can also apply global settings, such as
session or packet log. You can apply the following filters:
Policy allowed The FortiGate unit logs all traffic that is allowed according to the firewall
policy settings.
traffic
Policy violation The FortiGate unit logs all traffic that violates the firewall policy settings.
traffic
Note: You can enable traffic logging for specific interfaces or firewall policies. See
traffic logging" on page 360

Event log

The Event Log records management and activity events, such as when a
configuration has changed or a routing gateway has been added. You can apply the
following filters:
01-28006-0072-20041105
for more information.
Log & Report
"Enabling
Fortinet Inc.
