Lennox MERIT Series Installation Instructions Manual

Downflow air discharge
Hide thumbs Also See for MERIT Series:
Table of Contents

Advertisement

Quick Links

Download this manual
2019 Lennox Industries Inc.
©
Dallas, Texas USA
Contents
Unit Dimensions - inches (mm) ......................................2
ML195DF Gas Furnace ..................................................3
Shipping and Packing List ..............................................3
Safety .............................................................................3
General ...........................................................................5
Combustion, Dilution, Ventilation Air...............................5
Setting Equipment ..........................................................8
Filters ............................................................................ 11
Duct System ................................................................. 11
Pipe Fittings Specifications...........................................12
Joint Cementing Procedure ..........................................14
Venting Practices ..........................................................14
INSTALLATION
INSTRUCTIONS
ML195DF
MERIT
SERIES GAS FURNACE
®
DOWNFLOW AIRDISCHARGE
507269-03
02/2019
Supersedes 07/2018
THIS MANUAL MUST BE LEFT WITH THE
HOMEOWNER FOR FUTURE REFERENCE
This is a safety alert symbol and should never be
ignored. When you see this symbol on labels or in man-
uals, be alert to the potential for personal injury or death.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer (or
equivalent), service agency or the gas supplier.
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves and
protective clothing.
Vent Pipe Guidlines ......................................................15
Gas Piping ....................................................................32
Electrical .......................................................................34
Integrated Control .........................................................41
Unit Start-Up .................................................................38
Gas Pressure Measurement.........................................39
Proper Combustion.......................................................40
High Altitude .................................................................40
Testing Non Direct Applications for Proper Air ..............41
Repair Parts Lsit ...........................................................41
Other Unit Adjustmens..................................................42
Service..........................................................................42
Twinning .......................................................................44
Start-Up Checklist.........................................................44
