- Page 1 INSTRUCTION MANUAL 12V Ride-On Truck with Remote SKY2856 + 2857 + 2858 Ver. 4...
-
Page 2: Battery Warnings
SAFETY Please retain these instructions for future reference. This vehicle must be assembled by an adult who has read and understood the instructions in this manual. Keep the packaging and bags away from children and dispose of all packaging before use. Always use common sense and safe practices when operating this vehicle. -
Page 3: User Warnings
USER WARNINGS The following safety hazards may result in serious injury or death: • Never leave a child unattended. • Always sit in the seat when using this vehicle. • Keep your hands, hair, and clothes away from moving parts. •... - Page 4 TOOLS REQUIRED PHILLIPS NEEDLE NOSE SMALL 65 LBS 1 PERSON APPROXIMATELY SCREWDRIVER PLIERS WRENCH ASSEMBLY 1 HR. CAPACITY ASSEMBLY HARDWARE 4 x 10mm 3 x 12mm 10 x 20x 2mm 12 x 22x 2mm 2.5 x 16mm 12 PCS 2 PCS 2 PCS 6 PCS 5 PCS...
- Page 5 PARTS HOOK WINDSHIELD SIDE MIRROR 1 PC 1 PC 2 PCS SEAT FRONT AXLE STEERING WHEEL 1 PC 1 PC 1 PC FRONT REFLECTOR REMOTE CONTROL CHARGER 2 PCS 1 PC 1 PC Pg. 5...
- Page 6 PRODUCT ASSEMBLY FRONT REAR Flip the vehicle over and lay it on a level surface. Slide out the part A rear axle from underneath the vehicle. Remove the nut and bolt from the stabilizer near the rear gear box. Slide the part A rear axle through the gear box, metal stabilizer, and shocks.
- Page 7 TOOLS REQUIRED PRODUCT ASSEMBLY Slide on a part B rear wheel and secure it with a part 4 large washer and part 5 pin. Use needle nose pliers to bend the pin and lock the wheel in place. Repeat on the other side. Snap a part D hub cap onto each wheel. Slide the part K front axle into the steering column.
- Page 8 TOOLS REQUIRED PRODUCT ASSEMBLY Slide on a part 4 large washer, part C front wheel, another part 4 large washer, and secure it with a part 5 pin. Use needle nose pliers to bend the pin and lock the wheel in place.
- Page 9 TOOLS REQUIRED PRODUCT ASSEMBLY Secure the part G hook to the rear of the vehicle with two part 1 screws. Slide the part F bar light into the holes located on the frame pieces and secure it with two part 2 screws. Pg.
- Page 10 TOOLS REQUIRED PRODUCT ASSEMBLY Join the connector from the part L steering wheel to the connector from the steering mount, then snap the steering wheel into place. Pg. 10 Snap on the part H windshield.
- Page 11 TOOLS REQUIRED PRODUCT ASSEMBLY Snap on part I side mirrors. Attach the part J seat with two part 1 screws. Pg. 11...
- Page 12 TOOLS REQUIRED PRODUCT ASSEMBLY Slide the two part M front reflectors onto the front of the vehicle and they will snap in place. CONTROL MODULE SPEAKER STEERING SHAFT BATTERY Under the hood, connect the red wire to the red terminal on the battery Pg.
- Page 13 DASHBOARD DIAGRAM FORWARD: DRIVE FORWARD POWER SWITCH PEDAL PARK: PARK VEHICLE BATTERY CHARGING (PEDAL IS DISABLED) SOCKET LIGHT SWITCH REVERSE: DRIVE IN REVERSE Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop. MP3 FUNCTIONS •...
-
Page 14: Troubleshooting
TOOLS REQUIRED REMOTE CONTROL FUNCTIONS FREQUENCY KEY TURN LEFT FORWARD TURN RIGHT EMERGENCY HIGH-SPEED LED BRAKE MEDIUM-SPEED LED REVERSE LOW-SPEED LED SPEED • Insert 2 AAA batteries into the remote control • After 10 seconds of non-operation, the indicator light will turn o and the remote will go into power-saving mode. - Page 15 CHARGING INSTRUCTIONS AND WARNINGS • Charging socket is located under the dashboard on the left side. Insert one end of the part O charger into the charging socket and plug the other end into a wall outlet (see Dashboard Diagram). •...
-
Page 16: Product Warranty Information
ASSEMBLY IS COMPLETE! PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included. All returned items will receive a full refund back to the original payment method.
