FortiController-5208 Firmware
1
2
3
4
5
6
7
FortiController-5208 System Guide
01-30000-0376-20070615
• Install a TFTP server that you can connect to from the FortiGate internal
interface. The TFTP server should be on the same subnet as the internal
interface.
Before beginning this procedure, it is recommended that you back up the
FortiController-5208 module configuration
If you are reverting to a previous firmware version, you might not be able to
restore the previous configuration from the backup configuration file.
To install firmware from a system reboot
Connect to the CLI using the RJ-45 to DB-9 serial cable port and
FortiController-5208 console port.
Make sure the TFTP server is running.
Copy the new firmware image file to the root directory of the TFTP server.
Make sure one of the FortiController-5208 module interfaces is connected to the
same network as the TFTP server.
To confirm the FortiController-5208 module can connect to the TFTP server, use
the following command to ping the computer running the TFTP server. For
example, if the IP address of the TFTP server is 192.168.1.168:
execute ping 192.168.1.168
Enter the following command to restart the FortiController-5208 module.
execute reboot
The FortiController-5208 module responds with the following message:
This operation will reboot the system!
Do you want to continue? (y/n)
Type y.
As the FortiController-5208 module starts, a series of system startup messages is
displayed. When the following messages appears:
Press any key to display configuration menu..........
......
Immediately press any key to interrupt the system startup.
.
Note: You have only 3 seconds to press any key. If you do not press a key soon enough,
the FortiController-5208 module reboots and you must log in and repeat the execute
reboot command.
If you successfully interrupt the startup process, the following menu appears:
[G]: Get firmware image from TFTP server.
[F]: Format boot device.
[B]: Boot with backup firmware and set as default.
[I]: Configuration and information.
[Q]: Quit menu and continue to boot with default
firmware.
[H]: Display this list of options.
Enter G,F,B,I,Q,or H:
Installing firmware images from a system reboot using the CLI
