EOS4 SAFETY LIGHT CURTAIN
SUMMARY
INTRODUCTION ................................................................................................................................................. 3
PRINCIPLE OF OPERATION ........................................................................................................................... 4
INSTALLATION ................................................................................................................................................... 5
Positioning ........................................................................................................6
Master/Slave Positioning....................................................................................7
Calculation of safety distance ............................................................................8
Multiple systems................................................................................................9
Use of deflecting mirrors .................................................................................10
Distance from reflective surfaces .....................................................................11
Mechanical assembly and optical alignment.....................................................12
Vertical positioning of the light curtain ............................................................13
Models with 30, 40mm resolution ................................................................13
Models with 50, 90mm resolution ................................................................13
Multibeam Models ........................................................................................14
Horizontal positioning of the light curtain .......................................................14
Electrical connections ......................................................................................15
Emitter connections......................................................................................16
Receiver connections ....................................................................................17
Warnings regarding connection cables..........................................................18
functions) ........................................................................................................19
Automatic operation .....................................................................................19
Manual operation..........................................................................................19
Connection of external contactors K1 and K2 ...............................................20
Examples of connection with REER safety modules .......................................21
OPERATION AND TECHNICAL DATA .................................................................................................... 22
Light signals ....................................................................................................22
Emitter light signals......................................................................................22
Receiver light signals ....................................................................................22
TEST function ..................................................................................................23
Status of the outputs .......................................................................................23
Technical specifications ...................................................................................24
Dimensions......................................................................................................26
CHECKOUTS AND MAINTENANCE.......................................................................................................... 27
Checking of light curtain efficiency ..................................................................27
Troubleshooting ..............................................................................................28
Accessories/Spares ..........................................................................................30
GUARANTEE...................................................................................................................................................... 31
8540733 • 10th February 2009 • Rev.1
E
O
S
4
S
A
F
E
T
Y
E
O
S
4
S
A
F
E
T
Y
L
I
G
H
T
C
U
R
T
A
L
I
G
H
T
C
U
R
T
A
I
N
I
N
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EOS4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Reer EOS4

  • Page 1: Table Of Contents

    Configuration and operating modes (Master Models / With integrated control functions) ......................19 Automatic operation ..................19 Manual operation..................19 Connection of external contactors K1 and K2 ..........20 Examples of connection with REER safety modules ........21 OPERATION AND TECHNICAL DATA ....................22 Light signals ....................22 Emitter light signals..................22 Receiver light signals ..................22 TEST function ....................23...
  • Page 2 EOS4 SAFETY LIGHT CURTAIN ABBREVIATIONS AND SYMBOLS USED IN THIS MANUAL FE = Functional earth (earth connection) M/S = Master/Slave System OSSD = Output Signal Switching Device = Light curtain’s solid state safety outputs TX = Safety light curtain emitter.
  • Page 3: Introduction

    EOS4 SAFETY LIGHT CURTAIN INTRODUCTION The EOS4 light curtain is an optoelectronic safety device belonging to the category of Type 4 electro-sensitive protective equipment for the protection of personnel exposed to risks inherent in the use of hazardous machines or plants, complying with the IEC 61496-1,2 and EN 61496-1 standards.
  • Page 4: Principle Of Operation

    • 50mm and 90mm (protected heights from 300mm to 1800mm): PROTECTION OF THE LIMBS. The EOS4 is also available in a Multibeam version with a distance between the mirrors of: • 500mm (2 beams), 400mm (3 beams), 300mm (4 beams).
  • Page 5: Installation

    INSTALLATION Before installing the EOS4 safety system, check all the conditions listed below: The level of protection of EOS4 (Type 4, SIL3, SILCL3 PLe) must be compatible with the level of danger of the system to be protected. The safety system is used only as a stopping device and not to control the machine.
  • Page 6: Positioning

    EOS4 SAFETY LIGHT CURTAIN Positioning The Emitter EOS4E and the Receiver EOS4R must be positioned so that it is impossible to access the dangerous area from above, from below and from the sides without intercepting one of the beams. Useful indications for correct positioning of the light curtain are provided in the figure below.
  • Page 7: Master/Slave Positioning

    In addition to standard models (that can be positioned either horizontally or vertically), EOS4 can be purchased in a MASTER/SLAVE configuration. This configuration comprises two (or three) pairs of light curtains in which the two (or three) Emitters and the two (or three) Receivers are connected in series.
  • Page 8: Calculation Of Safety Distance

    EOS4 SAFETY LIGHT CURTAIN Calculation of safety distance The light curtain must be positioned at a distance equal to or greater than the minimum safety distance S so that the dangerous point can be reached only after stopping the dangerous movement of the machine (Figure 5).
  • Page 9: Multiple Systems

    EOS4 SAFETY LIGHT CURTAIN Multiple systems When several EOS4 are used, precautions must be taken to prevent optical interference between these: position the elements so that the beam of the Emitter of one system is received only by its respective Receiver.
  • Page 10: Use Of Deflecting Mirrors

    EOS4 SAFETY LIGHT CURTAIN Use of deflecting mirrors For protection or control of areas accessible from several sides, one or more deflecting mirrors can be used in addition to the Emitter and Receiver. Deflecting mirrors make it possible to redirect the beams generated by the Emitter on several sides.
  • Page 11: Distance From Reflective Surfaces

    EOS4 SAFETY LIGHT CURTAIN Distance from reflective surfaces The presence of reflective surfaces close to the light curtain may cause occasional reflections that prevent sensing. Referring to Figure 8, object A is not detected due to surface S that, reflecting the beam, closes the optical path between the Emitter and Receiver.
  • Page 12: Mechanical Assembly And Optical Alignment

    EOS4 SAFETY LIGHT CURTAIN Mechanical assembly and optical alignment The Emitter and Receiver must be installed facing each other, at a distance equal to or less than that indicated in the technical data. Using the provided inserts and fastening brackets, place the Emitter and Receiver so that they are aligned and parallel to each other, and with the connectors facing the same side.
  • Page 13: Vertical Positioning Of The Light Curtain

    EOS4 SAFETY LIGHT CURTAIN Vertical positioning of the light curtain Models with 30, 40mm resolution point of Light curtain These models are suitable for hand detection. danger The minimum safety distance S is calculated according to the following formula: S = 2000 (t...
  • Page 14: Multibeam Models

    EOS4 SAFETY LIGHT CURTAIN point of danger Multibeam Models These models are suitable for whole body Light grid detection and must not be used to detect arms or legs. minimum safety distance determined according to the following formula: direction S = 1600 (t...
  • Page 15: Electrical Connections

    EOS4 SAFETY LIGHT CURTAIN Electrical connections WARNINGS Before making electrical connections, make sure that the mains voltage matches the one indicated in the technical data. The Emitter and Receiver must be powered at a 24Vdc±20%. The external power supply must comply with EN 60204-1.
  • Page 16: Emitter Connections

    EOS4 SAFETY LIGHT CURTAIN Emitter connections STANDARD - WITH INTEGRATED CONTROL FUNCTIONS - MASTER MODELS M12 5-pin primary connectors. PIN COLOUR NAME TYPE DESCRIPTION Brown 24VDC 24VDC power supply Light curtain configuration White RANGE0 complying with the EN61131-2 standard (ref. Table 5)
  • Page 17: Receiver Connections

    EOS4 SAFETY LIGHT CURTAIN Receiver connections STANDARD MODELS - M12, 5-pin connector. PIN COLOUR NAME TYPE DESCRIPTION OPERATION Brown 24VDC 24VDC power supply White OSSD1 Static safety output 1 PNP active high Blue 0VDC 0VDC power supply Black OSSD2 Static safety output 2...
  • Page 18: Warnings Regarding Connection Cables

    EOS4 SAFETY LIGHT CURTAIN SLAVE/SLAVE2 MODELS - M12, 5-pin primary connectors. COLOUR NAME DESCRIPTION Brown 24VDC 24VDC power supply Communication White LINE_A MASTER-SLAVE Blue 0VDC 0VDC power supply Communication Black LINE_B MASTER-SLAVE Grey Ground connection Table 10 - M12, 5 pins Primary Slave RX MASTER MODELS - M12, 5-pin Secondary Connector.
  • Page 19: Configuration And Operating Modes (Master Models / With Integrated Control Functions)

    Table 12 –Setting of manual/automatic mode Automatic operation If the EOS4 light curtain is used in AUTOMATIC mode, it will not be equipped with a start/restart interlock circuit. In most applications, this safety function is compulsory. Carefully assess the risks analysis of your own application.
  • Page 20: Connection Of External Contactors K1 And K2

    EOS4 SAFETY LIGHT CURTAIN Connection of external contactors K1 and K2 In both operating modes, it is possible to activate control of the external contactors K1/K2. If this control is to be used, it is necessary to connect pin 4 of the M12 8-pin connector of the Receiver with the power supply (24VDC) via a set of NC contacts (feedback) of the external contactors.
  • Page 21: Examples Of Connection With Reer Safety Modules

    2 and 4 of the Emitter as indicated in Table 4. Figure 21 - EOS4 A: Manual operation with AD SR1 module For correct operation of the light curtain, connect pins 2 and 4 of the Emitter as indicated in Table 4.
  • Page 22: Operation And Technical Data

    FAIL condition (Table 18) RED BLINKING Table 15 – RX light signals EOS4 (With integrated control functions) The type of fault is identified by the number of flashes (see Troubleshooting chapter) Double blinking (at power-on) of the GREEN led indicates that high range has been selected.
  • Page 23: Test Function

    The minimum duration of the TEST command must be at least 4 msec. Status of the outputs On the Receiver of the EOS4 there are two PNP static outputs whose status depends on the condition of the protected area. The maximum permissible load for each output is 400mA @ 24VDC, corresponding to a resistive load of 60Ω.
  • Page 24: Technical Specifications

    PL e - Cat.4 ISO 13849-1 If the EOS4 light curtain is used in a Master-Slave configuration, use the following formula to calculate the total response time of the device: t tot = [0,11 * (Nr slave1 + Nr master ) + 0,9376] * 2...
  • Page 25 EOS4 SAFETY LIGHT CURTAIN 30 mm Resolution Models 1053 1203 1353 1503 Number of beams Response time 10,5 15,5 18,5 (EOS models) Response time t tot = [0,11 * (Nr slave1 + Nr master ) + 0,9376] * 2 (Master + 1 slave)
  • Page 26: Dimensions

    EOS4 SAFETY LIGHT CURTAIN Dimensions Figure 25 - Emitter and Receiver Height Model 1050 1200 1350 1500 1113 1263 1413 1563 A (Master/Slave) 236.5 386.5 536.5 686.5 836.5 986.5 1136.5 1286.5 1436.5 1586.5 61.5 29.5 D (Master/Slave2) 34.5 (With 2 connectors)
  • Page 27: Checkouts And Maintenance

    ON. Figure 27 – Efficiency check The EOS4 light curtain does not require any specific maintenance; however, it is good practice to clean the front protective surfaces of the mirrors of the Emitter and Receiver. Clean with a damp cloth; in very dusty environments, after cleaning the front surface, spray with an anti-stat product.
  • Page 28: Troubleshooting

    Shield the beams emitted by the interfering Emitter using opaque protections Check connections. OSSD outputs error 5 consecutive flashes If the fault persists, send to REER for repair. 6/7 consecutive Send the device to ReeR laboratories for Internal failure flashes...
  • Page 29 Reer assistance service. If the checks suggested are not sufficient to restore the correct operation of the system, please send the device, with all its parts, to the REER laboratories, clearly indicating: • product code number (P/N field shown in the product label);...
  • Page 30: Accessories/Spares

    EOS4 SAFETY LIGHT CURTAIN Accessories/Spares MODEL ITEM CODE AD SR1 ADMIRAL AD SR1 safety module 1330900 AD SRM ADMIRAL AD SRM safety module with muting function 1330904 AD SR0 ADMIRAL AD SR0 safety relay 1330902 AD SR0A ADMIRAL AD SR0A safety relay...
  • Page 31: Guarantee

    EOS4 SAFETY LIGHT CURTAIN GUARANTEE All new EOS4 systems are guaranteed by REER for a period of 12 (twelve) months under normal working conditions, against defects due to faulty materials and workmanship. During the aforesaid period, REER promises to replace faulty parts free of charge. This guarantee covers both material and labour.
