- Page 1 V6-XL HOVERBOARD -MANUAL-...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Included in the Box Features and Specs Charging the Battery The Ride Jetson App Bluetooth Function How It Works Care and Maintenance Safety Warnings Warranty Product Registration... -
Page 4: Introduction
This product manual can help you understand, use, and maintain your V6-XL. In order to avoid danger caused by collisions, falls, and loss of control, please use caution and learn how to ride the V6-XL safely. Jetson and authorized dealers cannot be held liable for injury or dam- age caused from riding the V6-XL. -
Page 5: Included In The Box
INCLUDED IN THE BOX Charging Cable Charger FEATURES AND SPECS MODEL: V6-XL MOTOR TYPE: HUB WHEEL SIZE: 8.5” CHARGER: 110-240V MAX SPEED: 12 MPH CHARGE TIME: 2 HOURS MAX RANGE: 14 MILES PRODUCT WEIGHT: 30 LBS BATTERY TYPE: LITHIUM ION WEIGHT LIMIT: 275 LBS BATTERY RATED VOLTAGE: 36V, 4.0Ah... - Page 6 1. Pad Sensors 4. Front LED Lights 2. Battery Indicator and Status Light 5. Power Button 3. Wheels 6. Charging Port...
-
Page 7: Charging The Battery
Before your first ride you must fully charge the V6-XL - charge for 4 hours. For every ride after, charge your V6-XL until it is fully charged, and NOT LONGER. Do not leave any chargers plugged in overnight, or leave it plugged in past the charge time. -
Page 8: The Ride Jetson App
THE RIDE JETSON APP The Ride Jetson App is available for download from the App Store and the Google Play Store, and unlocks exciting features on your V6-XL. Simply install the app and connect to your V6-XL via Bluetooth® (as detailed below). -
Page 9: Bluetooth Function
TO CONNECT TO THE RIDE JETSON APP: 1. Open the Ride Jetson app on your handheld device. 2. Tap the Bluetooth symbol in the top left corner of the app to find your V6-XL. 3. Select your hoverboard. Default password is “000000.” (note: To customize your password go to Settings in the App. -
Page 10: How It Works
• Step off with one foot first behind the unit and then step down with the other. • Once you are safely off, power down the V6-XL. If you do not turn it off, it will stay on for 10 minutes allowing you to step on and go again without engaging... - Page 11 HOW TO RIDE • Moving forward: Lean forward on both platforms and/or point your toes downward to move forward. • Moving backward: Lean backward on both platforms and/or push your heels down to move backward. • Turning right: point your left toes downward, rotating the platform forward to turn right.
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE DRIVING RANGE The average range of the V6-XL is 14 miles. However, a lot of factors will affect how far you can go per charge: • Driving surface: A smooth, flat surface will increase driving distance. • Weight: More weight means less distance. - Page 13 • A wheel is blocked (the V6-XL will shut down after 2 seconds). • Battery is low but still being used (the V6-XL will turn the motor off after 15 seconds). • Balancing in a neutral position for over 30 seconds.
-
Page 14: Safety Warnings
• Do not ride after drinking or taking prescription medication. • Do not carry items when riding. • Prior to each ride, inspect each part of the V6-XL to ensure it has been maintained correctly and is functioning properly. • Always give way to pedestrians. - Page 15 ADDITIONAL OPERATION CAUTIONS Do not lift the V6-XL off the ground while it is on and the wheels are in motion. This can result in freely spinning wheels, which may cause injury to yourself or others nearby.
-
Page 16: Warranty
• Jetson® makes no warranty with respect to products or trade accessories not made by Jetson®, including, but not limited to, motors, tires, wheels, and batteries, such products or trade accessories, such items being subject to the original manufacturer’s warranty, if any. -
Page 17: Product Registration
For myself For my child For my grandchild Gift for someone else (adult) Gift for someone else (child) How did you hear about the Jetson V6-XL?: ______________________________________________ _____________________________________________________________________________________ Complete this form and mail it to: Attention: Product Registration Jetson Electric Bikes... - Page 20 V6-XL HOVERBOARD...
