- Page 1 INSTRUCTION MANUAL 12V Ride on ATV Quad SKY2071 + SKY2580 + SKY3754 Ver. 3...
-
Page 2: Battery Warnings
SAFETY Please retain these instructions for future reference. This vehicle must be assembled by an adult who has read and understood the instructions in this manual. Keep the packaging and bags away from children and dispose of all packaging before use. Always use common sense and safe practices when operating this vehicle. -
Page 3: User Warnings
USER WARNINGS The following safety hazards may result in serious injury or death: • Never leave a child unattended. • Always sit in the seat when using this vehicle. • Keep your hands, hair, and clothes away from moving parts. •... -
Page 4: Tools Required
TOOLS REQUIRED AAA - PHILLIPS FLATEHEAD SMALL 3 AA BATTERIES 77 LBS 1 PERSON APPROXIMATELY SCREWDRIVER SCREWDRIVER WRENCH ASSEMBLY 45 MIN. CAPACITY ASSEMBLY HARDWARE 6 PCS 2 PCS 4 PCS PARTS REAR AXLE WHEEL HUB CAP 1 PC 4 PCS 4 PCS GEAR BOX HANDLE BARS... -
Page 5: Product Assembly
PRODUCT ASSEMBLY Flip the vehicle over and lay it on a level surface. Slide on a part 1 washer, part B wheel, and another part 1 washer onto a front wheel axle and secure it with a part 3 pin. Repeat on the other side. Snap a part C hub cap onto each wheel. Slide the part A rear axle through the body of the vehicle. - Page 6 TOOLS REQUIRED PRODUCT ASSEMBLY Insert 3 AAA batteries into the part E handlebars. Remove the bolt and nut from the handlebars, slide on the handlebars, and then replace the bolt and nut to secure the handlebars to the mount. WHITE CONNECTOR RED CONNECTOR Undo the latch on the seat to reveal the battery components.
-
Page 7: Care And Maintenance
CHARGING INSTRUCTIONS AND WARNINGS • Charging socket is located on the back of the vehicle near the rear left wheel. Insert one end of the part F charger into the charging socket and plug the other end into a wall outlet. •... -
Page 8: Product Warranty Information
DASHBOARD DIAGRAM Power Switch FAST FOWARD: Drive Forward SLOW PARK: Park Vehicle (Pedal Is Disabled) REVERSE: Drive In Reverse High/Low Speed Pedal Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop. PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
